Page 1: Installation Manual
INSTALLATION MANUAL IM-WMXG-0205-McQuay Group: INVERTER Part Number: A08014078756 Date: FEBRUARY 2005 INVERTER WALL MOUNTED SPLIT TYPE AIR CONDITIONER (G Series) © 2005 McQuay International... -
Page 2: Outline And Dimensions
OUTLINE AND DIMENSIONS Indoor Unit (MWMXG Series) TOP VIEW SIDE VIEW FRONT VIEW INSTALLATION PLATE All dimensions are in mm / (in) Dimension 10 / 15G / GR (35,4) (10,2) (7,8) (23,2) (9,7) (7,3) (4,9) (0,3) (2,2) (2,0) (16,5) (19,5) - Page 3 Indoor Unit (MWMXG Series) TOP VIEW SIDE VIEW FRONT VIEW CENTER LINE INSTALLATION PLATE All dimensions are in mm / (in) Dimension 20 / 25G / GR 1060 (41,7) (12,2) (8,6) (35,9) (11,6) (3,9) (2,0) (0,3) (1,9) (1,7) (13,9) (15,9)
- Page 4 Outdoor Unit (MLCX Series) All dimensions are in mm / (in) Dimension 10 / 15C / CR (27,5) (20,5) (9,8) (19,1) (6,8) (1,4) (3,7) (3,6) (3,3) (2,6) (17,3) (5,1) (4,3) (0,5) (0,7)
- Page 5 All dimensions are in mm / (in) Dimension 20 / 25C / CR (33,7) (28,7) (12,9) (20,2) (7,2) (1,7) (3,7) (5,9) (4,0) (4,4) (23,7) (5,0) (6,4) (0,7) (1,9) Dimension 20 / 25C / CR (1,3) (0,1) (0,9) (2,9) (3,0) NOTICE This product is subjected to Waste of Electrical and Electronic Equipment Regulations (WEEE Regulations).
- Page 6 WMX20G/MWMX020G 5WMX10GR / M5WMX010GR SLV20B/MLCV020B 5SLX10CR / M5LCX010CR 5WMX15GR / M5WMX015GR 5SLX15CR / M5LCX015CR R410A 5WMX20GR / M5WMX020GR 5WMX10G/M5WMX010G 5SLX20CR / M5LCX020CR 5SLX10C/M5LCX010C 5WMX25GR / M5WMX025GR 5WMX15G/M5WMX015G 5SLX25CR / M5LCX025CR 5SLX15C/M5LCX015C 5WMX20G/M5WMX020G 5SLX20C/M5LCX020C 5WMX25G/M5WMX025G 5SLX25C/M5LCX025C Part No.: A08014078756 IM-WMXG-0205 (1)-McQuay...
-
Page 7: Table Of Contents
CONTENTS - Outline And Dimensions page i-iv - Vacuuming and Charging page 7 - Safety Precautions page 2 - Indicator Lights page 8 - Installation Diagram page 3 - Air Conditioner Unit Operation page 9 - Installation Of The Outdoor Unit page 3 - Operating Range page 9... -
Page 8: Installation Diagram
INSTALLATION DIAGRAM Indoor Unit Air Filter Front Frame Back Housing Air Intake ON/OFF Switch Grille Indicator Drain Hose Lights Signal Receiver Air Intake Refrigerant Piping Air Discharge Nozzle Outdoor Unit INSTALLATION OF THE OUTDOOR UNIT The outdoor unit must be installed in such a way, so as to Condensed Water Disposal of Outdoor Unit prevent short circuit of the hot discharged air or obstruc- (Heat Pump Unit Only) -
Page 9: Installation Of The Indoor Unit
INSTALLATION OF THE INDOOR UNIT Mounting Installation Plate The indoor unit must be installed in such a way so as to Ensure that the wall is strong enough to withstand the weight prevent short circuit of the cool discharged air with the hot return air. -
Page 10: Refrigerant Piping
REFRIGERANT PIPING Piping Length & Elevation Cutting Copper Tube If the pipe is too long, both the capacity and reliability of 1/4t the unit will drop. As the number of bends increases, resistance to the flow of refrigerant system increases, thus lowering cooling capacity. -
Page 11: Electrical Wiring Connection
ELECTRICAL WIRING CONNECTION Inverter Cooling / Heat Pump Unit IMPORTANT : * The figures shown in the table are for information purpose only. They should be checked and selected to comply with the local/national codes of regulations. This is also subject to the type of installation and conductors used. -
Page 12: Vacuuming And Charging
VACUUMING AND CHARGING Purging the piping and the indoor unit Refrigerant Piping Except for the outdoor unit which is pre-charged with Allen key Flare nut refrigerant, the indoor unit and the refrigerant connection pipes must be air-purged because the air containing moisture that remains in the refrigerant cycle may cause malfunction of the compressor. -
Page 13: Indicator Lights
INDICATOR LIGHTS IR signal receiver Inverter Unit (MWMX-G) When an infrared remote control operating signal has been transmitted, the signal receiver on the indoor unit will make a <beep> sound to confirm acceptance of the signal transmission. Cooling unit IR Receiver / Heat Pump unit LED indicator lights The table shows the LED indicator lights for the air condi-... -
Page 14: Air Conditioner Unit Operation
AIR CONDITIONER UNIT OPERATION Dry mode Frost prevention • When the air humidity is high, the unit can operate in • When the air filter is dirty, the evaporating temperature dry mode. Press <MODE> button and choose <DRY>. will decrease and eventually cause frosting. •... -
Page 15: Electrostatic Filter
ELECTROSTATIC FILTER DUAL ACTION ELECTROSTATIC AIR PURIFYING AND DEODORIZING FILTER MEDIA AND FILTER FRAME ACTION 2- ACTION 1- DEODORIZING FILTER ELECTROSTATIC AIR PURIFYING FILTER Removes unwanted smells and odors in the air and keeps Removes microscopic dust, smoke and small invisible the room air fresh with activated carbon filter. -
Page 16: Service And Maintenance
SERVICE AND MAINTENANCE ! Warning • Disconnect from the main power supply before servicing the air conditioner unit. • DO NOT pull out the power cord when the power is ON. This may cause serious electrical shocks which may result in fire hazards. -
Page 17: Troubleshooting
When The Unit Is Not To Be Used For An Extended Long Period Of Time Operate the unit for 2 hours Remove the power plug. with the following setting. If you are using an independent electric circuit for your unit, Operating mode : cool cut off the circuit. - Page 18 • In the event that there is any conflict in the interpretation of this manual and any translation of the same in any language, the English version of this manual shall prevail. • The manufacturer reserves the right to revise any of the specification and design contain herein at any time without prior notification.
