Summary of Contents for ZOpid HF-ZG024P
- Page 1 2.4” TFT Mini Photo Frame HF-ZG024P USER MANUAL...
- Page 2 A. PREFACE We express our sincere thanks for purchasing this Mini Photo Frame (MPF)! Before operating this MPF, be sure to read this user manual carefully. After reading it, please keep it in a safe place for future reference. We reserve the right to make changes to this MPF, Software and/or this User Manual without notice.
- Page 3 B. PRECAUTIONS Before operating this MPF, please read the following precautions carefully: Do not operate this MPF in extremely cold, hot, dusty or damp environment Avoid putting this MPF under direct sunlight Do not scrub this MPF with a hard thing; it may result in scratches on the screen and/or damage to the hardware Keep this MPF and all accessories out of reach of children less than 3 years old.
-
Page 4: Buttons & Interface
C. BUTTONS & INTERFACE... - Page 5 1. USB Port: Use USB Cable to connect frame to the computer to download pictures and charge built-in rechargeable battery. NOTE: Frame can be used to display pictures while it’s being charged using computer’s USB port 2. ON/OFF: Turn power ON or OFF and is also used to RESET the frame (Menu) During play mode press this button to bring up the menu and press this button again to accept the selection (just like an ENTER key)
-
Page 6: Other Features
NOTE: When frame ON/OFF switch is used to turn power OFF, the frame resets and requires setting up menu functions again and frame will display first picture in the memory when powered ON. Pause：Pressing this button delays displaying next picture during slide show ►... -
Page 7: Basic Functions
IMPORTANT: The photo files must be converted, resized and downloaded by the convert tool to display on the frame. When the frame has no files, the screen will display: D. BASIC FUNCTIONS During Play Mode, press “M” button to display Main Menu NOTE: Press “►’’... -
Page 8: Clock Set
Display Mode Auto Slide • Select picture display interval for each pictures (in seconds) during slide show mode. • Press “M” key to complete selection • Select “Exit” to exit from the menu and start slide show Display Mode Manual Slide In Manual Slide mode press “►”... -
Page 9: Clock Display
Use “►” or “◄” key to set ON time and OFF time. Then press ‘’menu’’ to confirm and exit. Auto ON/OFF Select this option to disable Auto On/Off feature 5. CLOCK DISPLAY Use this option to select if you want to display date and time without displaying pictures or display just the time as a watermark during picture display Clock Display Normal... - Page 10 E. CONNECTING FRAME TO THE COMPUTER and to display pictures without using rechargeable battery) Plug smaller end of the USB Cable into USB Port on the frame and the larger end of the cable into USB port on the computer. When properly connected, you will see the following on frame display: NOTE: Optional A/C charger can be used to supply power and charge built-in battery •...
- Page 11 “PhotoViewer” software from the CD (included in the package) to your computer before using this option. NOTES: • Once frame is properly connected to the computer and “USB Update” is selected by pressing “M” key, your computer will recognize frame as a removable disk. But you CANNOT copy photos using File Explorer;...
-
Page 12: Using Photoviewer
USING PHOTOVIEWER (Picture convert and copy tool) NOTE: This tool converts pictures of JPG, BMP, GIF, TIF, and PNG formats Install “PhotoViewer” software from the CD that came with the frame Connect frame to a computer using USB cable (the following options will be displayed on the frame display) Select USB Update and press “M”... - Page 13 PhotoViewer”. Figure 1 (Pictures saved for Portrait Mode) Figure 2 (Pictures saved for Landscape Mode) Select the folder where you have the pictures you want to convert and copy to the frame...
- Page 14 Select the picture you want to copy to the frame, and then use the following picture EDIT tools: (Crop) Use this to select the picture area you want in the converted/resized picture IMPORTANT: For high-resolution pictures, PhotoViewer EDIT tool will automatically display the box showing the picture area that can be converted to fit the frame, you can move the box to select exact area you want saved in the resized picture.
- Page 15 “Portrait Mode” (See Figure 1 on previous page) “Landscape Mode” (see Figure 2 on previous page) You will have to Rotate pictures before saving for correct orientation. The default save mode is Portrait (as shown in Figure 1) Use this to select this picture for saving to the frame. IMPORTANT: Your changes are NOT saved to the frame until you use ”Synchronize”...
- Page 16 Use this to delete pictures that are already saved on the frame or you just selected to be saved to the frame IMPORTANT: Your changes are NOT saved to the frame until you use ”Synchronize” Use this to save a copy of converted picture to a folder on your computer as a backup (Optional) IMPORTANT: Your changes are NOT saved to the frame until you...
-
Page 17: Technical Specifications
(power will be supplied through computer’s USB Port) G. TECHNICAL SPECIFICATIONS Dimensions 8.5*5.5*1.2cm Screen Display 2.4 inch TFT Rechargeable (about 10 hours continuous Battery use after full charge) Supported Photo Format JPG, BMP, GIF, TIF and PNG (requires conversions) Memory capacity 32MB NOR flash, can store around 60 photos... -
Page 18: Troubleshooting
Accessories USB Cable, User Manual, Software CD H. TROUBLESHOOTING This is not a malfunction. This is not a USB mass storage Cannot format the device device and is accessible only by using “PhotoViewer” software installed on your computer. You cannot format this device Can’t see the picture that Make sure to use “Synchronize”... - Page 19 Limited 90-Day Warranty Coverage: Hi-Tech Trading (USA), Inc. (“HiTT”) warrants this product (“product”) against defects in materials and workmanship under normal consumer use for 90 days from the date of purchase. HiTT, at its option, will at no charge repair, replace or refund the purchase price of this product should it not conform to this warranty.
- Page 20 ZOpid and the Stylized Logo are registered in the US Patent & Trademark Office. All other product or service names are the property of their respective owners. © 2007 Hi-Tech Trading (USA), Inc. The information contained in this User Manual is believed to be correct at the time of printing.
