KitchenAid KCMC155J Dimension Manual

Countertop microwave ovens
Hide thumbs


Advertisement

PRODUCT MODEL NUMBERS
KCMC155J
KCMS145J
KCMS185J
Electrical: A 120-volt, 60-Hz, AC-only, 15- or
20-amp fused electrical supply is required.
(A time-delay fuse is recommended.) It is
recommended that a separate circuit serving
only this appliance be provided.
Because Whirlpool Corporation policy includes a continuous commitment to improve
our products, we reserve the right to change materials and specifications without notice.
®
Countertop Microwave Ovens
OVERALL DIMENSIONS
B
A A
Models
"A"
KCMC155J
14 7/8"
KCMS145J
12 5/8"
KCMS185J
13 9/16"
NOTE: These microwave ovens can be built-in over
approved electric single ovens only using approved
trim kits. See dealer for details.
NOTE: Do not block the exhaust vents or air intake
openings. Allow a few inches of space at the back and
side of the oven where the exhaust vents are located.
Blocking the exhaust vents could cause damage to the
oven and poor cooking results.
Dimensions are for planning purposes only. For complete details, see Installation
Instructions packed with product. Specifications subject to change without notice.
C
"B"
"C"
20"
22 5/8"
17 1/4"
21 7/8"
18 13/16"
23 7/8"
countertop3
01-09-04
