W A R N I N G
Never immerse motor housing and/or handle
in liquid! The housing contains the electrical
components and is not sealed against liquid.
Contact with liquid can cause damage to the
blender and serious injury to the operator.
• THE TUBE AND BELL
There are two ways to proceed :
• Simple cleaning procedure after each different use
- Submerge the tube and bell in water and run for a
few seconds to clean.
- Unplug the power cord.
Complete cleaning procedure on a daily basis
- Unplug the power mixer and rinse the bell under a
water tap.
- Remove the bell from the tube, then remove the
blade (wear cutting gloves) ! Be careful to avoid
damaging the surface of the blade shaft and the
watertight seals.
- Always dilute the detergent/disinfectant (see
above).
- Thoroughly dry all parts before reassembling.

• BLADE

The blade can be removed from the bell for
thorough cleaning.
Always dry thoroughly to avoid spotting.

• ALUMINUM

Use soft-metal-safe cleaning agents!

• PLASTIC

Be careful, many cleaning agents are corrosive and
are not safe for use on plastics!
Do not use strong alkaline detergent (having a high
concentration of soda or ammonia).
10

• WHISK GEARBOX

Never immerse the whisk gearbox in water. Clean it
with a cloth lightly dampened (not dripping).
Never run the whisk gearbox through a dishwasher.
• WHISKS
The whisks can be cleaned either by hand or in a
dishwasher.
To ensure effective cleaning, always remove the
whisk ejector.

• MIXING TOOL HOUSING

Never immerse the mixing tool housing
in water or put it in the dishwasher.
Instead, clean it with a slightly damp
cloth.
• MIXING TOOL
The mixing tool can be washed either by
hand or in the dishwasher. You
can also clean it with a slightly damp
cloth.

MAINTENANCE

• BLADE
Over time the blades will become worn and will need
to be replaced. The washer and seals should also be
replaced at this time. A blade service kit is available.

• TUBE SEAL

In order to maintain a watertight seal between the
tube and bell, inspect the seal for wear and replace
it if necessary.

• SEAL RING

The seal ring can be lubricated using a suitable food
grade grease. In order to maintain a watertight
seal, check the seal ring for wear and replace it if
necessary.
• WHISKS
The per formance of the whisks depends on
the condition of the wires. The metal wires may
become worn over time. In order to ensure optimum
performance, they will need to be replaced. Do not
use a defective or damaged whisk!

• CARTRIDGE

You need to change the cartridge :
- If liquid starts seeping into the foot
- If there is any play in the blade
1) Cartridge dismantling :
Position the knife dismantling tool
cartridge . Remove the cartridge from its place
B
by knocking on the knife dismantling tool
D
with a plastic mallet.
2) Cartridge mounting :
Direct the ears of cartridge
in order to be aligned
B
with the groove of the bell
. Push the car tridge
A
with the hand in the direc-
tion of arrow, then clip on
into the bell thanks to the
knife dismantling tool.
on the
C
C
