LitterMaid LME5500MR Use & Care Book

Self-cleaning litter box
Hide thumbs

Advertisement

Quick Links

Download this manual
IDEAL FOR EXTRA-LARGE CATS OR MULTIPLE CAT HOUSEHOLDS
Register your product online at www.prodprotect.com/applica,
US /Canada 1-800-LITM ID
www.littermaid.com
ccessories/Parts
(US /Canada)
1-800-738-0245
Please Read and Save this Use and Care Book
for a chance to WIN $100,000!
For US residents only
(548-6243)
Model
❑ LME5500MR

Advertisement

loading
Need help?

Need help?

Do you have a question about the LitterMaid LME5500MR and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for LitterMaid LitterMaid LME5500MR

Summary of Contents for LitterMaid LitterMaid LME5500MR

  • Page 1 IDEAL FOR EXTRA-LARGE CATS OR MULTIPLE CAT HOUSEHOLDS Register your product online at www.prodprotect.com/applica, US /Canada 1-800-LITM ID www.littermaid.com ccessories/Parts (US /Canada) 1-800-738-0245 Please Read and Save this Use and Care Book for a chance to WIN $100,000! For US residents only (548-6243) Model ❑ LME5500MR...

  • Page 2: Import Nt S Fegu Rds

    WELCOME TO THE F MILY! Congratulations on your purchase of the LitterMaid ® dvanced utomatic Self-Cleaning Litter Box. This product is designed to make caring for your cat a simpler, less time-consuming process. OPER TING INSTRUCTIONS FOR THE LITTERM ID ® SELF-CLE NING LITTER BOX • Cat enters the unit; once he/she leaves, the sensors are triggered, setting the timer for the cleaning cycle (sensors need to be blocked for at least 5 seconds). Important: Unit will not start a cleaning cycle while cat is in the box. • s soon as the cat leaves the litter box, the sensors activate the 10-minute countdown and the ionic air cleaner. • The ionic air cleaner stays on during the countdown and the cleaning cycle. • fter the 10-minute countdown, the cleaning cycle starts and the rake scoops out the waste clumps. • If the cat reenters and leaves the litter box before the initial 10 minutes have elapsed, the timer will automatically reset and delay the beginning of the cleaning cycle for an additional 10 minutes. Note: Rake stops and reverses if the safety bar touches any object that has gotten behind the rake while it is returning to its home position. • Rake opens waste receptacle compartment cover and deposits clumps into the waste receptacle. Note: Rake stops and reverses if it encounters an obstacle larger than 35 lb. It will try five times to clear the obstacle. If obstacle is not cleared, the rake reverses back to the home position and the green POWER LED blinks (1 time per second).
  • Page 3 Product may vary slightly from what is illustrated. 1. ON/OFF button. Important: When the On/Off button is in the Off position it only disables the rake function. 2. Timer 3. Warranty board † 4. Battery compartment cover (Part# LME5500MR-01) (batteries not included) 5. Blue LED ionizer light 6. Ionic air cleaner 7. Motor housing † 8. Removable rake (Part# LME5500MR-02) † 9. Litter tray (Part# LME5500MR-03) 10. Sensors (both sides) † 11. Waste receptacle compartment cover with flaps (Part# LME5500MR-04) 12. Receptacle supports Right (Part# LME5500MR-05) and Left (Part# LME5500MR-06) 13. Top housing 14. Plug holes for Plug 2 (1 each side) 15. Cutout handle (1 each side) 16. Plug holes for Plug 1 (1 each side) † Consumer replaceable/removable parts ccessories † 1. Tent plugs type 1 and 2 (4) set (Part# LME5500MR-07) † 2. Cleaning brush (Part# LME5500MR-08) † 3. C adapter (Part# LME5500MR-09) † 4. LitterMaid...
  • Page 4 Timer 1. Green LED POWER indicator light 2. Red LED SLEEP indicator light 3. Digital clock 4. Time/Programming buttons ® Other LitterMaid ccessories Check our online service for parts and accessories at www.littermaid.com or call 1-800-548-6243 LitterMaid Kitty Kabana™ litter box cover (white) LitterMaid Elite™ litter box cover (white) ® LitterMaid litter box carpet ® LitterMaid hard clumping cat litter Disposable waste receptacles (12 pk.) Disposable waste receptacles (18 pk.) Carbon filters (12 pk.) Setup Instructions No Tools Required for Setup • Unpack the pieces of the unit listed below. • Peel off the protective tape on the battery compartment. • Cut or remove the tie restraints on the underside of unit. Before getting started be sure you have all of the following contents. Litter tray Top housing Waste receptacle compartment supports Waste receptacle compartment cover Rake C adapter (packed in styrofoam) Disposable waste receptacles Carbon filters LitterMaid™ triple-action tool...
  • Page 5 ssembly 1. Slide receptacle supports (marked L (left) and R (right)) into grooves on the bottom tray until they lock into place ( ). 2. Place both left and right flaps flat on top of the waste receptacle compartment panel. 3. Push the flaps in and up until they click into place (B). 4. Lift the flaps until they lock into place (C). 5. Snap each pivot of the waste receptacle compartment cover, one at a time, into notches in the receptacle supports (D). 6. Open waste receptacle compartment cover. Important: Waste receptacle compartment cover must be opened to remove and install top housing. 7. Lift top housing. ngle into position bracket end of top housing under tray ledge. Important: 5 black tabs of the tray should be on top of the grey bar in front of the top housing (E). Bring the other end of top housing down so that it snaps into place. Check to be sure top housing is positioned securely on the tray. If positioned correctly, you will not be able to read writing on silver tray ledge. 8. Insert waste receptacles. • Open waste receptacle compartment cover. • Insert a disposable waste receptacle into the waste receptacle compartment. • Insert the edge of the waste receptacle in an inclined position and place it between the edge of the tray and the bar of the top housing (F). • Press the waste receptacle down into position (G). • There should be no gap between the unit and the waste receptacle. • ttach the waste receptacle lid by inserting the push tabs into the round holes. To secure, press on positions indicated (H).
  • Page 6 • ssists in cleaning the rake in case it's needed (N). • ids in the removal of small waste particles (P). 1 1. Install paw cleaning ramp: • The paw-cleaning ramp has two pivot pins that fit into holes on the sides of the waste receptacle compartment cover. • Position the paw-cleaning ramp with carpet-side facing up. • Insert the pivot pins into the holes (Q). • Tug slightly on the ramp to ensure that it is firmly in place. Install rake 1 2. lign tracks on back of rake (each end) and slide into grooves on motor housing (R). 1 3. Remove the C adapter from where it is packed in the styrofoam and plug it into the unit (S). • Plug the cord into a standard electrical wall outlet. • Press the ON/OFF button to turn unit ON. The rake will automatically run through its first cleaning cycle and smooth out the litter. Important: When the On/Off button is in the Off position it only disables the rake function. 14. Place the 4 tent plugs into the 4 holes on top housing. Note: lways use both hands to move LitterMaid ® litter box by holding handle cutouts located on each side of the tray.

  • Page 7: Care And Cleaning

    Helpful Information If you need to acclimate your cat to the LitterMaid ® dvanced utomatic Self-Cleaning litter box, refer to " cclimating Your Cat" in this use and care book. Unit will work without setting the clock when unit is turned on. If your unit is not working properly, refer to "Troubleshooting" in this use and care book. Batteries (We recommend using batteries only as a back-up): • Push up on center ridges to open battery compartment door. • Remove the battery door. • Follow the diagram in the compartment to install 8 (batteries not included). Just as your alarm clock continues to run on batteries if there is a power failure, the LitterMaid ® litter box will continue to operate as long as batteries are installed. Change the batteries periodically. Sensors Sensors (located on interior side panels) must be kept clean. Wipe sensors with a soft, dry cloth to keep them dust free (U). LED operation, function and why they blink: Green on control panel Power LED indicator is lit when power to the unit is on. LED is located on control panel. Blinking green on control panel LED blinks (2 times per second) indicating batteries are low. LED blinks (1 time per second) when the rake assembly has encountered a blockage. Blue on ionizer Ionic air cleaner LED (behind the rake) is only lit when the ionizer is operating. Red on control panel Sleep timer LED is continually lit when sleep mode is activated.

  • Page 8: Troubleshooting

    • Depress the two push tabs in the waste receptacle compartment cover (V) to detach the disposable waste receptacle lid from the waste receptacle compartment cover. • Lift the compartment cover, exposing the closed disposable waste receptacle assembly. • Press in on four corners of lid to secure lid to the waste receptacle, pull up from both sides making sure to hold lid and receptable together; lift out and dispose (W). Disposable waste receptacles are available in packages of 12 or 18 and may be purchased through your local retailer, by visiting us at our website at www.littermaid.com, or by calling us at 1-800-738-0245. We will be happy to assist you in any way we can. Rake Removal & Cleaning Removing the rake: The rake can be removed for easy cleaning. We recommend wearing rubber or latex gloves when handling the soiled rake. • Be sure rake is in the home position and unit is turned off. • Grasp rake ledge underneath logo and slide up and off of unit. • Clean rake with a soft cloth using warm water and mild detergent. Do not use scouring pads or harsh or abrasive chemicals. Spray rake lightly with nonstick cooking spray or a silicone spray before reinstalling. Note: Rake may be cleaned while installed by using the LitterMaid ® triple-action tool. Paw-Cleaning Ramp: The carpet is made of 100% polypropylene and latex foam. To Clean: • Remove mat by gently pulling on the fabric strip provided (X). • The mat is held in place by 5 tabs and will remove easily. • Remove and clean carpet by using a vacuum cleaner.
  • Page 9 Unit does not completely clean litter box. Probable Cause: • Low-quality litter. Solution: 1. Do not use non-clumping, crystal or pearl-like litter. 2. Use only hard clumping litter. Unit does not operate when you press ON/OFF button to turn unit ON. Important: When the On/Off button is in the Off position it only disables the rake function. Probable Cause: • Power outage • Faulty or non-activated outlet • Old batteries Solution: • Check batteries and outlet • Use batteries in case of power outage • Switch to battery power Probable Cause: • Incorrectly installed or dead batteries. Change the batteries once yearly (batteries should only be used as backup). Solution: 1. Press the ON/OFF button OFF. 2. Open battery compartment; check to see that batteries are correctly installed. 3. Press the ON/OFF button ON. The unit should perform a whole cleaning cycle. 4. If unit does not operate, replace batteries with fresh ones and try again. 5. If unit does not operate with fresh batteries, try it with the C adapter. 6. Green light should come on. If it does not, there is a problem with the C adapter or batteries.
  • Page 10 If you can’t solve the problem using this Troubleshooting section, more help is available by calling Customer Service at 1-800-LIT-M ID (548-6243). Power light blinks slowly and continuously. Probable Cause: • Rake has encountered an obstacle it cannot remove. If the rake cannot move an obstacle during the cleaning cycle, the unit will go through a cleaning cycle up to five times in an attempt to clear the obstacle. If unsuccessful, the rake will return to its home position, and the green light will blink slowly (approximately every second), indicating that the rake has encountered an obstacle it cannot move. Solution: 1. Press ON/OFF button OFF. Important: When the On/Off button is in the Off position it only disables the rake function. 2. Use the LitterMaid™ triple-action tool to remove the obstacle. 3. Make sure that the rake teeth are clean and free of litter. Use the LitterMaid ® tool to clean rake teeth. 4. Press ON/OFF button ON. Power light blinks quickly. Probable Cause: • Batteries need replacing. Solution: Light will continue to blink until batteries are removed or until they are completely dead. If SLEEP timer light is off. Solution: 1. Check to be sure clock is set to the correct time. 2. Check to see if the sleep mode is set and activated, see "Programming the Sleep Timer " section. If the rake is stuck in the center or dumping position. Solution: 1. Press ON/OFF button OFF. Important: When the On/Off button is in the Off position it only disables the rake function.

  • Page 11: Need Help

    For service, repair or any questions regarding your appliance, call the appropriate "800" number on the cover of this book. Do not return the product to the place of purchase. Do not mail the product back to the manufacturer nor bring it to a service center. You may also want to consult the website listed on the cover of this manual. Two-Year Limited Warranty ( pplies only in the United States and Canada) What does it cover? • ny defect in material or workmanship; provided; however, pplica’s liability will not exceed the purchase price of the product For how long? • Two years after the date of original purchase What will we do to help you? • Provide you with a reasonably similar replacement product that is either new or factory refurbished How do you get service? • Save your receipt as proof of the date of sale. • Check our on-line service site at www.prodprotect.com/applica, or call our toll-free number, 1-800-548-6243, for general warranty service or If you need parts or accessories, please call 1-800-738-0245. What does your warranty not cover? • Damage from commercial use • Damage from misuse, abuse or neglect • Products that have been modified in any way • Products used or serviced outside the country of purchase • Glass parts and other accessory items that are packed with the unit • Shipping and handling costs associated with the replacement of the unit • Consequential or incidental damages (Please note, however, that some states do not allow the exclusion or limitation of consequential or incidental damages, so this limitation may not apply to you.) How does state law relate to this warranty? • This warranty gives you specific legal rights, and you may also have other rights that vary from state to state or province to province. RM & H MMER ® EVER CLE N...
