- Grasp the holder in one hand.
- With the other hand, take the first whisk and insert
the shaft into the bore B
A
box drive shaft. Make sure the drive lugs
properly aligned with the notches.
- As you push the whisk into the holder drive
shaft , rotate it slightly in order to slide
C
the drive lugs into the notches
shaft , thereby locking the whisk into place
C
inside the shaft.
- To check that the whisk is properly fixed inside the
shaft , gently pull the metal wires.
C
- Repeat this procedure with the second whisk. If
you cannot push it in properly, remove it, rotate it
90° and start again.
Removing the whisk from the whisk gearbox
While griping the
ejector in one hand
A
and the holder in
B
the other, pull the
ejector in the direction
of the arrow.
Removing the ejector
Hold the whisk by the
wires
With the other hand, pull
B
the ejector
direction of the arrow
(see figure).
A

• MIXING TOOL FUNCTION

(MP 450 Turbo FW XL)
of the whisk gear-
ATTACHING THE MIXING TOOL TO THE MIXING
are
TOOL HOUSING:
D
of the drive
D
A
Line the flat side of the mixing tool
flat side of the housing
Once the mixing tool has been attached to the
housing, simply insert the latter into the motor unit,
turning it in an anticlockwise direction.
B
DETACHING THE MIXING TOOL FROM ITS
HOUSING:
A
C
in one hand.
B
To release the mixing tool from its housing, simply
A in the
press the button
done is to remove the housing from the motor unit.
B
up with the
B
.
A
Mixing tool
housing
Mixing tool
. All that then remains to be
C
W A R N I N G
• Always unplug the power mixer before
cleaning it!
• Always dilute bleach according to the
instructions on the label
• Never run the motor assembly through a
dish machine.
Mixing tool
housing
• The type and concentration of the sanitation
agent must comply with 21 CFR 178 1010
Mixing tool
regulations.
• Clean according to local health department
regulations.

• THE MOTOR HOUSING

The power mixer must be clean through all stages
of production. Clean between each job using a
detergent or disinfectant. Dilute the detergent /
disinfectant following the instructions normally
specified on it's packaging container. Use a cloth
lightly dampened (not dripping) with the cleaning
solution.
Do not allow liquid to come into contact with
the electrical components contained within the
housing. Be careful when cleaning around vents
do not allow liquid to drip or seep into the
housing. Use a cloth lightly dampened (not drip-
ping) with water to remove detergent / disinfectant
then dry using a clean cloth.
After using the power mixer in a hot mixture,
cool the bottom of the tube in cold water before
disassembling the bell from the tube.
Clean immediately after use to prevent product from
sticking to surfaces.

CLEANING
