Pyramid Flame Heater
Instruction Manual
FOR YOUR SAFETY:
If you smell gas:
Shut off gas to the appliance.
If Odour continues, keep away from
the appliance and immediately call your
gas
DANGER indicates an imminently
hazardous situation which, if not avoided,
will result in death or serious injury.
Failure to comply with the precautions
and instructions provided with this heater
can result in death, serious bodily injury
and property loss or damage from
hazards
poisoning. Only persons who can
understand and follow the instructions
should use or service this heater.
This product can expose you to chemicals
including Lead, Chromium (hexavalent
compounds), Di(2-ethylhexyl) phthalate (DEHP)
and Diisononyl phthalate (DINP), which are known
to the State of California to cause cancer and birth
defects or other reproductive harm. For more
information, go to www.P65Warnings.ca.gov.
(8
)
– Friday
@
and/or carbon monoxide
a.m. – p.m., ST
KLD7001S, KLD7001SS
Item#:
Model #: PH100141
Do not store or use gasoline or other
vicinity of this or any other appliance.
An LP-cylinder not connected for use
shall not be stored in the vicinity of this
or any other appliance.
Improper installation, adjustment,
alteration, service or maintenance can
cause property damage, injury or death.
Read the installation, operation and
maintenance instructions thoroughly
before installing or servicing this
FOR OUTDOOR USE ONLY!
Electronic ignition.
+
Requires (1) AA Battery.
.
_
(Not Included)
Keep a copy of your proof of
which will be needed if you need
to contact us about warranty
coverage.
Serial No.
Purchase Date
Advertisement
Table of Contents
Related Manuals for Paramount Fitness PH100141
Summary of Contents for Paramount Fitness PH100141
- Page 1 Pyramid Flame Heater KLD7001S, KLD7001SS Item#: Instruction Manual Model #: PH100141 FOR YOUR SAFETY: Do not store or use gasoline or other If you smell gas: Shut off gas to the appliance. vicinity of this or any other appliance. An LP-cylinder not connected for use...
-
Page 2: Before You Begin
BEFORE YOU BEGIN 6-11 12-15 Patio Heater. NOTE: Electronic ignition. Requires 1 (AA) battery. (Not Included) -
Page 3: Safety Information
SAFETY INFORMATION CAUTION indicates an imminently EXPLOSION—FIRE HAZARD CARBON MONOXIDE HAZARD • Keep solid combustibles, such as building hazardous situation which, if not avoided, • This heater is a combustion appliance. materials, paper, or cardboard a safe may result in minor or moderate personal All combustion appliances produce carbon distance away from the heater as injury, or property damage. -
Page 4: Package Contents
PACKAGE CONTENTS Reflector Flame Screen Glass Tube Upper Support Inner Emitter Protective Guard Black Silicone Ring iddle Plate Control Box Assy Lower Support Side Panel Block Belt Front Panel Wheel Assembly Gas Hose & Regulator Bottom Plate DESCRIPTION DESCRIPTION QUANTITY PART PART QUANTITY... -
Page 5: Hardware Contents
HARDWARE CONTENTS M5x10 Screw Qty. 44 Big Screw M4 X 8 M5x10 Qty. 4 Washer (Not included) 4 and 5... - Page 6 1. Fix the Wheel Assembly(N) to the Bottom Plate(O) with 4 Bolts (EE) and 4 Flange Nuts(FF) Bolt M6 X 12 M6 Flange nut Wrench Twist off the igniter button cap, load one AA battery(OO) on the right pole. Then place the cap back.
- Page 7 3.Assemble Block Belt. Fix the Block Belt(M) to the 2pcs of lower support opposite to the front door with 2 screws(DD ). M5x10 Screw Philips screwdriver 4 Assemble the Upper Support. Insert the 4pcs Upper Support(D) to the lower support at the right end(with 2 screw holes vertically).
- Page 8 5. Assemble the flame screen. Secure the Flame Screen(B) to the upper support with 8 screw(DD). Hardware Used M5x10 Screw Philips screwdriver 6. Assemble the Reflector. Insert the 3 studs(CC) on the Flame Screen(B). Place 3 washer(BB) onto the stud, then thread it through the Reflector(A). Then secure with 3 wing nuts(AA) and 3 washer(BB) Hardware Used...
- Page 9 Install the Glass Tube(C). a. Insert the Inner emitter (P) into the glass tube, place the black silicone ring onto the end of the glass tube as illustrated. The inner emitter directs heat near the bottom of the glass tube and increases heat lower in the tube for added warmth when sitting.
- Page 10 9. Attach the 3 Side Panel(G) onto the lower support poles with 18 screw(DD). M5x10 Screw x 18 Philips screwdriver 10 Attach the Knob(KK) ,the Chain(MM) and the Washer (NN) onto the Front Panel(H) with 1 screw(LL). Hook the chain onto the the control box assy. and position the pothook of front panel into the holes of bottom plate.
- Page 11 WARNING! Hardware Used...
- Page 12 Hose/ Control Box Assy. Connection 4. Apply several drops of solution where hoses attach to the box assembly 3. The presssure reguulator and the hose assembly supplied with the appliance mjust be used. 4. Complete installation. Replacement pressure regulators and hose assemblies must be manufacturer.
- Page 13 Do not store a spare LP- adjustment of propane gas. Storage of an appliance indoors is permissible only gas cylinder under or near if the cylinder is disconnected and removed from the appliance. A cylinder must this appliance. be stored outdoors in a well-ventilated area out of the reach of children. A disconnected cylinder must have dust caps tightly installed and must not be beyond 80 percent full.
-
Page 16: Care And Maintenance
CARE AND MAINTENANCE... -
Page 17: Troubleshooting
TROUBLESHOOTING... - Page 18 IMPORTANT For questions, concerns or problems with our product please Si vous éprouvez si vous avez des questions ou des email our customer service department: préoccupations, prière de faire parvenir un courriel à notre service à la clientèle customercare@jrhome.com customercare@jrhome.com DATED PROOF OF PURCHASE REQUIRED FOR WARRANTY SERVICE UNE PREUVE D’ACHAT DATÉE EST REQUISE POUR SE PRÉVALOIR DE LA GARANTIE.
