DataRoute voice User Manual
7.8
QoS Configuration
Please go to path: Network -> QoS Configuration page to enable Queue Management
Configuration. If Enable QoS checkbox is selected, a default DSCP mark should be chosen to
automatically mark incoming traffic without reference to a particular classifier. Click
Apply/Save button to save.
Note: If Enable QoS checkbox is not selected, all QoS will be disabled for all interfaces; The
default DSCP mark is used to mark all egress packets that do not match any classification
rules.
Please click QoS QUEUE button to enter the QoS Queue setup page, then click Add button.
This screen allows you to configure a QoS queue and assign it to a specific layer 2 interface.
The scheduler algorithm is defined by the layer 2 interface. Click Apply/Save to save and
activate the queue.
28
