Accton Technology ES3016C Specification Sheet

ES3016C 16-port 10/100 Fast
Powered by Accton
Ethernet Switch
With our advanced switching technology,
the ES3016C 16-port 10/100Mbps Fast
Ethernet Switch will boost your network
performance with much more than just full duplex data transfer and dedicated bandwidth.
Product Overview
With our advanced switching technology, the
ES3016C 16-port 10/100Mbps Fast Ethernet
Switch will boost your network performance with
much more than just full duplex data transfer
and dedicated bandwidth. It features non-
blocking, wire-speed switching that forwards
packets as fast as your network can deliver them.
MAC address learning and aging to prevent
packet collisions are also included.
No matter how intensive your network demands,
the advanced chipset of ES3016C Fast Ethernet
Switch supports your needs, with an affordable
and efficient networking solution you can count
on.
Key Benefits
Total bandwidth of ES3016C up to
3.2Gbps (non-blocking)
Support up to 2K MAC address
Store-and-forward scheme to forward
packets.
Operates at maximum packet filtering
and forwarding rate
The Vitruvian Man, Leonardo da vinci, 1490
Leonardo da vinci said, "Simplicity is the ultimate sophistication." It is also our Edge-Core fundamental design philosophy.
Features
16 10/100Mbps auto-sensing ports
Up to 200Mbps per port at full duplex
Perfect for running10Base-T and
100Base-TX hardware
Data flow control filters out erroneous
frames (CRC error, fragment, and jab
ber)
Auto MDI/MDI-X
