5. Install Inside Trim Plate
Fasten Inside Trim Plate using two #8-32 x 3/8" Flat Head Machine Screws (item #4c).
!
Correct for installation
*Unlocked position is required for installation and removal of the Inside
Trim Plate Assembly.
8
!
USER CODES
ARE LOCATED
ON THE INSIDE
TRIM PLATE &
ON PAGE 11.
*Unlocked
Inside
Incorrect for installation
Locked
!
THUMBTURN MUST BE IN
UNLOCKED POSITION FOR
INSTALLATION.
