Disassembling The Bell From The Tube; Removing The Blades; Attaching The Whisk Gearbox To The Motor Unit; Removing The Gearbox - Robot Coupe MP 350 Turbo Combi User Manual

- Unplug the power mixer.
- Align the flat side of A the conical part of the
tube with catch on the inside of the bell.
B
- Insert the conical part into the bell. With the
C
washer touching the tube seal
the direction of the arrow (See figure) to lock the
bell lug and tube lug snugly together.
E F

Disassembling the bell from the tube

TURN TO REMOVE BELL
- Unplug the power mixer.
- Turn the bell in the direction of the arrow
next figure) to separate the bell lug
tube lug .
F
- Remove the bell.

Removing the blades

Unplug the machine. Turn the bell in the direction of
the arrow (see next figure) to separate the bell
1
from the foot lug . Remove the bell.
E F
To safely remove the sharp blades, hold with the
provided blade locking tool. Using the blade
disassembling tool, unscrew the male drive
coupling. As the drive coupling is unscrewed
disengage the blade for easy cleaning.
8
BLADES WITH WATERTIGHT SEALS
, turn the bell in
D
• WHISK FUNCTION
(MP 350 Turbo Combi, MP 450 Turbo Combi,
MP 450 Turbo FW)

Attaching the whisk gearbox to the motor unit

- Unplug the power mixer.
(see
1
- Align the flat side
from the
E
the whisk gearbox with the catch
of the aluminum casing.
- Insert the conical part
into the aluminum casing.
- Turn the whisk gearbox in the direction of the arrow
(see figure) until it is snugly locked into place.

Removing the gearbox

- Unplug the power mixer.
- Turn the whisk gearbox in the opposite direction
from that used to attach it.
- When it will go no further, remove the whisk
gearbox from the aluminum casing.
BLADE LOCKING
BELL
MALE DRIVING COUPLING
BLADE REMOVAL
of the conical part
A
on the inside
B
of the whisk gearbox
C
C
B
Fitting the whisk into the whisk gearbox
C
C of
A
D
A
B
E
