Suzuki GSX250F Owner's Manual page 8

COOLANT TEMPERATURE GAUGE
®
The coolant temperature gauge in-
dicates engine coolant tempera-
ture when the ignition switch i's in
the "ON" position.
ACAUTION
Riding the motorcycle with highly
heated engine coolant may cause
engine overheating and damage the
engine. If the needle of the coolant
temperature indicates the red area
I of the meter, stop the engine and
allow the engine to cool.
TACHOMETER
®
The tachometer indicates the en-
gine speed in revolutions per min-
ute (r/min).
12
URE INDICATOR LIGHT (])
ACAUTION
Whenever the oil pressure indicator
lights up, indicating low oil pres- sure, stop the engine immediately.
First check the oil level and deter-
mine if the proper amount of oil is in the engine. If the oil level is low, refill the engine to the correct level.
If the light still does not go out, then have your authorized Suzuki dealer or qualified mechanic inspect your
motorcycle to determine the diffi-
culty. Do not operate the motorcy- cle when the light is lit as it may
cause'serious damage to the inter- nal parts of the engine or transmis-
sion.
TURN
SIGNAL INDICATOR
LIGHT
®
When the turn signals are being
operated either to the right or to the
left. the indicator will flash at the
same time.
NOTE: If turn signal light is not
operating properly due to bulb fila-
ment or circuit failure, the indicator
light does not flicker but remains
lit to notify the rider of the exis-
tence of failure.
FUEl lEVEl INDICATOR LIGHTS (jJ)
The fuel level indicator comes on
when the fuel level in the fuel tank
comes low, requiring fuel supply.
The yellow light will come on when
the fuel level in the fuel tank is
approximately 6 L (1.6/1.3 US/
Imp. gal) or less.
The red light will come on when the
fuel level in the fuel tank is approxi-
mately 2.5 L (0,7/0.5 US/Imp. gal)
or less.
NO TE: With the ignition switch in
the "ON" position but the engine
not started, the fuel level indicator
lights should come on to check the
bulb function. As soon as the en-
gine is started, the lights should go
out.
r
13
LEFT HANDLEBAR
HEADLIGHT FLASHER SWITCH CD
Press the switch to light the
headlight.
DIMMER SWITCH CV
When the switch is in "HI" position,
the high beam will be lit. At the
same time that the high beam is lit,
the high beam indicator will also
light in the instrument panel. When
the switch is in
"La"
position, the
low beam will be lit.
TURN SIGNAL SWITCH
®
Moving the switch to the "L" posi-
tion will flash the left turn signals.
Moving the switch to the "R" posi-
tion will flash the right turn signals.
The indicator light will also flash
intermittently, To cancel turn sig-
nal operation, push the switch on.
AWARNING
Always use the turn signals when
you intend to change lanes or make
a turn. Be sure to turn off the turn
signals after completing the turn or
lane change.
HORN SWITCH
@
Press the switch to sound the horn.
