[LOGIC UNIT]
REF ORDER
NO. NO.
J1* 6510022490 AXK5S30045P
J2* 6510019870 AXK5S40045P
J51* 6910014251 IMSA-9202B-2-06Z041-PT1
J102* 6510019981 52808-1671
J602* 6510019971 52808-1071
J604* 6510019971 52808-1071
J802* 6510024261 S9B-PH-SM4-TB (LF) (SN)
J803* 6510024401 S11B-EH (LF) (SN)
J804* 6510024251 S5B-PH-SM4-TB (LF) (SN)
J805* 6510024111 52793-2070
J806* 6510024131 IMSA-9637S-40Y905
J807* 6510024151 50FY-BMT-TB (LF) (SN)
J808* 6510022471 40FLT-SM2-TB (LF) (SN)
J809* 6510022471 40FLT-SM2-TB (LF) (SN)
J810* 6510022731 S13B-PH-SM4-TB (LF) (SN)
J811* 6510021561 52808-2470
J812* 6510020701 52793-1270
J813* 6510020081 52808-2071
J814* 6510019971 52808-1071
J815* 6510019991 52808-2271
J816* 6510019991 52808-2271
J820* 6510003581 S10B-EH-S (LF) (SN)
J821* 6510003551 S07B-EH-S (LF) (SN)
J822* 6510021601 S2B-PH-SM4-TB (LF) (SN)
J823* 6510021601 S2B-PH-SM4-TB (LF) (SN)
J824* 6510024100 SC25-02WL
J825* 6510019421 B8B-ZR-SM4-TF (LF) (SN)
J826* 6510023801 S4B-ZR-SM4A-TF (LF) (SN)
MP101 8510016490 2590 LOGIC B-PLATE
MP103 8930063300 AL SHEET (AK)
MP201 8510016480 2590 LOGIC C-PLATE
MP203 8510016500 2590 LOGIC A-PLATE
MP204 8930063320 2590 A-SHEET
MP205 8930063310 2590 B-SHEET
MP801 8510005350 VCO Sheild plate (A)
[DC-DC UNIT]
REF ORDER
NO. NO.
J2* 6510003471 B11B-EH-S (LF) (SN)
J3* 6510003431 B07B-EH-S (LF) (SN)
J4* 6510003461 B10B-EH-S (LF) (SN)
J5* 6510020421 S4B-PH-SM4-TB (LF) (SN)
W1 8900012780 OPC-1298
MP21 8510015720 2590 DC-DC A-CASE
MP22 8510015730 2590 DC-DC A-PLATE
MP41 8510015720 2590 DC-DC A-CASE
MP42 8510015730 2590 DC-DC A-PLATE
MP61 8510015720 2590 DC-DC A-CASE
MP62 8510015730 2590 DC-DC A-PLATE
MP81 8510015720 2590 DC-DC A-CASE
MP82 8510015730 2590 DC-DC A-PLATE
MP101 8510015720 2590 DC-DC A-CASE
MP102 8510015730 2590 DC-DC A-PLATE
MP121 8510015740 2590 DC-DC B-CASE
MP122 8510015750 2590 DC-DC B-PLATE
Screw abbreviations A, B0, BT: Self-tapping PH: Pan head ZK: Black NI-ZU: Nickel-Zinc SUS: Stainless
DESCRIPTION QTY.
DESCRIPTION QTY.
[RXPLL-B UNIT]
REF ORDER
NO. NO.
1 J2* 6510019991 52808-2271
1 J10* 6510007020 TMP-J01X-V6
1 J351* 6510007020 TMP-J01X-V6
1 J561* 6510007020 TMP-J01X-V6
1 J601* 6510007020 TMP-J01X-V6
1 J681* 6510007020 TMP-J01X-V6
1 J831* 6510007020 TMP-J01X-V6
1 J1002* 6510007020 TMP-J01X-V6
1 J1101* 6510007020 TMP-J01X-V6
1 J1201* 6510007020 TMP-J01X-V6
1 J1301* 6510007020 TMP-J01X-V6
1 J1501* 6510018961 B2B-PH-SM4-TB (LF) (SN)
1 J1701* 6510019981 52808-1671
1
1 W1052 9016201006 73/98/025/X98/X98
1 W1401 9029495075 73/98/020/X98/X98
1 W1411 7120000480 MJP-0.4
1
1 MP1 8930039710 Rubber sheet (V)
1 MP101 8510010760 1876 DDS CASE
1 MP102 8510010770 1876 DDS COVER
1 MP103 8510010850 1897 D/A CASE
1 MP151 8510013510 2355 VCO CASE
1 MP201 8510013510 2355 VCO CASE
1 MP221 8510015780 2590 VCO CASE
1 MP222 8510015790 2590 VCO COVER
1 MP223 8810007231 Set screw (H) 3X8 ZC3
1 MP224 8930062300 RUBBER SHEET (BI)
MP301 8930065740 2590 D-Earth SPRING
1 MP501 8510010760 1876 DDS CASE
1 MP502 8510010770 1876 DDS COVER
1 MP503 8510010850 1897 D/A CASE
1 MP541 8510011970 2177 OSC CASE
1 MP542 8510011960 2177 OSC COVER
1 MP543 8510005070 599 Sheild plate
1 MP544 8930030940 Emboss tape (D)
MP545 8930030940 Emboss tape (D)
MP546 8930027810 Emboss tape (B)
MP547 8930025070 Sponge (CW)
MP548 8930030940 Emboss tape (D)
MP549 8930030940 Emboss tape (D)
MP601 8930065740 2590 D-Earth SPRING
MP651 8510005980 724 Shield case
MP652 8510005990 724 Shield case cover
1
MP1058 6910001130 10M SHIELD CASE
1
MP1101 8510016060 2590 HF CASE
1
MP1102 8510015910 2590 HF COVER
1
MP1103 8930020860 IC-HOLDER
MP1104 8930070820 Shield Sponge (BK)
1
MP1301 8510016050 2590 50M CASE
MP1408 6910001130 10M SHIELD CASE
1
MP1501 8930065740 2590 D-Earth SPRING
1
MP1502 8930065740 2590 D-Earth SPRING
1
MP1503 8930065740 2590 D-Earth SPRING
1
MP1504 8930065740 2590 D-Earth SPRING
1
MP1505 8510010460 1691 MAIN SHIELD PLATE
1
MP1651 8510016340 2590 2MIX CASE
1
MP1652 8510016390 2590 SHIELD PLATE
1
MP1653 8930024170 Earth spring (G)
1
1
1

[REG UNIT]

1
REF ORDER
NO. NO.
MF1 2710000520 SB0812H-ICOM-00
EP1 6910016052 FP2212B-2
6910016062 FP2212C-2
MP1 8930068760 2590 MAGNETIC SHIELD
[BPF UNIT]
REF ORDER
NO. NO.
J1* 6510020521 52808-1271
J101* 6510007020 TMP-J01X-V6
J102* 6510007020 TMP-J01X-V6
J103* 6510023750 01K1971-10
J104* 6510023750 01K1971-10
J105* 6510023750 01K1971-10
J106* 6510007020 TMP-J01X-V6
J107* 6510007020 TMP-J01X-V6
J108* 6510007020 TMP-J01X-V6
J504* 6510023750 01K1971-10
J505* 6510023750 01K1971-10
J506* 6510007020 TMP-J01X-V6
J601* 6510007020 TMP-J01X-V6
J602* 6510007020 TMP-J01X-V6
W506 9025900640 61/99/130/W13A/W13A
W507 9086700300 Wire 08
*: Refer to SECTION 8 "BOARD LAYOUTS."
6 - 5
DESCRIPTION QTY.
DESCRIPTION QTY.
[USA], [CHN]
[others]
DESCRIPTION QTY.
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
2
1
1
1
1
1
1
1
4
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
2
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
