Cabinet Parts - KitchenAid KBRS19KTBL11 Parts List

CABINET PARTS

For Model: KBRS19KTWH01, KBRS19KTBL01, KBRS19KTSS01
(White)
Illus. Part
No. No.
1
W10137649 Owners Manual
W10138304 Energy Tag
W10165418 Tech Sheet
2
3
67001130 White
67001131 Black
4 67005064 Label, Fill Tube
5 67006118 Roller Assembly
6 12627302 Clip, Grille
7 67006642 Pin, Center Hinge
8 67006611 Bolt, Adjusting
9 67006521 Screw
10 67001098 Cover, Fill Tube
11 67006380 Screw
12 67006473 Screw (8)
13 A3076901 Plug, Button
14 67006303 Screw (3)
15
67006960 White
67007043 Black
16 67003868 Foot Brake (2)
17
67003484 White
67003485 Black
18 12566604ED Hinge, Top
19 12479901 Plate, Cover
20 67006564 Screw (8)
21
67001014 White
67001012 Black
22
67006905 White
67006886 Black
24 67006662 Screw
25 67006425 Screw (9)
26 67007174 Bracket, Foot
27 67001173 Cover, Water Valve
28 12575101ED Cover, Unit
29 67003796 Insulation, Sound
30 W10164397 Tube, Drain
31 67001067 Clip, Drain Tube
32 67006737 Screw
33 B5759649 Gasket
(Black) (Stainless Steel)
DESCRIPTION
Literature Parts
Cabinet (Not a
Servicable Part)
Plug, Button (3)
(Rear)
Hinge, Center
Cover, Corner
Cover, Hinge
Grille Assembly
(Includes Clips)
2
W10185239
