A64IMCA1/ AUS
English
GB
Operating Instructions
COOKER AND OVEN
Contents
Operating Instructions,1
Warnings,1
Description of the appliance-Overall view,2
Description of the appliance-Control Panel,2
Installation,3
Start-up and use,5
Cooking modes,6
Using the hob,9
Precautions and tips,14
Care and maintenance,16
Assistance,18
Warnings
GB
WARNING: The appliance and its
accessible parts become hot during use.
Care should be taken to avoid touching
heating elements.
Children less than 8 years of age shall be
kept away unless continuously supervised.
This appliance can be used by children
aged from 8 years and above and
persons with reduced physical, sensory or
mental capabilities or lack of experience
and knowledge if they have been given
supervision or instruction concerning
use of the appliance in a safe way and
understand the hazards involved. Children
shall not play with the appliance. Cleaning
and user maintenance shall not be made
by children without supervision.
WARNING: Unattended cooking on a hob
with fat or oil can be dangerous and may
result in fi re.
NEVER try to extinguish a fi re with water,
but switch off the appliance and then cover
fl ame e.g. with a lid or a fi re blanket.
Do not use harsh abrasive cleaners or
sharp metal scrapers to clean the oven
door glass since they can scratch the
surface, which may result in shattering of
the glass.
The internal surfaces of the compartment
(where present) may become hot.
Keep children away from the appliance
during the automatic cleaning cycle as
surfaces may become very hot.
Never use steam cleaners or pressure
cleaner s on the appliance.
Do not place metal objects (knives,
spoons, pan lids, etc.) on the hob as they
may become hot.
Remove any liquid from the lid before
opening it.
Do not close the glass cover (if present)
when the gas burners or electric hotplates
are still hot.
After use, switch off the hob element by its
control and do not rely on the pan detector.
WARNING: Ensure that the appliance is
switched off before replacing the lamp to
avoid the possibility of electric shock.
! When you place the rack inside, make sure
that the stop is directed upwards and in the
back of the cavity .
Advertisement
Table of Contents
Related Manuals for Ariston A64IMCA1
Summary of Contents for Ariston A64IMCA1
- Page 1 A64IMCA1/ AUS Warnings English WARNING: The appliance and its accessible parts become hot during use. Care should be taken to avoid touching Operating Instructions heating elements. COOKER AND OVEN Children less than 8 years of age shall be kept away unless continuously supervised.
- Page 2 Description of the appliance DISPLAY 1. LOW TEMPERATURE MODE icon 2. AUTOMATIC COOKING MODE icons 3. Indicator Preheating 4. indicator DOOR LOCK Description of the appliance 5. icon STOP 6. icon DURATION Overall view 7. icon END OF COOKING 8. icon TIMER 1.Glass ceramic hob 9.
-
Page 3: Electrical Connection
Installation ! Please keep this instruction booklet in a safe place for Levelling If it is necessary to level the future reference.. Make sure the booklet remains with appliance, screw the adjustable the appliance if it is sold, given away or moved. feet into the positions provided on each corner of the base of ! Please read this manual carefully: it contains... - Page 4 Safety Chain -breaker with a minimum opening of 3 mm between the con- ! In order to prevent ac- tacts, suitable for the load indicated and complying with cur- cidental tipping of the rent directives, must be installed between the appliance and appliance, for example by the mains (the earthing wire must not be interrupted by the a child climbing onto the...
- Page 5 Start-up and use Setting the clock a buzzer sounds the preheating process is complete: you may now place the food in the oven. 4. During cooking it is always possible to: ! The clock may be set when the oven is switched off - Change the cooking mode by turning the SELECTOR or when it is switched on, provided that the end time of knob.
- Page 6 Manual cooking modes Automatic cooking modes ! All cooking modes have a default cooking temperature which may be adjusted manually to a value between 40°C ! The temperature and cooking duration are pre- and 250°C as desired. In the SPIT ROAST mode, the default set values, guaranteeing a perfect result every time power level value is 270°C.
-
Page 7: Practical Cooking Advice
sounds. • For example: it is 9:00 a.m. and a time of 1 hour and Recipe for BREAD: 15 minutes is programmed. The programme will stop 1 Dripping pan weighing 1000 g max placed on a low shelf automatically at 10:15 a.m. level Setting the end time for a cooking mode ! A cooking duration must be set before the cooking end time... - Page 8 WARNING! The oven is provided with a stop sys- tem to extract the racks and prevent them from coming out of the oven. (1) As shown in the drawing, to extract them completely, simply lift the racks, holding them on the front part, and pull (2). Co ok in g Foods We ig ht...
- Page 9 Start-up and use Description of the appliance Start-up and use Control panel Before connecting the appliance to the power supply, make sure that: • The appliance is earthed and the plug is com- pliant with the law. • The socket can withstand the maximum power of the appliance, which is indicated on the data plate located on the appliance itself.
- Page 10 • Loud whistle: heard when two induction ele- After connecting the hob to the electricity mains, the to- ments of the same group function simultaneously at ma- uch pannel might be automatically locked. To unclock ximum power and/or when the booster function is set on the pannel press and hold the Control Panel the larger element while the other is auto-adjusted.
- Page 11 Switching on the cooking zones 1. Select the cooking zone using the corresponding selector button. Each cooking zone is controlled using a selector button and a power adjustment device consisting of a double(-) and (+) button. corresponding control button and set the desired power level (between 0 and 9) using the buttons (-) or (+) Press and hold the (-) button to set the power level...
-
Page 12: Safety Devices
Switching off the hob Press the button to switch off the appliance - do not rely solely on the pan sensor. If the control panel lock has been activated, the controls will continue to be locked even after the hob is switched beep signal is emmited. - Page 13 Hobs Power level Maximum operating time in hours Cooking zone Power (W) Back Left I 1200 - B1600 Back Right I 1500 - B 2000 Front Left I 1500 - B 2000 Front Right I 1200 - B1600 Total power 7200 ª...
-
Page 14: Precautions And Tips
Precautions and tips ! This appliance has been designed and • When unplugging the appliance, always pull the plug from the mains socket; do not pull on the cable. manufactured in compliance with international safety standards. The following warnings are provided for •... - Page 15 Respecting and conserving the • For the attention of wearers of pacemakers or other environment active implants: The hob complies with all current standards on • You can help to reduce the peak load of the electromagnetic interference. electricity supply network companies by using Your induction hob is therefore perfectly in keeping the oven in the hours between late afternoon and with legal requirements (89/336/CEE directives).
-
Page 16: Care And Maintenance
Care and maintenance Switching the appliance off Disconnect your appliance from the electricity supply Cleaning the glass ceramic hob before carrying out any work on it. ! Do not use abrasive or corrosive detergents (for example, products in spray cans for cleaning barbecues Cleaning the oven and ovens), stain removers, anti-rust products, powder ! Never use steam cleaners or pressure cleaners on... - Page 17 Removing and fitting the oven door: WARNING! Oven must not be operated with inner 1.Open the door door glass removed! 2.Make the hinge clamps of the oven door WARNING! When reassembling the inner door rotate glass insert the glass panel correctly so that the backwards completely (see photo) text written on the panel is not reversed and can be easily legible.
- Page 18 ARISTON PRIORITY SERVICE If you are not completely satisfied with your appliance or require service call: Australia Phone: 1300 815 589 New Zealand Phone: (09) 306 1020 GENUINE ACCESSORIES & SPARE PARTS A wide range of genuine accessories are available for...
- Page 20 08/2013- 195116249.00 XEROX FABRIANO...
