Internal Programs, Sound Control

Press the MODE button to select the internal program mode. When the display shows P, you can select the
desired internal program, with or without sound control, via the UP or DOWN buttons (see following graphic).
Mode:
P

Sound Control/Sensitivity

Press the MODE button until the display shows S. You can select the desired sensitivity via the UP or
DOWN buttons.
Mode:
S S01 - S99 (S50 default setting)

DMX MODE

The Control Board allows you to assign the DMX fixture address, which is defined as the first channel from
which the LED PAR-64 QCL Short will respond to the controller.

Addressing

Press the MODE button until the display shows Add. You can now set the desired address via the UP or
DOWN buttons.
Setting the DMX Start Address:
Mode:
Add 001 - 512
Controlling:
After having addressed the LED PAR-64 QCL Short, you may now start operating it via your lighting
controller.
Note:
It's necessary to insert the XLR termination plug with 120
proper transmission on the DMX data link.
Value:
P01
P02
P03
P04
P05
P06
Endless loop in 15 colors,
P07
Endless loop in 15 colors,
P08
Endless loop in 15 colors,
P09
Value
Value:
Function:
Endless loop in 7 colors,
change every 3 seconds
Endless loop in 7 colors,
fade every 3 seconds
Endless loop in 3 colors,
change every 3 seconds
Endless loop in 3 colors,
fade every 3 seconds
Endless loop in 7 colors,
via sound control
Endless loop in 3 colors,
via sound control
change every 3 seconds
fade every 3 seconds
via sound control
in the last lighting in the link in order to ensure
21/23 00064094.DOC, Version 1.0
