ZOpid HF-ZP035W Instruction Manual

3.5” display
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Enlarged version
3.5" DISPLAY DIGITAL PHOTO FRAME
HF-ZP035W
INSTRUCTION MANUAL
IMPORTANT: If the frame does not power on or you get dark gray screen
please connect frame to the AC adapter and RESET the frame. To reset, use
something pointy to press the RESET button which is inside the small hole right
below the USB port on the frame (see diagram on next page).
Please check our support website www.hittusa.com for FAQs and
Troubleshooting Tips.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HF-ZP035W and is the answer not in the manual?

Questions and answers

Related Manuals for ZOpid HF-ZP035W

Summary of Contents for ZOpid HF-ZP035W

  • Page 1 3.5” DISPLAY DIGITAL PHOTO FRAME HF-ZP035W INSTRUCTION MANUAL IMPORTANT: If the frame does not power on or you get dark gray screen please connect frame to the AC adapter and RESET the frame. To reset, use something pointy to press the RESET button which is inside the small hole right below the USB port on the frame (see diagram on next page).

  • Page 2: Buttons & Interface

    PREFACE We express our sincere thanks for purchasing this Digital Photo Frame (DPF)! Before operating this DPF, be sure to read this user manual carefully. After reading it, please keep it in a safe place for future reference. We reserve the right to make changes to this DPF, Software and/or this User Manual without notice.
  • Page 3 1. POWER:  Press & Hold this button to turn power ON or OFF  Press & quickly release this button to toggle between Digital Clock, Analog Clock and Calendar, while displaying clock/calendar  Press this button to pause slide show (from SD card only) – while in slide show mode 2.

  • Page 4: Basic Menu Functions

    BASIC MENU FUNCTIONS The MAIN MENU, as shown below will appear, when the frame power is turned ON or connected to computer’s USB port or AC Charger: PHOTO:  Press RIGHT’ or LEFT key to select PHOTO option from the Main menu and then press ENTER key to confirm the selection ...
  • Page 5 key to display that picture on full screen (SLIDESHOW will start automatically if Interval Time under SETUP is not set to Manual). NOTE: The frame will display pictures from SD card if inserted in the frame. If the card is not inserted then the frame displays pictures from the built-in memory NOTE: There is 32MB of built-in memory which holds about 90 pictures and...
  • Page 6 CALENDAR: Press RIGHT or LEFT key to highlight CALENDAR Menu Option and then press ENTER key to complete selection NOTE: Press ENTER button while displaying calendar to Enter Date and Time Change Mode  Once in Date and Time Change Mode YEAR starts flashing ...

  • Page 7: Photo Settings

     Use LEFT or RIGHT key to change Month  Press Enter to confirm selection and move to change DAY  Use LEFT or RIGHT key to change Day  Press Enter to confirm selection and move to change HOURS ...

  • Page 8: Interval Time

    INTERVAL TIME:  Press ENTER key to select Interval Time and change the time  Use RIGHT or LEFT key to select one of the following available options: 5 Seconds, 10 Seconds, 15 Seconds, 30 Seconds, 1 Minute, 2 Minutes, Manual (select this option to disable slideshow mode) ...
  • Page 9  Press ENTER key to select OSG Language and change the option  Use RIGHT or LEFT key to select one of the following available options: English, Chinese  Press ENTER key to confirm selection and move to the next SETUP option or press EXIT key to return to the Main Menu BRIGHTNESS: ...
  • Page 10 E. CONNECTING FRAME TO THE COMPUTER (to charge battery, download pictures and to display pictures without using rechargeable battery or AC adapter) Plug smaller end of the USB Cable into USB Port on the frame and the larger end of the cable into USB port on the computer.

  • Page 11: Important Notes

    IMPORTANT NOTES: 1. The built-in memory can hold about 90 pictures and requires DPFMate350 program, which is preinstalled on frames’ memory, to resize, format and download pictures to the built-in memory only. 2. SD card appears as a USB/Removable Drive if an SD card is inserted in the SD card slot on the frame, use computer’s Windows Explorer or Finder to move files from your computer to the SD card (DPFMate350 program is not required to copy picture-files to the SD card)
  • Page 12 application MacDPFMate350 or PhotoViewer is slightly different. The following screen appears on the computer when the computer successfully recognizes the frame and DPFMate350 software is automatically started: NOTE: If DPFMate350 application is not launched automatically, open Windows Explorer and open removable drive which appears as “CD Drive” and manually launch DPFmate350.exe...
  • Page 13 EXPLAINATION OF THREE APPLICATION INTERFACE AREAS & BUTTONS: SRC AREA: This area display’s computer’s hard-drive and other storage devices connected to the computer where pictures are saved (source files) PIC AREA: This area displays selected picture which can be rotated, resized and added to the selection to be downloaded to the frame’s built-in memory...
  • Page 14  Cut / Small  Press Cut button to enable Zoom In & Zoom and press Small to disable them – This feature is used to select specific area of the picture to copy to the frame  Zoom In  Zoom In on specific area of selected picture in Preview Area – move red box using the mouse to select different area of the picture ...
  • Page 15 TAG AREA: This “Selection Area” displays pictures already on frame’s’ built-in memory and newly selected pictures to be added to the frame’s memory. Pictures can be deleted from the frame, downloaded to the frame, and backed up to the computer from this area.
  • Page 16 STEPS TO COPY PICTURES TO FRAME’S BUILT-IN MEMORY: STEP 1: Use SRC Area to select picture from computer’s hard-drive or other storage devices connected to the computer STEP 2: Use PIC Area to edit picture (zoom in, zoom out, crop and rotate) STEP 3: Add picture to the Selection Area (by pressing ADD button) to be downloaded NOTE: Repeat Steps 1 to 3 for all the pictures to be copied to the frame and then perform STEP 4...

  • Page 17: Technical Specifications

    TECHNICAL SPECIFICATIONS Dimensions (W x H x T) 3.75 x 3.0 x 0.5 in (9.5 x 7.5 x 1.3 cm) Weight (w/o Case) 3.3 oz (93.5 g) Display Size & Type 3.5 inch LCD (4:3), TFT Panel LCD Resolution 320 x 240 pixels Max.
  • Page 18 TROUBLESHOOTING TIPS & FREQUENTLY ASKED QUESTIONS Q: How do I charge my Digital Photo Frame? A: You can charge frames’ built-in battery by connecting the frame using USB cable to a computer’s USB port or by using an A/C charger. Q: How do I know when to charge the battery? A: A low battery sign is displayed when battery charge is low indicating battery should be charged.
  • Page 19 Limited 90-Day Warranty Coverage: Hi-Tech Trading (USA), Inc. (“HiTT”) warrants this product (“product”) against defects in materials and workmanship under normal consumer use for 90 days from the date of purchase. HiTT, at its option, will at no charge repair, replace or refund the purchase price of this product should it not conform to this warranty.

  • Page 20: Customer Service

    Woodbury, NY 11797 U.S.A. CUSTOMER SERVICE Web: www.hittusa.com Email: help@hittusa.com ZOpid and the Stylized Logo are registered in the US Patent & Trademark Office. All other product or service names are the property of their respective owners. © 2011 Hi-Tech Trading USA, Inc.
