MICROWAVE OVEN

USER'S MANUAL
PMD 20 BiX

Advertisement

Table of Contents
loading

Related Manuals for Philco PMD 20 BIX

Summary of Contents for Philco PMD 20 BIX

  • Page 1: Microwave Oven

    MICROWAVE OVEN USER'S MANUAL PMD 20 BiX...
  • Page 2 Dear customer, Thank you for buying a PHILCO brand product. So that your appliance serves you well, please read all the instructions in this user's manual.

  • Page 3: Table Of Contents

    CONTENTS PART 1: SAFETY PRECAUTIONS ........................2 • Important safety instructions ..............................2 • Radio wave interference ................................4 • Grounding instructions ................................4 PART 2: DESCRIPTION OF THE APPLIANCE ....................5 PART 3: INSTALLATION ............................ 6 • Built-in installation ..................................6 PART 4: THE BASICS OF COOKING IN A MICROWAVE OVEN ................. 9 •...

  • Page 4: Part 1: Safety Precautions

    PART 1: SAFETY PRECAUTIONS Recommendation: Carefully read these instructions before installing and operating this microwave oven. Write down the serial number found on the rating label of the oven in the space below. It is essential that you store this user's manual in a safe place so that you can use it in the future.
  • Page 5 • Read all the instructions before using this appliance. • Only use the appliance for the purposes for which it was designed and in the manner described in this user's manual. This oven is designed only to heat, cook or dry food. It is not designed for industrial or laboratory purposes.

  • Page 6: Radio Wave Interference

    Radio wave interference The use of the oven may cause interference to a radio, television or similar receivers. If interference occurs, it may be limited by the following measures: keeping the door and the surface of the oven seals clean; redirecting the radio or television signal reception antenna;...

  • Page 7: Part 2: Description Of The Appliance

    PART 2: DESCRIPTION OF THE APPLIANCE Ventilation openings Rotating glass plate – made from special fi re-resistant glass. Always ensure that the plate is correctly seated in the oven before operating it. Do not use the oven without the glass plate inserted. Control panel Safety door closing system –...

  • Page 8: Part 3: Installation

    PART 3: INSTALLATION Make sure that you have removed all packaging materials and advertising labels from inside the appliance. WARNING: Check that the microwave oven is not damaged and that the door and the locks fi t well, that the gasket seal is not damaged, that the hinges and locks are not destroyed or loosened and that the inside area is in order.
  • Page 9 Dimensions Dimensions of the appliance: 350 mm (d) x 580 mm (w) x 365 mm (h) Dimensions of the frame: 20 mm (d) x 592 mm (w) x 376 mm (h) The above dimensions must be adhered to. At the same time these are the minimum dimensions. Check that the load bearing capacity of the cabinet inside which the appliance will be installed corresponds to the weight of the appliance.
  • Page 10 NOTE: The template should be fl ush with the left, right and front edge. Insert the microwave into the installation location. Check that the distance on the right and left side is the same and that the stopper is in the back part. After placement, open the oven door and in the front part of the interior of the oven there is a hole for the locking screw (4 x 35 mm).

  • Page 11: Part 4: The Basics Of Cooking In A Microwave Oven

    PART 4: THE BASICS OF COOKING IN A MICROWAVE OVEN Carefully organise the food. Place the largest food pieces towards the centre of the plate. Set the correct cooking time. Use short time periods for cooking, if necessary extend them. When cooking food at high temperatures smoke may be created or a fi re may start.

  • Page 12: Part 5: Control Panel

    PART 5: CONTROL PANEL Control panel 1. MICRO / GRILL button 2. AUTO MENU button 3. TIME / WEIGHT button 4. CLOCK / TIMER button 5. Display 6. START / RESET button EN - 10 Copyright © 2012, Fast ČR, a. s. 09/2012...

  • Page 13: Part 6: Operating Instructions For The Microwave Oven

    PART 6: OPERATING INSTRUCTIONS FOR THE MICROWAVE OVEN General use Connect the power plug to a power socket with a rating of 230 V ~ 50 Hz. Place the food into a container suitable for use in a microwave oven, open the door. Check that the guide and the rotating plate are correctly installed.

  • Page 14: Defrosting

    Microwave cooking power table Number of presses Approximate value in % Power level (shown on the display) P100 Defrosting The defrosting function is used to defrost various types of food. The maximum weight is 2 kg. Example: you want to defrost 0.4 kg of frozen food. Repeatedly press the MICRO/GRILL button to set "dEF"...

  • Page 15: Child Safety Lock

    NOTE: If you select only grilling, the grilling process will be automatically interrupted, two sounds will be made, informing you to turn the food over. Turn the food over, close the door and press the START/RESET button. The cooking process will resume. If you do not perform any operation within 1 minute, the cooking process will resume automatically.

  • Page 16: Part 7: Maintenance And Cleaning

    PART 7: MAINTENANCE AND CLEANING Turn off the microwave oven and disconnect from the power socket before performing regular or exceptional maintenance. Keep the inside area clean. If the walls of the microwave oven are splattered with food juices then wipe them away using a damp cloth.

  • Page 17: Part 8: Before You Call The Service Centre

    PART 8: BEFORE YOU CALL THE SERVICE CENTRE If the oven is not working properly: Check that the microwave oven is correctly connected to the power socket. If not, take the power plug out of the power socket, wait 10 seconds and then reinsert it. Check whether a fuse has burned or a circuit breaker has been disconnected.

  • Page 18: Part 9: Technical Specifications

    PART 9: TECHNICAL SPECIFICATIONS Nominal voltage range 230 V Nominal frequency 50 Hz Rated power input 1080 W Microwave power output 700 W Grill 800 W Operating frequency 2,450 MHz Noise level 48/53 dB (A) (at start up) Volume 20 l External dimensions (h x w x d) 376 x 592 x 313 mm Internal dimensions (h x w x d)
  • Page 19 INSTRUCTIONS AND INFORMATION REGARDING THE DISPOSAL OF USED PACKAGING MATERIALS Dispose of packaging material at a public waste disposal site. DISPOSAL OF USED ELECTRICAL AND ELECTRONIC APPLIANCES The meaning of the symbol on the product, its accessory or packaging indicates that this product shall not be treated as household waste.
