Icom IC-7800 Service Manual page 127

[MAIN UNIT]
REF ORDER
NO. NO.
J1* 6510023671 TCS4480-0141577
J2* 6510023661 TCS4470-0141577
J3* 6510023671 TCS4480-0141577
J4* 6510023661 TCS4470-0141577
J5* 6450001130 JPJ2042-01-110
J6* 6510023730 LGY6502-0600C
J7* 6510023730 LGY6502-0600C
J8* 6510023740 LGR4609-7000
J9* 6510024940 HEC2305-016250
J140* 6510023720 LGY6501-0600C
J141* 6510023720 LGY6501-0600C
J490* 6510023750 01K1971-10
J495* 6510023701 TORX178S (F)
J496* 6510023711 TOTX178S (F)
J501* 6510007020 TMP-J01X-V6
J502* 6510007020 TMP-J01X-V6
J503* 6510007020 TMP-J01X-V6
J801* 6510007020 TMP-J01X-V6
J802* 6510007020 TMP-J01X-V6
J808* 6510007020 TMP-J01X-V6
J900* 6510022471 40FLT-SM2-TB (LF) (SN)
J901* 6510015541 B4B-ZR-SM4-TF (LF) (SN)
J940* 6510022471 40FLT-SM2-TB (LF) (SN)
F1 5220000230 S-N5054 #01
F2 5220000230 S-N5054 #01
F3 5210000041 FGB 2A PBF
W1 9024801019 74/98/020/X98/X98
EP501 9088000010 IRRAX D=1.5 L=12MM
MP496 8930062740 2590 M-SPRING
MP501 8930014140 Earth spring (D)
MP502 8510015800 2590 2LO CASE
MP503 8510000180 117 Sheild plate
MP511 8510015900 2590 M-2LO CASE
MP551 8930014140 Earth spring (D)
MP801 8930014140 Earth spring (D)
[DSP-A BOARD]
REF ORDER
NO. NO.
J921* 6910013900 IMSA-9180S-22A
J961* 6910012460 IMSA-9180S-30A
MP1 8510014140 2432 DSP COVER
MP2 8510016110 2590 M-DSP CASE
MP3 8930062220 THERMALLY SHEET (AO)
[DSP-B BOARD]
REF ORDER
NO. NO.
J921* 6910013900 IMSA-9180S-22A
J961* 6910012460 IMSA-9180S-30A
MP1 8510014140 2432 DSP COVER
MP2 8510016110 2590 M-DSP CASE
MP3 8930062220 THERMALLY SHEET (AO)
[DSP-TX BOARD]
REF ORDER
NO. NO.
J921* 6910013900 IMSA-9180S-22A
J961* 6910012460 IMSA-9180S-30A
MP1 8510014140 2432 DSP COVER
MP2 8510016110 2590 M-DSP CASE
MP3 8930062220 THERMALLY SHEET (AO)
[MEMORY BOARD]
REF ORDER
NO. NO.
J1* 6510024210 AXK6S30435P
J2* 6510024200 AXK6S40435P
MP1 8930028840 Sponge (DF)
MP2 8930028840 Sponge (DF)
MP3 8930063720 AL SHEET (AN)
Screw abbreviations
DESCRIPTION
DESCRIPTION
DESCRIPTION
DESCRIPTION
DESCRIPTION
A, B0, BT: Self-tapping PH: Pan head ZK: Black NI-ZU: Nickel-Zinc SUS: Stainless
[SCOPE UNIT]
REF ORDER
QTY.
NO. NO.
1 J1* 6510007020 TMP-J01X-V6
1 J2* 6510007020 TMP-J01X-V6
1 J3* 6510007020 TMP-J01X-V6
1 J4* 6510020001 52808-3071
1 J11* 6510007020 TMP-J01X-V6
1 J901* 6510023720 LGY6501-0600C
1 J902* 6510023120 CD6109SA1J0
1 J903* 6510024040 TM11R-5M2-88-LP
1 J904* 6510024032 UBA-4R-D10T-4D (LF) (SN)
1 J905* 6450001941 KEY-15S-2A3A (LF) (SN)
1 J906* 6510019971 52808-1071
1 J907* 6510020251 B9B-PH-SM4-TB (LF) (SN)
1 J908* 6510022311 B5B-PH-SM4-TB (LF) (SN)
1 J909* 6510003471 B11B-EH-S (LF) (SN)
1 J910* 6510019421 B8B-ZR-SM4-TF (LF) (SN)
1
1 MP3 8930014140 Earth spring (D)
1 MP101 8510015810 2590 MIX CASE
1 MP301 8510015810 2590 MIX CASE
1 MP601 8510015770 2590 DSP CASE
1 MP701 8510015880 2590 S2LO CASE
1 MP801 8510015891 2590 S3LO CASE-1
1 MP802 8510014870 2577 RX-VCO CASE
MP901 8850001860 Flat washer M3 SUS 3X6X0.5
1 MP902 8850000420 S-washer M3 NI
1
1
1
[RXPLL-A UNIT]
1
REF ORDER
NO. NO.
1
1
J2* 6510019991 52808-2271
1
J10* 6510007020 TMP-J01X-V6
1
J351* 6510007020 TMP-J01X-V6
1
J421* 6510007020 TMP-J01X-V6
1
J561* 6510007020 TMP-J01X-V6
1
J601* 6510007020 TMP-J01X-V6
J681* 6510007020 TMP-J01X-V6
J831* 6510007020 TMP-J01X-V6
J1001* 6510007020 TMP-J01X-V6
J1002* 6510007020 TMP-J01X-V6
J1101* 6510007020 TMP-J01X-V6
QTY.
J1201* 6510007020 TMP-J01X-V6
J1301* 6510007020 TMP-J01X-V6
1
J1501* 6510018961 B2B-PH-SM4-TB (LF) (SN)
1
J1701* 6510019981 52808-1671
1
W1052 9016201006 73/98/025/X98/X98
1
W1401 9029495075 73/98/020/X98/X98
1
W1411 7120000480 MJP-0.4
MP1 8930039710 Rubber sheet (V)
MP101 8510010760 1876 DDS CASE
MP102 8510010770 1876 DDS COVER
MP103 8510010850 1897 D/A CASE
MP151 8510013510 2355 VCO CASE
MP201 8510013510 2355 VCO CASE
QTY.
MP221 8510015780 2590 VCO CASE
MP222 8510015790 2590 VCO COVER
1
MP223 8810007231 Set screw (H) 3X8 ZC3
1
MP224 8930062300 RUBBER SHEET (BI)
MP301 8930065740 2590 D-Earth SPRING
1
MP501 8510010760 1876 DDS CASE
1
MP502 8510010770 1876 DDS COVER
1
MP503 8510010850 1897 D/A CASE
MP541 8510011970 2177 OSC CASE
MP542 8510011960 2177 OSC COVER
MP548 8930025070 Sponge (CW)
MP601 8930065740 2590 D-Earth SPRING
MP651 8510005980 724 Shield case
MP652 8510005990 724 Shield case cover
QTY.
MP1058 6910001130 10M SHIELD CASE
MP1101 8510016060 2590 HF CASE
1
MP1102 8510015910 2590 HF COVER
1
MP1103 8930020860 IC-HOLDER
MP1104 8930070820 Shield Sponge (BK)
1
MP1301 8510016050 2590 50M CASE
1
MP1408 6910001130 10M SHIELD CASE
1
MP1501 8930065740 2590 D-Earth SPRING
MP1502 8930065740 2590 D-Earth SPRING
MP1503 8930065740 2590 D-Earth SPRING
MP1504 8930065740 2590 D-Earth SPRING
MP1505 8510010460 1691 MAIN SHIELD PLATE
MP1651 8510016340 2590 2MIX CASE
MP1652 8510016390 2590 SHIELD PLATE
QTY.
MP1653 8930024170 Earth spring (G)
1
*: Refer to SECTION 8 "BOARD LAYOUTS."
