Hytera PD502 Quick Reference Manual

PD502 User Guide

Quick Reference

Radio Guide for
Push to Talk Button
Short Press
Long Press
Radio Operation
Charging the Radio
• Please ensure the radio is off when charging
• Charging while the radio is on shortens the lifespan of your battery
• Full charge may take up to 3 hours
• The radio should be placed in the charger with the speaker (front of
radio) facing the front of the charger.
Transmitting Voice Calls
• To initiate a transmission hold the Push to Talk (PTT) Button
• Once you press the PTT Button, the radio will emit a talk permit chirp
• This talk permit chirp signals that you can begin to speak
• When done speaking release the PTT Button
• For a set period of time the system resources are held to allow
immediate responses
• If there is no response within this period the system will be released
signaled by a call ended chirp
Quick Reference User Guide
Left View
LED Indicator
Speaker
Microphone
Front View
Channel Knob
Turning the Radio On
• Rotate the on / off volume knob to power on & set the volume
• If the radio is tuned to a non‐programmed channel it will emit a continuous
error tone
• Please reference the zone / channel list to select the appropriate channel
Receiving Voice Calls
• Portables automatically receive transmissions on the Talkgroup
Channel Controls
• There are zones
• Each zone has channels programmed
• To switch zones
• To switch channels Turn the Channel Knob
Power / Volume Knob
Accessory / Programming Port
