Checking and Replacing the Ribbon

Checking the Printer Ribbon Supply

The Consumables area of the home page (Figure 5-9 on page 5-7)
displays a ribbon meter, showing the amount of unused ribbon
remaining in the cassette.
Figure 5-9: Printer Ribbon Supply
The meter displays three different colors to help check the ribbon level
at a glance.
• BLUE = Adequate ribbon availability
• YELLOW = Approximately 50 m (164 ft) of ribbon remaining
• RED = Approximately 20 m (66 ft) of ribbon remaining

Replacing the Ribbon

Rev AA
Caution
EQUIPMENT DAMAGE. The use of incompatible ribbon can
seriously damage your printer and such damage will not be
covered by your printer warranty. Use only the ribbon that is
approved by your dealer.
Zodiac Plus Operator Manual
Ribbon Meter
Checking and Replacing the Ribbon 5-7
