ASSEMBLY AND OPERATION INSTRUCTIONS
TABLE TOP FLAME HEATER
FOR OUTDFOOR USE ONLY | USES PROPANE LPG ONLY
PLEASE READ INSTRUCTIONS CAREFULLY BEFORE ASSEMBLY
Read this instruction before using this
appliance. The appliance must be installed
in accordance with the instructions and
local regulations. The use of this appliance
in enclosed areas can be dangerous and is
PROHIBITED
• Do the leak test after each changing LPG
cylinder.
• Never check for leaks with a match or open
• Do not store or use gasoline or other
this appliance.
• Close the valve of the gas cylinder or
regulator.
• Extinguish all naked flames; do not operate
any electrical appliances.
• Check for leaks as detailed in this instructions.
• If odor persists, contact your dealer or gas
supplier immediately.
For cus tomer service, parts
or warranty issues:
Call 1-800-561-5550
or e-mail customercare@jrhome.com
RETAIN THIS MANUAL FOR REFERENCE
Item Number: PH-T-113
Model Number: PH05-S/PH05-SS
WARNING
IF YOU SMELL GAS

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PH05-S and is the answer not in the manual?

Questions and answers

Related Manuals for Paramount Fitness PH05-S

Summary of Contents for Paramount Fitness PH05-S

  • Page 1 Item Number: PH-T-113 Model Number: PH05-S/PH05-SS ASSEMBLY AND OPERATION INSTRUCTIONS TABLE TOP FLAME HEATER WARNING Read this instruction before using this appliance. The appliance must be installed in accordance with the instructions and local regulations. The use of this appliance...

  • Page 2: Carbon Monoxide Hazard

    DANGER CARBON MONOXIDE HAZARD • This appliance can produce carbon monoxide which has no odor. • Using it in an enclosed space can kill you. • Never use this appliance in a enclosed space such as a camper, tent, car or home. •...
  • Page 3 PRECAUTIONS • Installation and services should only be a qualified person. • Do not use the heater in an explosive atmosphere. • Before to use, check the hose. • Disconnect LPG cylinder before moving the heater. • Do not attempt to alter any parts of the heater. Example: Using the heater without reflector or protection guard.
  • Page 4 • Young children should be carefully supervised when they are in the working area of the heater. • Clothing or other flammable material should not be hung from the heater, or placed on or near the heater. • Do not obstruct the flow of combustion products. •...
  • Page 5 APPLIANCE STAND AND LOACTION - The appliance is for outdoor use only. Do not use it for indoor or in an enclosed area. - Always maintain proper clearance from combustible materials, i.e. top 800mm and sides 650mm minimum. DIAGRAMMATICAL REPRESENTATIONS OF OUTDOOR AREAS - 5 -...

  • Page 6: Leakage Test

    LEAKAGE TEST Gas connections on the appliance are leak tested at the factory prior to shipment. Possible mishandling of the appliance during the shipment might contribute to product integrity as a whole. A complete gas leakage test must be performed again at the installation site. Please follow the procedure below for leakage test.

  • Page 7: Parts List

    PARTS LIST-1 Part NO. Part Name Picture Remarks Bottom Plate Preassembled in Control Box the Middle plate Middle Plate Support Upper Plate Preassembled in Plate cover the Middle plate Glass tube Preassembled in Damper upper plate Reflector - 7 -...
  • Page 8 PARTS LIST-2 Part NO. Part Name Picture Remarks Connect with Two side bolts damper and reflector Hook Mesh Guard Guard Fastening Pieces Side panel A chain is Front panel preassembled in this panel All preassembled Screw M4 in relative parts Knob Preassembled in Nuts...

  • Page 9: Heater Assembly

    INJECTOR HEATER ASSEMBLY Tools Required: 1 Phillips head screwdriver, 1 adjustable spanner 1. Remove the protective paperboard off the 2. Using wing nuts to firm the reflector top of glass tube completely. Assemble the reflector into the frame parts using two-side bolts, then use the nuts to firm the top.

  • Page 10: Operation

    OPERATION Preparation: You will need to purchase a 1 pound propane cylinder before you start to use. Connect the cylinder with the inner regulator Warning: Always test the connection place leaks with soapy water. Any guard or protective device removed for servicing the heater must be replaced prior to operation.

  • Page 11: Cleaning/Maintenance/Storage

    CLEANING/MAINTENANCE/STORAGE CLEANING AND MAINTENANCE: ● To enjoy outstanding performance of your heater for years make sure to perform the following maintenance activities on a regular basis: ● Keep exterior surfaces clean. -Use warm soapy water for cleaning. Never use flammable, corrosive or abrasive cleaners.

  • Page 12: Troubleshooting

    Troubleshooting PROBLEM PROBABLE CAUSE SOLUTION Pilot will not light Gas valve may be OFF Turn the gas valve ON Fuel Tank empty Refill LP gas tank Orifice blocked Clean or replace Orifice Air in supply system Purge air from lines Loose connection Check all fittings Pilot will not stay on...
  • Page 13 IMPORTANT For questions, concerns or problems with our product please email our customer service department: customercare@jrhome.com or call 1-800-561-5550. DATED PROOF OF PURCHASE REQUIRED FOR WARRANTY SERVICE. WARRANTY This product is inspected, tested and carefully packaged to minimize the chance of damage during shipment.
