Warranty
To receive after service, have the following ready before you
contact our branches.
1. Name of the product.
2. Model number of the product.
3. The area of problem.
4. Phone number and address at which you can be contacted.
Warranty Card
PRODUCT
MODEL
DATE PURCHASED
WARRANTY PERIOD
AGENCY ADDRESS
KOCOM Warranties the original purchaser of this product as follows.
1) This product is produced under strict quality control and inspection procedures.
2) If this product breaks down during proper use as a result of product defect, KOCOM
will repair it within one year from date of purchase free of charge.
3) The following cases will be subject to charge, even during warranty period:
a. Breakdown during transport, or through careless treatment, by consumer.
b. Breakdown cause by unauthorized repair, or system modification.
c. Breakdown caused by natural disaster or power disorder.
SINCE
1976
KOREA COMMUNICATIONS CO.,LTD
http://www.kocom.com
E-mail : export@kocom.co.kr
This manual is based on the date as shown in the right and specifications are subject to
change without notice for quality improvement
KVL/KEL Series 4wire
10.01
Common Gate Camera
[ KVL-C302i / KVL-C303i / KVL-C304i / KVL-TC306i / KVL-TC308i ]
[ KEL-303 / KEL-306 / KEL-309 / KEL-312 / KEL-T324 ]
■ Automatically opens common gate while communication with house
■ For 4 wire type videophone
■ Keypad backlight function - LED lamp
■ White LED for night detection
■ Camera angle control
■ Conneting upto 32 household
■ Openning function of entrance door using I -button key
■ Function of door release without adaptor
■ Function of two door release type( NO, NC )
I-BUTTON KEY
(option)
www.kocom.com
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for KOCOM KVL-C302i
Summary of Contents for KOCOM KVL-C302i
- Page 1 1) This product is produced under strict quality control and inspection procedures. 2) If this product breaks down during proper use as a result of product defect, KOCOM will repair it within one year from date of purchase free of charge.
- Page 2 Warnings Warnings for disposal Cautions for Safety Do not throw used-up battery into fire places, which may cause fire and explosion. ● Cautions Warnings & Cautions for Safety Cautions for installation For safe use, please stick to the following cautions. Read this cautions carefully and keep it within easy reach of you.
-
Page 3: Cautions For Use
Warnings Warnings Cautions for use Cautions for use Do not install the product at bathroom or at the place near a washing machine, or at other humid places. This product is not for perfect security solution. ● ● It may cause fire or electric shock. Do not handle the equipment with wet hand, which may cause electric shock. -
Page 4: Installation
& household monitor depends on each model as below. 1. White(VIDEO) KVL-C302i : 2 house - 8pin 1pcs. KVL-C303i : 3 house - 8pin 1pcs. & 4pin 1pcs. 2. Red(VOICE) KVL-C304i : 4 house - 8pin 2pcs. -
Page 5: Name Of Each Part
Name of Each Part Button & Wiring Information KVL-TC308i KEL-T324 KVL-TC308i ■ COMMON GATE CAMERA KVL-C302i KVL-C303i KVL-C304i KVL-TC306i KVL-TC308i 2 House 3 House 4 House 6 House 8 House KVL-TC308i Name C-Mic ■ EXTENSION UNIT Camera lens KEL-303 KEL-306... -
Page 6: Wiring Information
Wiring Information Wiring Connection A. Adjust audio : Common gate camera → Monitor audio volume Using a screwdriver, increase(+) or decrease(-) the volume from the Common gate camera to the house : Monitor → Common gate camera audio volume Using a screwdriver, increase(+) or decrease(-) the volume from the house to the Common gate camera B. -
Page 7: Operation Explanation
Operation Explanation I-BUTTON Registration and Deletion ■ Communication with house monitor TACT SWITCH Location ※ 1. When the visitor presses the call button for certain house on the common gate camera, the certain house monitor gets call signal. 2. In case of hanging up the hand-set or pressing talk button, the conversation is available. 3. -
Page 8: Product Specifications
Explanation of I-BUTTON Specification ■ I-BUTTON KEY maximum registration quantity 1. Using EEPROM, maximum up to 1022 are registered. 2. it is impossible to store more than 1022 units and when storage capacity is exceeded, buzzer sound is transmitted for 4 seconds. * The same I-BUTTON KEY can store and motion but maintains the existing DATA.
