Summary of Contents for Topp Music Gear XCS 12A
- Page 1 XCS 12A / XCS 15A...
- Page 3 WIRE CONNECTIONS TECHNICAL SPECIFICATIONS WARRANTY * XCS 12A, XCS 15A are Active Speakers for professional use , they can be used in following electromagnetic environment: residential, commercial and light industrial, urban outdoors. They are the apparatusNot intended for rack mounting.
-
Page 5: Technical Specifications
Technical Specifications Hookup Diagrams Two speaker in stereo operation Model Active XCS 12A System Type 2-Way Active Vented Speaker /Bi-Amp. With DSP processor Transducer Low 12" Woofer, 2"voice coil Transducer Driver 1" Neodymium Driver, 1" Voice Coil Horn Coverage H x V... -
Page 6: Installation Tips
Installation Tips 1- Speakers should be placed in a position that allows for unobstructed sound projection. In many instances is beneficial for speakers to be elevated on tripod stands to achieve maximum dispersion and reach. 2- Use professional advice or service when hanging and installing speakers. Please take precautions to secure them to prevent them from falling and hurting someone. -
Page 7: Quick Start
Make all initial connections with all the equipments powered off, and ensure that all the main volume controls are turned completely down. XCS 12A 1). Connect one side of the signal cable at your audio mixer into output left / right (with Stereo- Jack or XLR) and the other side of the cable into the line input Stereo-Jack) of your active speaker cabinet. -
Page 8: Panel Description
(11) VOLUME CONTROL (12) USB PLAYER ( OPTIONAL The floor use is as a function of a monitor when the angle is 45 (13) IP CONTROL (OPTIONAL) (12) (13) Use only with a 250V fuse XCS 12A / XCS 15A...
