- Page 1 Trantec S5 Wireless Microphone Series Q U I C K I N S T A L L A T I O N G U I D E...
- Page 2 Technical specifi cations WEEE statement and warranty INTRODUCTION The Trantec S5 series represents our commitment to our customers by providing high-quality, reliable wireless audio links using our considerable design expertise gained over many years as a leading edge manufacturer. We would like to thank you for purchasing this product and would like you to spend a few moments studying this Quick Installation Guide, especially the safety instructions, before going on to ‘read’...
-
Page 3: Getting Started
GETTING STARTED The S5 series is a high quality, fully featured wireless microphone system with many features including an intuitive operating system. To enable you to get started we recommend you initially set up the system as outlined in the next few pages. - Page 4 RECEIVER SET-UP l n i ” 4 f e i Rear View Diversity switch A/B indicators Infra-red port Jog wheel Power switch indicator Mute indicator Headphone output Front View 1. Attach the supplied antennae (2) to the rear panel BNC antenna connectors as shown in above illustration.
- Page 5 Go to step 6 to program transmitter via the Receiver infra-red port. Please note: For S5.3 product the single user frequency will be added to Transmitter with receiver Bank1. In the case of the S5.5 it will be added to the Custom “USER” bank. See CD-ROM for more information.
- Page 6 TRANSMITTER SET-UP HANDHELD End cap Power ‘On’ Position Up/Down Grille Sleeve Infra-red port Frequency Battery indicator 1. Undo handheld sleeve by unscrewing the end cap anti-clockwise and then gently sliding the sleeve to expose the LCD and Battery compartment. Place alkaline “AA” cell into battery compartment observing the correct polarity.
- Page 7 TRANSMITTER SET-UP BELTPACK 1. Insert battery into compartment by sliding end cap forward and up. Ensure battery is inserted with the correct polarity as shown. Antenna 2. Screw antenna into antenna socket as illustrated. 3. Plug Lavalier mic into Mini-XLR socket. 4.
-
Page 8: Troubleshooting
• Set transmitter AF gain so the receiver VU indicates 0db with occasional peaks to +6dB. • Keep Microphone/Instrument lead away from the antenna on the beltpack. • Do not mix other brands of wireless microphone as Trantec cannot guarantee multi- channel compatibility. - Page 9 S5 SERIES RACK MOUNT KIT The rackmounting kit is supplied as standard with S5.5 systems, or is available as an accessory for S5.3 systems. POWER POWER RF A RF A RF B RF B 30 60 125 250 500 30 60 125 250 500...
-
Page 10: Technical Specifications
RSSI range: 10 steps 30dB range Antenna Inputs: BNC 50 Ohm AF switches: Low Cut – High Boost – Phase Reversal (S5.5 only) AF Output level: XLR Line +15dBm max. XLR Mic -25dBm max. Unbal ” 4 ⁄ Antenna Phantom: 9V @ 60mA short-circuit protected on each RF port 10 Banks x 24 Channels (S5.5) - Page 11 CE DECLARATION OF CONFORMITY 0891 This equipment is in compliance with the essential requirements and other relevant provisions of Directives 1999/5/EC, 89/336/EC or 73/23/EC. IMPORTANT NOTICE. Before using this wireless microphone system please observe the requirements of each country with respect to frequency allocations and individual licensing requirements.
