Summary of Contents for ZOpid HF-Z097HD
- Page 1 9.7” High Resolution Digital Photo Frame HF-Z097HD The pictures, diagrams and certain functions described in this manual may differ from the actual product due to different models. USER MANUAL Visit www.hittusa.com to check if an updated user manual is available...
-
Page 2: Cleaning The Lcd Screen
SAFETY AND GENERAL INFORMATION IMPORTANT INFORMATION ON SAFE AND EFFICIENT OPERATION OF THIS PRODUCT Before operating your Digital Frame, please read all these safety and operating instructions completely and then retain this manual for future reference. Keep all parts and accessories out of children’s reach ... -
Page 3: Table Of Contents
TABLE OF CONTENT Introduction......................3 Main Features....................3 Setting up Frame for First Time Use..............4 Remote Control / Keys on the Frame.............5 Storage Media Slots/Ports on the Frame............6 Basic Operations....................6 Viewing Photos in Slideshow Mode..............6 Main Menu......................7 Slideshow from a Selected Folder…...............8 Viewing Individual Pictures................9 Playing Video Files..................11 Listening To MP3 Music................13... -
Page 4: Introduction
Introduction Congratulations on your purchase of this digital photo frame. Before operating the unit, please read this manual carefully, and then retain it for future reference. This manual will help you use the many useful features that will make your photo frame viewing more enjoyable. -
Page 5: Setting Up Frame For First Time Use
Setting up Frame for First Time Use Open the package and remove the foam packing. Remove the photo frame from its protective sleeve. Install stand at the rear of the unit (Insert the end with the thread in the hole in the back of the frame and turn the stand clockwise to tighten it. -
Page 6: Remote Control / Keys On The Frame
Remote Control / Keys on the Frame Power on/off (Use as Esc/Exit key on the Frame) Mute, does not work if frame is in SETUP Mode. CALENDAR Display calendar Show information bar during Play mode EXIT Exit from the current mode – go to previous function PHOTO Enter Photo play mode –... -
Page 7: Storage Media Slots/Ports On The Frame
Storage Media slots/ports on the frame Basic Operations Photos and media can be viewed directly from one of the supported memory cards or USB Drive or you can copy files to frame’s built-in memory – See “Copying Pictures, Music & Video Files from Computer” section for instructions. -
Page 8: Main Menu
the memory card, you may have inserted it the wrong way. Reverse it and try again. NOTES: The digital picture frame displays pictures stored in JPEG format. Digital pictures stored in other formats are ignored by the frame. Make sure you have at least one picture stored on the built-in memory (NAND) or memory card. -
Page 9: Slideshow From A Selected Folder
CALENDAR icons. If selected storage device is removed, it disappears from the Main Menu and another device icon is highlighted. IMPORTANT: The slide show starts automatically, if the built-in memory or the memory card inserted in the slot has pictures stored on it when the frame is powered on. -
Page 10: Viewing Individual Pictures
view list of files and/or sub-folders. Select a file and press ENTER to start slide show – only the pictures from the selected folder are displayed (files from any sub-folders are not be displayed) NOTE: If slideshow is not started from selected folder following the process outlined above and instead button is pressed then the frame displays all the photos files on the selected memory card or built-in... - Page 11 When the desired photo is highlighted, press ENTER to view it on full screen. The photo shows up on full screen and remains still (in pause mode). Press ENTER again to begin slideshow mode. While a slideshow is playing or a picture is on display, press the OSD on remote or MENU button on frame and the following information Bar appears.
-
Page 12: Playing Video Files
Stop Stop slideshow and return to the photo thumbnail list (can also use Exit key) Zoom Increase the picture size by 2, 4, 8 or 16 times. Playing Video Files The digital picture frame supports the following video formats: Motion JPEG (AVI format used by most digital cameras), MPEG-1, MPEG-2, MPEG-4 –... - Page 13 While movie is playing, press the OSD/MENU button on the remote control to display Information Bar as shown below. The option icons displayed are as follows (Use LEFT/RIGHT keys to highlight one of the options on information bar and press ENTER: Previous/Next Play previous or next movie in the folder list (you can also use keys on the remote control to perform this function).
-
Page 14: Listening To Mp3 Music
Listening to MP3 music Select desired storage media from the Main Menu and press ENTER and then select MUSIC from the menu and press ENTER. A list of MP3 music files are listed on the left side of the screen. The right side shows the frequency chart and Status Bar, and below that the selected file information is displayed. -
Page 15: Copying/Deleting Files Using File Function
pictures on the storage media you want to use for slide show. Select the desired storage media from the Main Menu and then press the button on the remote control to begin the slideshow with background music. Copying/Deleting files using FILE function After Selecting the Storage Media from the Main Menu select File Icon from the Sub-Menu. -
Page 16: Setup Function
File copy status is displayed on the screen and when done the screen displays “Finished”. Press ENTER key to return to File/Folder List. Press EXIT key to return to the Main Menu SETUP Function Many of the picture frame functions can be changed through the SETUP Menu. -
Page 17: Calendar And Clock Display
(transition effects) Left-to-right, right-to-left, door-close, door-open, hori-cross, verti-cross and many others Music Repeat Mode Repeat one, repeat all, repeat off Movie Repeat Mode Repeat one, repeat all, repeat off Display Mode Normal, Wide Time Year Month Date Hours : Minutes Alarm Hours : Minutes Ring1, 2 or 3 On/Off Brightness... -
Page 18: Connecting Frame To A Computer
Connecting Frame to a Computer (Using Mini USB-port on the Frame) Connect big end of the USB Cable, provided with the frame, to computer’s USB port and connect the smaller end of the USB cable to the mini-USB port on the frame. -
Page 19: Technical Specifications
Technical Specifications Viewing Area 9.7” (Diagonally) Resolution 1024 x 768 Display Mode Luminosity 400cd/m2 max. Contrast 500:1 Viewing Angle 89/89/89/89 (CR=10) Menu Languages English, French, Deutsch, Spanish, Italian, Chinese Clock Alarm Photo Changing Interval 3, 5, 10 , 15 sec; 1, 15 min; or 1 hr Picture Setup Brightness, Contrast, Saturation Supported File Formats... - Page 20 Viewing Area 9.7” (Diagonally) Start-up Slideshow A/C Adapter Input: AC 110—240V (50Hz—60Hz) Output: 12V, 1.5A Working Temperature -20 to +45 degrees Dimensions (L x W x T) 9.4 x 7.6 x 0.9 inches without stand Weight 0.95 lbs with stand Package Content Digital Picture Frame, Stand, Power Adapter, User Manual, Remote Control, USB Cable...
-
Page 21: Frequently Asked Questions
Frequently Asked Questions Q: Why do my photos take so long to load? A: Generally the higher the resolution of the photo, the longer it takes to load. Resizing your photos to a lower resolution quickens the processing time. Q: How do I copy music files to the frame? A: The Digital Picture Frame only plays MP3 files, so audio files in other formats like WMA, ACC (iTunes) etc. -
Page 23: Warranty & Service
Warranty & Service Coverage: Hi-Tech Trading USA Inc. ("HiTT") warrants this digital frame ("Product") against defects in materials and workmanship under normal consumer use for 1 year from the date of purchase. HiTT, at its option, will at no charge repair or replace this Product should it not conform to this warranty. -
Page 24: Regulatory Compliance
Regulatory Compliance CE Declaration of Conformity Attestation RSH05080201-1, RSH06080201-2 We declare under our responsibility that the product is in conformity with the following standards EN55022: 1998 (Radio Disturbance requirement of Information Technology Equipment) EN55024: 1998 (Immunity requirement of Information Technology Equipment) EN61000-3-2: 2000 (Limits for Harmonic Current Emission) As assessed by the following applications standards:... -
Page 25: End-Of-Life Disposal
THIS CLASS B DIGITAL APPARATUS MEETS ALL REQUIREMENTS OF CANADIAN INTERFERENCE-CAUSING EQUIPMENT REGULATIONS. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. - Page 26 ZOpid and the stylized logo are registered in the US Patent &Trademark Office. All other product or service names are the property of their respective owners. © 2011 Hi-Tech Trading USA Inc The information contained in this User Manual is believed to be correct at the time of printing.
