Fujitsu ETERNUS2000 100 Setup Manual

disk storage system
Read this Setup Guide first
Read and understand the "Safety Precautions"
before use.
"Safety Precautions"
The company names, product names and service names mentioned in this document are registered trademarks or trademarks of their respective companies.
The latest version of this document and the latest information about the ETERNUS2000 is released in the following web-site. Access the following address if needed.
http://www.fujitsu.com/global/services/computing/storage/system/eternus2000/
Preparation, Installation Area & Package Contents
S T E P
Prepare the following items
The following items need to be prepared in advance:
IP addresses and subnet mask
Network equipment such as a switching hub
Web browser
Java Runtime Environment 5.0
Make sure that all of the following manuals (supplied with the ETERNUS2000 on paper or CD) are handy:
"ETERNUS2000 disk storage system User Guide for models 100 and 200"
"ETERNUS2000 models 100 and 200 disk storage system Safety Precautions"
"ETERNUS2000 models 100 and 200 disk storage system Package Contents"
"ETERNUS8000, ETERNUS4000, ETERNUS2000 disk storage system Server Connection Guide (iSCSI)"
"ETERNUS8000, ETERNUS4000, ETERNUS2000, ETERNUS6000, ETERNUS3000 ETERNUSmgr Install Guide"
"ETERNUSmgr User Guide -Introduction-"
"ETERNUS2000 ETERNUSmgr User Guide -Settings/Maintenance- For models 100 and 200"
"4.1 Prior Preparation" in the "ETERNUS2000 disk storage system User Guide for models 100 and 200"
Secure the Installation Area
Installation space
Check that the installation area meets the space requirements
of the rack in which the ETERNUS2000 is to be installed.
Installation requirements
Check that the installation area satisfies all the requirements
described in the "Setting" section of the "ETERNUS2000
models 100 and 200 disk storage system Safety Precautions"
"3.1 Preparation" in the "ETERNUS2000 disk storage system User
Guide for models 100 and 200"
"ETERNUS2000 models 100 and 200 disk storage system Safety
Precautions"
Power outlets
Check that a sufficient number of suitable wall outlets are
available.
Environmental conditions
Temperature: 5 – 35°C
Humidity: 20 – 80%RH
Setup Guide (iSCSI type)
This guide describes the workflow required to proceed from installation to
operation of the
(for the ETERNUS2000 and maintenance engineer PC)
(Microsoft® Internet Explorer 6.0 or later, Mozilla Firefox™ 1.5.0.10 or later, or Netscape 7.1 or later)
(Update 11 or later) or Java Runtime Environment 6.0 (Update 3 or later)
(iSCSI type).
Workflow
1
Preparation, Installation Area
& Package Contents
2
Installation
3
Cable Connection
4
Pre-Setup Preparation
Check the Package Contents
Refer to the "ETERNUS2000 models 100 and 200 disk
storage system Package Contents" and check that there are
no missing items.
"ETERNUS2000 models 100 and 200 disk storage system Package
Contents"
model 100
P3AM-2552-02EN
5
ETERNUS2000 Basic Setup
6
Various Settings
7
Server Connection
8
Operation and Maintenance
Copyright 2009 FUJITSU LIMITED
model 200
Proceed to
next step
