Your scooter is equipped with either an off-board charger. To ensure maximum life
charge your batteries as described below:
Turn off the power of the scooter;

Slide away the cover of the battery socket at the driving position of the tiller

and insert the battery charger in the socket;
Put the charger into the outlet;

Do not switch on the battery charger until all the plugs are in position;

The led light of the battery will be amber while charging;

The led light will turn green when the batteries are fully charged;

If you are not going to use the scooter for more than a week, fully charge the

batteries and then disconnect them from the scooter.
8

PROBLEM ANALYSIS AND SOLUTIONS

Your Excel Galaxy Plus scooter is inspected and adjusted so that you can use it
immediately.
Number of lights
1
2
3
4
5
6
7
8
9
Picture 9
Meaning
Battery needs recharging
Battery voltage is too low
Battery voltage is too high
Current limit time out /Controller over heat
Brake fault
Not in neutral at power up
Speed pot error
Motor volts error
Other internal error
~ 22 ~
