Summary of Contents for Topp Music Gear X 8A
- Page 1 X 8A/10A/12A/15A...
- Page 3 INDEX INTRODUCTION HOOKUP DIAGRAMS QUICK START RIGGING PANEL DESCRIPTION FREQUENCY RESPONSE DIAGRAM WIRE CONNECTIONS TECHNICAL SPECIFICATIONS WARRANTY * X 12A, X 15A are Active Speakers for professional use , they can be used in following electromagnetic environment: residential, commercial and light industrial, urban outdoors. They are the apparatusNot intended for rack mounting.
-
Page 4: Technical Specifications
Technical Specifications Model Active X 12A System Type 2-Way Active Vented Speaker 12" Woofer, 2" Voice Coil Transducer Low 1" Neodymium Driver, 1" Voice Coil Transducer High Horn Coverage H XV 90 H x 60 V Frequency Response 60Hz-20KHz (-6dB) Crossover Frequency 2100Hz Max SPL(1M) -
Page 5: Hookup Diagrams
Technical Specifications Hookup Diagrams Two speaker in stereo operation Model Active X 8A System Type 2-Way Active Vented Speaker 8" Woofer, 1.5"voice coil Transducer Low 1" Ferrite Twitter, 1" Voice Coil Transducer Driver Horn Coverage H XV 90 H x 60 V... -
Page 6: Quick Start
Quick Start Make all initial connections with all the equipments powered off, and ensure that all the main volume controls are turned completely down. 1). Connect one side of the signal cable at your audio mixer into output left / right (with Stereo- Jack or XLR) and the other side of the cable into the line input Stereo-Jack) of your active speaker cabinet. - Page 7 Rigging The X series speaker cabinet also provides the suspension points for installation. (M10 1.5PH LENGTH: 30mm). X 12A For further details, please refer to the right illustration(OPTIONAL FUNCTIONAL) Eye bolt Suspension Point X 15A The floor use is as a function of a monitor when the angle is 45...
- Page 8 X 8A (2) AC POWER SOCKET WITH MAIN FUSE (3) LINE/MIC INPUT ON COMBO CONNECTOR (X 8A /10A ONLY LNE IN ) (4) MIX OUT ON XLR CONNECTOR (X 8A /10A ONLY LINK) (5) "INPUT SENSITIVITY" SWITCH FOR LINE & MIC...
