- Page 1 350 Series Electric Scooters Owners and Riders Instruction Manual (Standard Throttle Version) UPDATED 04 07 05...
-
Page 2: Table Of Contents
• Basic Assembly and Tool List ........Page 4 • Set Up and Operation of the 350 series Electric Scooter ....Page 5 •... - Page 3 N o t i c e : If you have any questions about scooter operation, warranty service, or the equipment and components provided with the 350 series electric scooter, please visit our website: www.currietech.com, or contact: Currie Technologies Inc., 20600 Nordhoff St., Chatsworth, CA.
-
Page 4: Basic Assembly And Tool List
Following these instructions will help insure safe riding and maximize scooter life. Tools Required: Here is a list of tools to have on hand for assembling and adjusting the 350 series scooter: • Philips head screwdriver • 10mm open end wrench (or small adjustable wrench) •... -
Page 5: Set Up And Operation Of The 350 Series Electric Scooter
1. Handlebar Assembly and Adjustment Caution: The 350 series scooter is equipped with an “Easy Fold” handlebar and stem a s s e m b l y. Take care not to pinch your hand or any of your fingers in the hinge when you are raising and locking the handlebar in place. - Page 6 2. Stem Assembly and Adjustment The stem of the 350 series electric scooter comes fully installed and tightened from the factory. The stem itself is attached to the lower hinge plate and includes a bicycle style stem expander bolt and expander wedge.
- Page 7 3. Battery Pack, Charger Port and Charger The 350 series electric scooter comes with a 24 Volt/10 AH “Plug and Play” battery pack. The battery pack is installed at the factory, and it is located under the deck plate. To access the battery, if necessary, turn the power switch to the OFF position (fig.
- Page 8 batteries and void your warranty. Changing the Battery Pack 1. Make sure the power switch is set to the OFF position. 2. Undo the deck plate mounting bolt and remove the deck. 3. Disconnect the battery power pack connector (cut zip tie holding the wire connector if necessary) and lift the battery pack out of the scooter’s figure 3...
- Page 9 RIDE YOUR SCOOTER. Contact CTI Customer Service for information and instructions at 1-800-377-4532. figure 1 Brake Operation The 350 series electric scooter is equipped with a large diameter rear band brake. It is operated using the left hand brake lever on the handlebars and is designed to provide excellent stopping power for your scooter.
- Page 10 Do not open or tamper with any of the factory sealed units; doing so may result in electric shock or injury and will render them inoperable. For answers to service questions regarding the 350 series drive train, please contact your local dealer, or call PAGE 10...
-
Page 11: Care And Maintenance: Repairs And Adjustments You Can Perform
CTI Customer Service at: 1-800-377-4532. 6. Chain Tension Adjustment Like a new brake wire, the direct drive chain can stretch during use or may occasionally come out of adjustment. Regular attention to proper chain tension and lubrication will minimize the risk of the drive chain falling off the rear sprocket and help your scooter maintain optimum performance. - Page 12 once a month using any quality bicycle chain figure a lube. Take time when you do so to check the chain tension. 7. Optional Seat and Seat Post Assembly The seat assembly is included. The seat assembly can be easily attached to the scooter. The assembly consists of: a) Comfort Seat, b) Seat Post, c) Seat Tube, d) Quick Release Seat Post Clamp (QR) e) a separate sheet of...
- Page 13 tube fully inserted. Before you ride the scooter, make sure you have tightened all parts of the seat assembly properly, especially the QR lever. Riding with a loose seat or seat post may cause a rider to fall, possibly damaging the scooter and causing serious injury.
- Page 14 easily removed from the front forks. • With a plastic bicycle tire lever “un-zip” one side of the tire from the rim. • Remove the inner tube from the tire. • Inflate the tube and inspect for leaks or punctures. •...
- Page 15 Make it a habit!) Who can ride? The 350 series scooter has a rider weight limit of 240 pounds and is intended for riders age 12 and up. Riders should have experience operating a multispeed bicycle with hand brakes, and have both good balance and coordination.
-
Page 16: Safe Riding Tips
3. Ride Straight: Do not stunt ride or jump the scooter! The 350 series scooter is simply not designed or built for stunt riding or jumping, and if riders abuse and damage the scooter by riding in that manner, the Limited Warranty won’t cover it. -
Page 17: Frequently Asked Questions
7. Ride Safe: Give yourself plenty of room to stop. This scooter travels much faster than non-powered scooters, and it carries the added weight of a motor and battery pack. Both the faster speed and the additional weight of the 350 series scooter extend the safe stopping distance compared to non-powered scooters. -
Page 18: Warranty
• How often should I recharge the batteries? Recharge them after every ride! Your scooter will perform best when the batteries are fully charged. And to help prolong battery life, make sure they are fully charged before you store the scooter for any extended period of time. •... - Page 19 Important Note: Keep a copy of your purchase receipt on hand and available in case you should need service under the warranty. We recommend you attach a copy of your receipt to this manual and store both in a safe and easy-to-remember place! V.
- Page 20 Ride Safe! Obey all local traffic laws and always ride with your helmet on! It’s the cool thing to do. Just watch the pros who ride... any 2 wheel vehicle! The 350 series electric scooter is manufactured and distributed exclusively by Currie Technologies™, 20600 Nordhoff St., Chatsworth, CA 91311. Made in China.
