EverMore SA-320 Installation Manual
Hide thumbs
Also See for SA-320:
- Installation manual (10 pages) ,
- Installation manual (8 pages) ,
- Installation manual (13 pages)
Table of Contents
Related Manuals for EverMore SA-320
Summary of Contents for EverMore SA-320
-
Page 1: Installation Guide
SA-320 Installation Guide SA-320 Installation Guide Date: Nov., 2004 Version: 1.0 All Rights Reserved EverMore Technology, Inc. 2F, No.7, R&D Road 1, Science-Based Industrial Park, Hsinchu, Taiwan, 300, R.O.C. http://www.emt.com.tw Page 1... - Page 2 SA-320 Installation Guide TABLE OF CONTENTS 1. Product Overview...………….……………………………………………….….3 1.1 Main Features....................3 1.2 Applications…...……………………………………………………………..3 1.3 Package Content…..………………………………………………………...3 2. Installation……………………………………………………………………….4 2.1 Mounting methods……………………………………………….………….4 2.2 Cable Wires Definition.………………………………………...…………...5 3. Technical Specification..………………………………………..…….………….5 4. Limited Warranty...….……………………………………………………….….7 5. Appendix..………………………………………………………………...……...7 EverMore Technology, Inc. 2F, No.7, R&D Road 1, Science-Based Industrial Park, Hsinchu, Taiwan, 300, R.O.C.
-
Page 3: Product Overview
1.3 Package Content When open the package, please check it includes the following items. Contact your dealer immediately if any item is missing or damaged. Installation Guide and Warranty Card SA-320 GPS Receiver with Cable Thread Adaptor Screw Pairs EverMore Technology, Inc. - Page 4 2.1.1 To mount the SA-320, with Thread Adaptor, on a standard cable pole. 2.1.2 To screw the SA-320 on the surface of the plate. 2.1.3 To screw the SA-320 on the surface of a plate from the other side. EverMore Technology, Inc.
-
Page 5: Technical Specification
SA-320 Installation Guide 2.2 Cable Wires Definition Wire Color Designation Green PGND, Power Ground Blue VCC, Power Supply + Yellow Brown RS-232 Transmit Tx, Output Signal White Violet RS-232 Receiver Rx, Input Signal Black SGND, Signal Ground 3. Technical Specification... - Page 6 Diameter: 83.3mm or 3.27-inch, Height: 60mm or 2.36-inch Dimensions 8.46oz or 240g Weight Protocol Features Description Protocols EverMore at 4800/9600 baud, 8N1 NMEA-0183 v2.20 at 4800 baud NMEA messages GGA, GLL, GSA, GSV, RMC, and VTG Interface Specification Features Description Interface RS-232C EverMore Technology, Inc.
-
Page 7: Limited Warranty
Preliminary Specification, Subject To Change without Notice 4. Limited Warranty The SA-320 GPS receiver is warranted to be defect free in material designed to use and production for one year from the date of purchase. Under normal operation conditions, any failure of this product caused by material/production within the warranted period, it would be replaced with no charge. - Page 8 EverMore Technology Inc. Information provided by EverMore Technology Inc. is believed to be accurate and reliable. However, no responsibility is assumed by EverMore Technology Inc. for its use. EverMore Technology Inc. reserves the right to change specification at any time without notice.
