Polaris 2013 Ranger EV Owner's Manual For Maintenance And Safety page 27

Malfunction Indicator Troubleshooting Guide
The malfunction codes will blink on the controller. The code definitions provided here are
for informational purposes only.
Tip: If the indicator illuminates due to a minor issue such as a low voltage condition or a sequence fault
(reversing direction without releasing the accelerator, turning the key on while in forward or
reverse), select neutral and turn the key off and on to clear the error. If the error does not clear,
please see your POLARIS dealer for diagnosis and repair.
# of Blinks
Steady
1
2
3
4
6
7
8
13
Charge Status Indicator Troubleshooting Guide
The code definitions provided are for informational purposes only. Please see your
POLARIS dealer for diagnosis and repair.
# of
Blinks
1 Battery high voltage
2 Battery low voltage
3 Charge time-out, battery pack not reaching
required voltage, charger output reduced
due to high temperatures
4 Battery could not be trickle-charged to
minimum voltage
5 Charger shut down due to overheating
6 Charger internal fault
Key was turned on in forward or reverse (switch to neutral, then to forward or
reverse)
Data or configuration error
Sequence fault
Power fault
Contactor issue
Throttle input error
Voltage protection
Controller or motor out of temperature range
Software fault
Code Definition
FEATURES AND CONTROLS
Code Definition
Check battery size and condition; reset
charger (interrupt AC power for 15 seconds)
Check connections; operate charger at
lower ambient temperature
Check battery for shorted or damaged cells
Ensure sufficient cooling air flow (open the
hood) and reset the charger (interrupt AC
power for 15 seconds)
Reset charger (interrupt AC power for 15
seconds); return to qualified service
provider if fault persists
Solution
23
