Summary of Contents for Currie tech EZIP e4.5

  • Page 2: Table Of Contents

    Safety .................... 13-15 Battery Care ................. 16-19 Battery charging ................19 Maintenance ................. 20-23 Brake adjustment ..............21-23 Troubleshooting ................24-25 Limited Warranty ................. 26-27 Additional Instructions and Warnings ........28-29 e4.5 Owner's Manual.indd, Last Modified: December 28, 2012 10:49 AM...

  • Page 3: Customer Service

    PLeASe Do noT ReTURn THIS SCooTeR To THe SToRe. For questions or assistance on assembly, contact Currie Technologies ® Customer Service toll free at (800) 377-4532 Monday - Friday 8:00 am - 4:00 pm (PST) Retain this manual along with the original sales receipt. Record the product serial number (S/n), place of purchase and date of purchase below.

  • Page 4: Technical Information

    24V 7Ah, SLA 4-6 hours Charging time** *Maximum range and speed varies based on rider weight and terrain **Charge time is based on new batteries charged with a standard charger e4.5 Owner's Manual.indd, Last Modified: December 28, 2012 10:49 AM...

  • Page 5: Scooter Components

    SCooTeR CoMPonenTS “Top cap” Brake lever Handlebar Saddle Throttle Seat mast Steering mast Locking pin Quick release On/Off switch Battery & controller compartments Charger port (underneath deck) (XLR-3 plug type) Chain guard with access door for tire inflation...

  • Page 6: Scooter Assembly

    1. Slide the steering mast onto the scooter frame. Make sure the silver locking pin engages, then close the quick release securely to hold the mast in place. See the next section of this manual for more information on properly tightening quick release clamps. Steering mast Locking pin e4.5 Owner's Manual.indd, Last Modified: December 28, 2012 10:49 AM...
  • Page 7 2. Install the seat mast into the frame. The mast should go all the way down to the base of the scooter, as shown in photo 2a. You may need to twist the mast to work it into position. With the mast fully inserted, twist the saddle so it is facing forward, parallel to the scooter, then tighten the binder bolt as show in photo 2b.

  • Page 8: Tire Inflation

    Inflating your scooter’s tires Both the front and rear tires on the e4.5 are pneumatic, meaning they need to be kept inflated at the proper air pressure to work properly. Just like a car tire, the proper inflation pressure is molded into the sidewall of the tire. Unlike a car, it is best to inflate your scooter’s tires with a hand pump (usually sold for inflating bicycle tires), to avoid overfilling.
  • Page 9 Attention! Before riding your scooter for the first time, you must connect the battery, located under the deck plate...

  • Page 10: Quick Release Levers/Clamps

    Properly adjusting the steering mast quick release clamp Tension adjusting On the E4.5, the steering mast is clamped in place by the force of the quick release cam lever pushing against one side of the clamp and pulling the tension adjusting nut, by way of the skewer, against the other.
  • Page 11 4. If you are able to force the handlebar out of alignment with the front wheel, the clamp needs to be adjusted. Holding the quick release lever in the OPEN position with one hand, tighten the tension adjusting nut with your other hand about 1/2 turn clockwise.

  • Page 12: Scooter Use

    In order to ensure your scooter’s battery lasts as long as possible, you should fully charge the battery after each and every ride. Please see the section of this manual on battery care for more information. e4.5 Owner's Manual.indd, Last Modified: December 28, 2012 10:49 AM...

  • Page 13: Safety

    SAfeTy gUIDeLIneS LIMITATIonS of SAfeTy AnD WARnIng noTICeS This owner’s manual includes important safety guidelines and maintenance instructions. Failure to read, understand and follow the instructions in this manual may lead to serious injury or even death. InSURAnCe noTICe Your insurance policies may not provide coverage for accidents involving the use of this electric scooter.
  • Page 14 Always drive slowly and pay extra attention when operating on unfamiliar terrain. Always be alert to changing terrain conditions when operating this product. Never operate on excessively rough, slippery or loose terrain. e4.5 Owner's Manual.indd, Last Modified: December 28, 2012 10:49 AM...
  • Page 15 Practice turning at low speeds before attempting to turn at faster speeds. Do not turn at excessive speed as this could increase the risk of injury. Always check for obstacles before operating in a new area. Never attempt to operate over large obstacles, such as large rocks or fallen trees.

  • Page 16: Battery Care

    Currie uses SLA (Sealed Lead Acid) batteries in the E4.5 scooter. This is a very user-friendly type of battery when cared for properly.
  • Page 17 • The rated output capacity of a battery is measured at 77°F (25°C). Any variation in this temperature will alter the performance of the battery, and shorten its expected life. High temperatures especially reduce overall battery life & run time. •...
  • Page 18 “End of useful life” refers to the point at which a battery can no longer supply 80% of its original rated capacity in ampere-hours. After this point, the aging process will accelerate and the battery will need to be replaced. e4.5 Owner's Manual.indd, Last Modified: December 28, 2012 10:49 AM...

  • Page 19: Battery Charging

    BATTeRy CHARgIng Plug the battery charger into a wall outlet, then into the charger port on the neck of the scooter. The indicator light on the face of the charger will turn red, showing that charging has started. When charging is complete, the indicator light will turn green.

  • Page 20: Maintenance

    ...check the drive chain for broken or damaged links..inspect the frame, especially the steering mechanism for cracks or wear..check that the tires are inflated to the pressure indicated on their sidewalls. e4.5 Owner's Manual.indd, Last Modified: December 28, 2012 10:49 AM...

  • Page 21: Brake Adjustment

    Brake adjustment Although the brake on your scooter is set at the factory, you may need to adjust it slightly as the brake pad wears over time. Find the rear brake on the left side of the scooter, attached to the rear wheel. The brake barrel adjuster is shown in the photo below.
  • Page 22 If the brake lever on your scooter becomes stiff and difficult to operate, the brake cable may have become rusted or dirty inside its housing. You can easily replace the brake cable to get back to “like new” performance. The E4.5 uses a standard bicycle brake cable and cable housing that can be purchased inexpensively at any bike shop.
  • Page 23 Lever barrel adjuster Cable is drawn through brake lever. Note the gap in the Barrel adjuster is rotated to close gap. Cable housing fits barrel adjuster that allows the cable to pass through. into end of barrel adjuster.

  • Page 24: Troubleshooting

    • See instructions on page 22 for help cleaning or replacing your brake cable. For instructions on more advanced troubleshooting, please call our customer service department in California at 800-377-4532 e4.5 Owner's Manual.indd, Last Modified: December 28, 2012 10:49 AM...
  • Page 25 This page intentionally left blank...

  • Page 26: Limited Warranty

    Purchased within the United States Currie Tech Corp. D/B/A Currie Technologies (“Currie”) warranties to the original owner of each new eZIP brand electric scooter, when purchased directly from an authorized Currie reseller, to be complete and that the following components will be free from defects in material and workmanship for the period indicated below.
  • Page 27 Currie’s Limited Warranty does not cover or apply to the following: Normal wear and tear; any damage, failure and/or loss caused by accident, shipping damage, misuse, neglect, abuse and/or failure to follow instructions or warnings as stated on the product or in the applicable owner’s manual or other printed materials provided with the product;...

  • Page 28: Additional Instructions And Warnings

    Those with any mental or physical conditions that may make them susceptible to injury or impair their physical dexterity or mental capacities to recognize, understand and perform all of the safety instructions and to be able to assume the hazards inherent in operating the scooter. SAfeTy InSTRUCTIonS (InSeRT) e4.5 Owner's Manual.indd, Last Modified: December 28, 2012 10:49 AM...
  • Page 29 fCC InSTRUCTIonS FCC Warning for the battery charger Warning: Changes or modifications to the charger not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
  • Page 30 3850A Royal Ave Simi Valley, CA 93063 Phone: +1 800.377.4532 fax: +1 805.915.4321 www.CurrieTech.com...
