Viking VCBB360 Installation Instructions Manual

Viking VCBB360 Installation Instructions Manual

Built-in bottom mount refrigerator
Hide thumbs
Table of Contents

Advertisement

Quick Links

INSTALLATION
INSTRUCTIONS
BUILT-IN BOTTOM MOUNT REFRIGERATOR
IMPORTANT - PLEASE READ AND FOLLOW
Make sure that incoming voltage is the same as unit rating. An electric rating plate specifying voltage, hertz, wattage, amps,
and phase is attached to the product.
To reduce the risk of fire, electric shock, or injury to persons, installation work and electrical wiring must be done by qualified
people in accordance with all applicable codes and standards, including fire-rated construction.
GENERAL INFORMATION
EXCESSIVE WEIGHT HAZARD
Use two or more people to move and install refrigerator.
Failure to follow this instruction can result in back or other injury.
It is your responsibility to :
-comply with installation specifications and dimensions
-properly install refrigerator
-make sure that you have these materials which are necessary for proper installation:
1/4" (6 mm) copper tubing with shutoff valve
1/4" (6mm) compression fitting
-assure that floor will support refrigerator (more than 600 lbs. [272 kg.]), door panels and contents
-provide a properly grounded electrical outlet
-assure that location will permit appliance doors to open 90
VIKING RANGE CORPORATION
Greenwood, Mississippi (MS) 38930 USA
Most of the refrigerator's weight is at the top.
Extra care is needed when moving the
refrigerator to prevent tipping. Keep
cardboard shipping piece or plywood under
refrigerator until it is installed in the operating
position.
minimum
o
111 Front Street
(601) 455-1200

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VCBB360 and is the answer not in the manual?

Questions and answers

Related Manuals for Viking VCBB360

Summary of Contents for Viking VCBB360

  • Page 1 INSTALLATION VIKING RANGE CORPORATION 111 Front Street Greenwood, Mississippi (MS) 38930 USA INSTRUCTIONS (601) 455-1200 BUILT-IN BOTTOM MOUNT REFRIGERATOR IMPORTANT - PLEASE READ AND FOLLOW Make sure that incoming voltage is the same as unit rating. An electric rating plate specifying voltage, hertz, wattage, amps, and phase is attached to the product.

  • Page 2: Cutout Dimensions

    CUTOUT DIMENSIONS Diagram A Description Dimension Width of lag bolt location 1” (2.54 cm) Distance from right side of cutout to left lag bolt location 32 9/16” (82.7 cm) Width of receptacle location 27 1/2” (69.9 cm) Distance from right side of cutout to right lag bolt location 3 3/8”...
  • Page 3 DIAGRAM A Lag bolt Location 2” X 4” Mounting Board Receptacle Location Water line entry...

  • Page 4: Electrical Requirements

    ELECTRICAL REQUIREMENTS If codes permit a separate grounding wire is used, it is recommended that a qualified electrician ELECTRICAL SHOCK HAZARD determine that the grounding path is adequate. Electrically ground refrigerator. Do Not ground to a gas pipe. Check with a Do Not use an extension cord.

  • Page 5: Refrigerator Installation

    REFRIGERATOR INSTALLATION Most of the refrigerator’s weight is at the top. Extra care is needed when moving the refrigerator to EXCESSIVE WEIGHT HAZARD prevent tipping. Do Not lower the refrigerator Use two or more people to move and install refrigerator. Failure against the shipping base when moving the to follow this instruction can result in back or other injury.
  • Page 6 9. Pull end of nylon cord around refrigerator side level with top of refrigerator door. Tape cord in place. 10. Roll refrigerator into cutout to within 3” (7.6 cm) of being flush with kitchen cabinets. To avoid kitchen cabinet damage, place cardboard between kitchen cabinets and refrigerator.

  • Page 7: Water Connection

    WATER CONNECTION The garden hose fitting, compression nut, and sleeve are located in the literature packet. The water filtration system is shipped in the crisper drawer. 1. Flush air and impurities from water line by turning on water supply and running a pint or more of water into a bucket.
  • Page 8 BASIC SPECIFICATIONS AND DIMENSIONS DESCRIPTION VCBB360 Overall Width 36 5/16” (92.2 cm) Overall Height from Bottom Min. 83 1/4” (211.5 cm) to Max. 84 1/4” (214.0 cm) Overall Depth from Rear To side trim 22 3/16” (56.3 cm) To front of top grill 24 11/16”...

  • Page 9: Front View

    FRONT VIEW 36 5/16” (92.2 cm) Min. 83 1/4” 51 7/16” (211.5 cm) (130.7 cm) Max. 84 1/4” (214.0 cm) 23” (58.4 cm)

  • Page 10: Side View

    SIDE VIEW 24 11/16” (62.7 cm) Min. 83 1/4” (211.5 cm) Max. 84 1/4” (214.0 cm) 22 3/16” (56.4 cm) 58 3/8” (148.3 cm)

  • Page 11: Electrical Grounding Instructions

    WIRING DIAGRAM BUILT-IN BOTTOM MOUNT REFRIGERATOR/FREEZER WARNING: ELECTRICAL GROUNDING INSTRUCTIONS This appliance is equipped with a three prong grounding plug for your protection against shock hazard and should be plugged directly into a properly grounded three prong receptacle. DO NOT CUT OR REMOVE THE GROUNDING REFER ONLY TO FEATURES WHICH ARE EQUIPPED WITH THIS UNIT.
  • Page 12 Viking Range Corporation 111 Front Street Greenwood, Mississippi (MS) 38930 USA • (601) 455-1200 F1692 Specifications subject to change without notice (PS599VR)
