Choosing a DMX Channel Mode with 4 or 6 Channal Occupation

The device has 2 DMX Modes. The Control Board allows you to assign the DMX Mode.
Setting DMX Mode
After setting the desired address via the UP or DOWN buttons, press the MODE button again and the
display shows 6CH.
In case you would rather select the 4-channel mode, press the DOWN button in order to choose the 4CH
setting.
Mode:
6CH (default setting)

DMX Protocol

6 Channel Mode
(compatible with EUROLITE DMX LED Operator 2, item no. 70064502)
Channel: Value:
1 000 – 255
Channel: Value:
2 000 – 255
Channel: Value:
3 000 – 255
Channel: Value:
4 000 – 255
Channel: Value:
5 000 – 255
Channel: Value:
000 – 000
001 – 005
6
006 – 010
011 – 255
4 Channel Mode
Channel: Value:
1 000 – 255
Channel: Value:
2 000 – 255
Channel: Value:
3 000 – 255
Channel: Value:
4 000 – 255
Value:
4CH
Function:
Red (0 – 100%)
Function:
Green (0 – 100%)
Function:
Blue (0 – 100%)
Function:
Cool white (0 – 100%)
Function:
Dimmer (0 – 100%)
Function:
ON
Sound Control (15 colors)
ON
Strobe (increasing)
Function:
Red (0 – 100%)
Function:
Green (0 – 100%)
Function:
Blue (0 – 100%)
Function:
Cool white (0 – 100%)
