- Page 1 Wireless-N 150Mbps Long Range Wall Mount AP/Repeater ERA150 Wireless-N 150Mbps Long Range Wall Mount AP/Repeater V1.0...
-
Page 2: Table Of Contents
Table of Contents Introduction ..................................5 Features and Benefits .....................................6 Package Contents ......................................7 System Requirements.....................................7 Applications ........................................7 Before you Begin ................................9 Considerations for Wireless Installation ..............................9 Computer Settings (Windows XP/Windows 7)........................... 10 Computer Settings in Apple Mac X OS..............................13 Hardware Installation.................................... - Page 3 Operation Mode......................................28 IP Settings........................................29 Spanning Tree Setting....................................30 Wireless .................................... 31 Wireless Network ......................................31 Wireless Security ......................................36 Site Survey ........................................40 Wireless MAC Filter ...................................... 44 Wireless Advanced ....................................... 45 WPS (Wi-Fi Protected Setup)..................................47 Management..................................49 Administration........................................
- Page 4 Appendix C – CE Interference Statement..........................67...
-
Page 5: Revision History
Revision History Version Date Notes 2012/08/14 First Release... -
Page 6: Introduction
The ERA150 delivers up to 3x faster wireless speeds and 7x extended coverage than legacy 802.11b/g wireless devices. Even though the ERA150 has been designed and engineered for traffic heavy and demanding business environments it is also quite at home in larger house scenarios because it efficiently extends the wireless range of an existing home router, especially in very architecturally-challenging structures to provide whole home connectivity. -
Page 7: Features And Benefits
(Ethernet cable) where a power outlet may not be available. Save User Settings Firmware upgrade does not delete user settings. SNMP Remote Configuration Management Allows remote connection to configure or manage the ERA150 easily. QoS (WMM) support Enhanced user performance and density. -
Page 8: Package Contents
1.2 Package Contents The ERA150 package contains the following items (all items must be in package to issue a refund): ERA150 Access Point Detachable 5dBi antenna * 1 12V/1A 100V~240V Power Adapter RJ-45 Ethernet Cable Wall Mount Screw Kit Wiring Belt * 2... - Page 9 SOHO users need a cost-effective, easy and quick installation of a small network. f) Wireless Extensions to Ethernet Networks Devices like the ERA150 enable network administrators, installers and end-users to extend the range and reach of an existing Ethernet-based network.
-
Page 10: Before You Begin
These could be the number, thickness, and location of walls, ceilings, or other objects that the ERA150’s wireless signals must pass through. Here are some key guidelines to allow the ERA150 to have optimal wireless range. -
Page 11: Computer Settings (Windows Xp/Windows 7)
2.2 Computer Settings (Windows XP/Windows 7) In order to use the ERA150, you must first configure the TCP/IPv4 connection of your Windows OS computer system. Click Start button and open Control Panel. Windows XP Windows 7... - Page 12 In Windows XP, click Network Connections In Windows 7, click View Network Status and Tasks in the Network and Internet section, then select Change adapter settings Right click on Local Area Connection and select Properties...
- Page 13 Properties Select Use the following IP address and enter an IP address that is different from the ERA150 and subnet mask then click OK. Note: Ensure that the IP address and subnet mask are on the same subnet as the device.
-
Page 14: Computer Settings In Apple Mac X Os
Highlight Ethernet In Configure IPv4, select Manually Enter an IP address that is different from the ERA150 and subnet mask then press OK Note: Ensure that the IP address and subnet mask are on the same subnet as the device. -
Page 15: Hardware Installation
1. Ensure that the computer in use has an Ethernet Card (RJ-45 Ethernet Port). For more information, verify User Manual. 2. Connect one end of the Category 5e Ethernet cable into RJ-45 port of the ERA150 and the other end to the RJ-45 port on the computer that will use the ERA150. - Page 16 Top and Front Panel Rear and Bottom Panel...
- Page 17 Top and Front Panel Detachable Antenna External interface for the antenna. Rear and Bottom Panel LED Lights LED lights for Power, LAN1, LAN2, WLAN and Signal Indicator. Reset Button One click for reset the device. Press over 10 seconds for reset to factory default. Ethernet Port Two Ethernet ports for RJ-45 cable.
-
Page 18: Configuring Your Access Point
3 Configuring Your Access Point This section will show you how to configure the device using the web-based configuration interface. 3.1 Default Settings Please use your Ethernet port or wireless network adapter to connect the Access Point. Default Settings IP Address 192.168.1.1 Username / Password admin / admin... -
Page 19: Web Configuration
3.2 Web Configuration Open a web browser (Internet Explorer/Firefox/Safari/Chrome) and enter the IP Address http://192.168.1.1 Note: If you have changed the default LAN IP Address of the Access Point, ensure you enter the correct IP Address. The default username and password are admin. Once you have entered the correct username and password, click the Login button to open the web-base configuration page. - Page 20 If successful, you will be logging in and see the ERA150 User Menu.
-
Page 21: Building A Wireless Network
In Access Point Mode, ERA150 behaves likes a central connection for stations or clients that support IEEE 802.11b/g/n networks. The stations and clients must be configured to use the same SSID (Service Set Identifier) and security password to associate with the ERA150. The ERA150 supports up to four SSIDs at the same time for secure guest access. -
Page 22: Repeater Mode
The Repeater mode is used to regenerate or replicate signals from a wireless router or other access point/station that is unable to reach certain areas in a building. When this mode is activated in the ERA150, the ERA150 receives the wireless... -
Page 23: Status
Status The Status section contains the following options: Save/Reload, Main, Wireless Client List, and System Log. The following sections describe these options. 5.1 Save/Reload This page lets you save and apply the settings shown under Unsaved changes list, or cancel the unsaved changes and revert them to the previous settings that were in effect. -
Page 24: Main
5.2 Main Clicking the Main link under the Status menu or clicking Home at the top-right of the ERA150 Page shows the status information about the current operating mode. - The System Information section shows general system information such as Device Name, MAC Address, Current Time, Firmware Version, and Management VLAN ID (Note: VLAN ID is only applicable in Access Point mode). - Page 25 - The Current Wireless Settings section shows wireless information such as Operating Mode, Frequency, and Channel. Since the ERA150 supports multiple-SSIDs, information about each SSID, the ESSID and security settings, are displayed (Note: Profile Settings is only applicable in Access Point mode).
-
Page 26: Wireless Client List
5.3 Wireless Client List Clicking the Wireless Client List link under the Status menu displays the list of clients associated to the ERA150, along with the MAC addresses and signal strength for each client. Clicking Kick can kick and ban this client. Clicking Refresh... -
Page 27: Connection Status
5.4 Connection Status Click on the Connection Status link under the Status menu. This page displays the current status of the Network, including Network Type, SSID, BSSID, Connection Status, Wireless Mode, Current Channel, Security, Data Rate, Noise Level, and Signal Strength. You can specify the time of refresh duration. Note: Only applicable in Repeater mode. -
Page 28: System Log
5.5 System Log The ERA150 automatically logs (records) events of possible interest in its internal memory. To view the logged information, click the System Log link under the Status menu. If there is not enough internal memory to log all events, older events are deleted from the log. -
Page 29: System
6 System 6.1 Operation Mode The ERA150 supports 2 operating modes: Access Point and Repeater. System Properties Device Name Enter a name for the device. The name you type appears in SNMP management. This name is not the SSID and is not broadcast to other devices. -
Page 30: Ip Settings
6.2 IP Settings This page allows you to modify the device's IP settings. IP Settings IP Network Setting Select whether the device IP address will use the static IP address specified in the IP Address field or be obtained automatically when the device connects to a DHCP server. IP Address The IP Address of this device. -
Page 31: Spanning Tree Setting
6.3 Spanning Tree Setting This page allows you to modify the Spanning Tree settings. Enabling Spanning Tree protocol will prevent network loops in your LAN network. Spanning Tree Spanning Tree Status Enable or disable the Spanning Tree function. Bridge Hello Time Specify Bridge Hello Time, in seconds. -
Page 32: Wireless
7 Wireless 7.1 Wireless Network This page displays the current status of the Wireless settings of the ERA150. Access Point:... - Page 33 Wireless Network (Access Point mode) Wireless Mode Wireless mode supports 802.11b/g/n mixed mode. Channel HT Mode The default channel bandwidth is 20/40MHz. The larger the channel, the better the transmission quality and speed. Extension Channel Select upper or lower channel. Your selection may affect the Auto channel function. Channel / Frequency Select the channel and frequency appropriate for your country’s regulation.
- Page 34 SSID Profile SSID Profile SSID Specify the SSID for the current profile. VLAN ID Specify the VLAN tag for the current profile. Suppressed SSID Check this option to hide the SSID from clients. If checked, the SSID will not appear in the site survey.
- Page 35 Repeater mode: Wireless Network (Repeater mode) Wireless Mode Wireless mode supports 802.11b/g/n mixed mode. SSID The SSID is a unique named shared amongst all the points of the wireless network. The SSID must be identical on all points of the wireless network and cannot exceed 32 characters. You may specify an SSID or select one from the Site Survey.
- Page 36 Preferred BSSID Specify the BSSID (Access Point’s MAC Address). Wireless Security The encryption is using. It must the same as Access Point’s encryption. Accept / Cancel Click Accept to confirm the changes or Cancel to cancel and return previous settings.
-
Page 37: Wireless Security
7.2 Wireless Security The Wireless Security section lets you configure the ERA150's security modes: WEP, WPA-PSK, WPA2-PSK, WPA-PSK Mixed, WPA, WPA2, and WPA Mixed. It is strongly recommend to use WPA2-PSK. WEP Encryption: WEP Encryption Auth Type Select Open System or Shared Key. - Page 38 Key; the other Keys are for decryption only. You must enter a Key Value for the Default Key. Encryption Key # Enter the key value or values you wish to use. Only the Key selected as Default is required. The others are optional.
- Page 39 WPA Encryption: Only in Access Point mode WPA Encryption Encryption Select the WPA encryption type you would like. Please ensure that your wireless clients use the same settings. Radius Server Enter the IP address of the Radius server. Radius Port Enter the port number used for connections to the Radius server.
- Page 40 Radius Accounting Port Enter the port number used for connections to the Radius accounting server. Radius Accounting Secret Enter the secret required to connect to the Radius accounting server. Interim Accounting Interval Specify how often, in seconds, the accounting data sends. Note: 802.11n does not allow WEP/WPA-PSK TKIP/WPA2-PSK TKIP security mode.
-
Page 41: Site Survey
7.3 Site Survey Use this feature to scan nearby Access Points. Note: Only applicable in Repeater modes. 1. Click Site Survey. - Page 42 2. Scanning the nearby Access Points 3. The ERA150 will list the available access points after site survey.
- Page 43 Site Survey (Repeater mode) BSSID Access Point's wireless MAC address. SSID SSID that the Access Point is broadcasting. Channel Channel that the Access Point is using. Signal Level (dBm) Signal strength from the Access Point to your station. Type The band that the Access Point is using. Security Encryption method that the Access Point is using to secure data over the WLAN.
- Page 44 5. Enter the correct security setting.
-
Page 45: Wireless Mac Filter
Wireless MAC Filters are used to allow or deny network access to wireless clients according to their MAC addresses. You can manually add a MAC address to restrict the permission to access ERA150. The default setting is Disable Wireless MAC Filter. -
Page 46: Wireless Advanced
7.5 Wireless Advanced This page allows you to configure wireless advance settings. It is recommended that the default settings are used unless the user has experience with more advanced networking features. - Page 47 Wireless Advanced Data Rate Select a data rate from the drop-down list. The data rate affects throughput of data in the ERA150. The lower the data rate, the throughput will be lower, but so will the transmission distance. Transmit Power Set the power output of the wireless signal.
-
Page 48: Wps (Wi-Fi Protected Setup)
7.6 WPS (Wi-Fi Protected Setup) Wi-Fi Protected Setup (WPS) feature is following the Wi-Fi Alliance WPS standard and it eases the set up of security- enabled Wi-Fi networks in the home and small office environment. It reduces the user steps required to configure a network and supports two methods that are familiar to most consumers to configure a network and enable security. - Page 49 Wi-Fi Protected Setup (WPS) Select to Enable or Disable the WPS feature. WPS Current Status Shows whether the WPS function is Configured or unConfigured. When it is Configured, the WPS has been used to authorize connection between the device and wireless clients.
-
Page 50: Management
8.1 Administration This page allows you to change the ERA150 password as well as configure the device by remote access. By default, the username is admin and the password is: admin. The password can contain 0 to 12 alphanumeric characters and is case sensitive. -
Page 51: Management Vlan
Click Accept to confirm the changes or Cancel to cancel and return previous settings. Note: 1. If you reconfigure the Management VLAN ID, you may lose your connection to the ERA150. Verify that the DHCP server supports the reconfigured VLAN ID and then reconnect to the ERA150 using the new IP address. -
Page 52: Snmp Settings
8.3 SNMP Settings This page allows you to assign the Contact Details, Location, Community Name, and Trap Settings for Simple Network Management Protocol (SNMP). This is a networking management protocol used to monitor network attached devices. SNMP allows messages (called protocol data units) to be sent to various parts of the network. Upon receiving these messages, SNMP compatible devices (called agents) return the data stored in their Management Information Bases. - Page 53 SNMP SNMP Enable/Disable Enable or Disable SNMP feature. Contact Specify the contact details of the device Location Specify the location of the device. Community Name (Read Only) Specify the password for the SNMP community for read only access. Community Name Specify the password for the SNMP community with read/write access.
-
Page 54: Backup/Restore
If extreme problems occur, or Restore Saved Settings from A File if the you have set the ERA150 wrongly, you can use the Factory Default button in the Revert to Factory Default Settings section to restore all the configurations of the ERA150 to the original default settings. -
Page 55: Auto Reboot Settings
Enable or disable the auto reboot function. Frequency of Auto Reboot To specify the time to reboot the ERA150 by Min, Hour, Day or Week. Save/Apply / Cancel Click Save/Apply to apply the changes or Cancel to return previous settings. -
Page 56: Firmware Upgrade
8.6 Firmware Upgrade This page allows you to upgrade the firmware of the ERA150. To perform the Firmware Upgrade: 1. Click the Browse button and navigate the OS File System to the location of the upgrade file. 2. Select the upgrade file. The name of the file will appear in the Upgrade File field. -
Page 57: Time Setting
8.7 Time Setting This page allows you to set the internal clock of the ERA150. Time Manually Set Date and Time Manually specify the date and time. Automatically Get Date and Select a time zone from the drop-down list and check whether you want to enter the IP... -
Page 58: Wifi Schedule
8.8 Wifi Schedule This page allows you to setup Wifi Schedule function of the ERA150. You can set a schedule when the ERA150’s Wireless is on or off. Note: Only applicable in Access Point mode. - Page 59 Wifi Schedule Wifi Schedule Select to Enable or Disable the Wifi schedule feature. Default is Disable. Schedule Name Assign a name to the schedule. Service The service (Wireless Power ON /OFF) provided for the schedule. Select which day the Wifi schedule will be active. Time of day Set what time of the selected day the Wifi schedule will be active.
-
Page 60: Cli Setting
8.9 CLI Setting This page allows you to setup CLI (Command Line Interface) function of the ERA150. -
Page 61: Log
8.10 Log This page allows you to setup Syslog and local log functions of the ERA150. Syslog Enable or disable the syslog function. Log Server IP Address Enter the IP address of the log server. Local Log Enable or disable the local log service. -
Page 62: Diagnostics
8.11 Diagnostics This page allows you to analyze the connection quality of the ERA150 and trace the routing table to a target in the network. Diagnositics Target IP Enter the IP address you would like to search. Ping Packet Size Enter the packet size of each ping. -
Page 63: Logout
8.12 Logout Click Logout in the Management menu to logout of the ERA150 interface. -
Page 64: Reset
8.13 Reset In some circumstances, it may be required to force the device to reboot. Click on Reboot the Device to reboot the ERA150. -
Page 65: Appendix A - Fcc Interference Statement
Appendix A – FCC Interference Statement Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. -
Page 66: Appendix B - Ic Interference Statement
Appendix B – IC Interference Statement Industry Canada statement: This device complies with RSS-210 of the Industry Canada Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Ce dispositif est conforme à... - Page 67 maximal (ou inférieur) approuvé pourl'émetteur par Industrie Canada. Dans le but de réduire les risques de brouillage radioélectriqueà l'intention des autres utilisateurs, il faut choisir le type d'antenne et son gain de sorte que lapuissance isotrope rayonnée équivalente (p.i.r.e.) ne dépasse pas l'intensité...
- Page 68 Appendix C – CE Interference Statement Europe – EU Declaration of Conformity This device complies with the essential requirements of the R&TTE Directive 1999/5/EC. The following test methods have been applied in order to prove presumption of conformity with the essential requirements of the R&TTE Directive 1999/5/EC: EN60950-1 Safety of Information Technology Equipment EN50385...
- Page 69 This device may not be used for setting up outdoor radio links in France and in some areas the RF output power may be limited to 10 mW EIRP in the frequency range of 2454 – 2483.5 MHz. For detailed information the end-user should contact the national spectrum authority in France. 0560 Česky [Czech] [Jméno výrobce] tímto prohlašuje, že tento [typ zařízení] je ve shodě...
- Page 70 Latviski [Latvian] Ar šo [name of manufacturer / izgatavotāja nosaukums] deklarē, ka [type of equipment / iekārtas tips] atbilst Direktīvas 1999/5/EK būtiskajām prasībām un citiem ar to saistītajiem noteikumiem. Lietuvių [Lithuanian] Šiuo [manufacturer name] deklaruoja, kad šis [equipment type] atitinka esminius reikalavimus ir kitas 1999/5/EB Direktyvos nuostatas.
