Accton Technology ES3005 Specification Sheet

ES3005/ES3008 5-port/8-port
Powered by Accton
10/100 Fast Ethernet Switch
This legendary Edge-Core 5-port and 8-Port Switchs can significantly increase your speed of network traffic.
Product Overview
High-speed 10/100Mbps switching for your
desktop
This legendary Edge-Core 5-port and 8-Port
Switchs can significantly increase your speed of
network traffic. A switch serves the same
function as a hub in a network- tying your
network equipment together. However unlike a
simple-minded hub that divides the network's
bandwidth among all the attached devices, a
switch delivers full network speeds at each port.
Installing this cost-effective 5-port and 8-Port
10/100Mbps Switchs can potentially increase
your network speed by 5 and 8 times respec-
tively.
It's the perfect way to drop this ES3005/ES3008
switch in place of your current PCs/ hubs to
integrate 10Mbps Ethernet and 100Mbps Fast
Ethernet devices. All ports are auto speed
negotiating, and have automatic MDI/MDI-X
crossover detection. Therefore, you don't need to
worry about the cable type. Each port indepen-
dently negotiates the best speed at half- or full-
duplex mode, for up to 200Mbps of bandwidth
per port. Fast store-and-forward switching
prevents damaged packets from being passed on
into the network.
Let the Edge-Core 5port/8-Port Fast Ethernet
Switchs kick your network into higher gear.
Key Benefits
5 (ES3005) or 8 (ES3008) auto-sens
ing10/100 ports with auto
MDI/MDI-X crossover detection
Total bandwidth of devices up to
1Gbps (ES3005)/1.6Gbps (ES3008)
Supports up to 2K MAC addresses
Address learning and Aging, and Data
Flow Control for enhanced transmis-
sion reliability
The Vitruvian Man, Leonardo da vinci, 1490
Leonardo da vinci said, "Simplicity is the ultimate sophistication." It is also our Edge-Core fundamental design philosophy.
Features
Ideal for integrating your 10Base-T and
100Base-TX network hardware
Support up to 2K MAC addresses
Provides dedicated bandwidth in half-
or full-duplex modes
Up to 200Mbps, full-duplex bandwidth
at each port
Each port supports auto MDI/MDI-X
cable detection
Compatible with all major network op-
eration systems
Advanced store-and-forward packet
switching scheme optimizes data trans-
fer
