Tekmar 654 User Manual

Snow Melting Control 654
This brochure will provide you with the information you need to benefit the most from your snow melting control. Please visit
www.tekmarControls.com for more detailed information on this or any other tekmar product.

Display

Status Field
Operation Field
Touch to turn system
off while away
Melt or Stop
Touch to adjust settings
Operation Field
MELT System is melting snow or ice.
IDLE System is idling.
Status Field
Warm Weather Shut Down. The slab is naturally
WWSD
warm enough to melt snow or ice.
CWCO Cold Weather Cut Out. Too cold to melt.
Timed melting operation. System operates until
TIMED
time has elapsed.
WARM Slab is warming up to the melting temperature.
Away scene. No melting until the away scene is
AWAY
exited.
Symbols
HEAT ON
Heat is turned on.
tekmarNet
Communication is present.
A Watts Water Technologies Company
User Manual
Touch to
®
Touch to display
Run Time,
Outdoor & Slab
Temperature
Touch to quickly enter
the View menu
Touch to go to the next setting
Home Button
ENTER
Return to the Home Screen
Press and hold for 3
Home
Button
seconds to access the
programming menus.
STRM System is in storm operation.
OFF System is off.
Pending. The system has detected water but it is too
PEND
cold to operate or the schedule is in Idle or Off.
Zone priority in effect. Zone must wait until higher
WAIT
priority zone finishes melting.
SENSOR Tandem 090 sensor.
TRACK This zone tracks the melting operation of zone 1.
WARNING SYMBOL
Indicates an error is present.
ARROWS
Adjust the displayed setting.
1 of 4
654_U
05/13
Snow Melting Replaces: New
© 2013 654_U - 05/13
