• Move the saw shoe (4) into the desired position. The corresponding depth of cut can be read from the scale (13).
• Tighten the lever to lock the saw shoe in place.
• Set depth adjustment of saw such that one tooth of the blade projects below the workpiece as shown in Fig. G.
ADJUSTING THE BEVEL ANGLE (FIG. H)
This tool can be set to bevel angles between 0° and 45°
• Loosen the locking knob (9) to unlock the saw shoe.
• Move the saw shoe (4) into the desired position. The corresponding bevel angle can be read from the scale (14).
• Tighten the locking knob to lock the saw shoe in place.
ATTACHING THE BLADE (FIG. I & J)
• To prevent spindle rotation engage the protrusions of the spanner wrench (8) into the holes in the outer washer (10)
as shown in Fig. I.
• Loosen and remove the blade retaining screw (11) by turning the hex wrench (15) counter- clockwise.
• Remove the outer washer.
• Place the saw blade (5) onto the inner flange (16), making sure that the arrow on the blade points in the same
direction as the arrow on the tool.
• Fit the outer washer (10) on the spindle, with the beveled edge facing away from the blade.
• Insert the blade retaining screw (11) into the hole in the spindle.
• Prevent spindle rotation by engaging the spanner wrench into the holes of the outer washer.
• Securely tighten the blade retaining screw by holding the spanner wrench and turning hex wrench clockwise to tighten
the blade retaining screw.
REMOVING THE BLADE
• To prevent spindle rotation, engage the protrusions of the spanner wrench (8) into the holes in the outer washer (10).
• Loosen and remove the blade retaining screw (11) by turning it counterclockwise using the hex wrench (15).
• Remove the outer washer (10).
• Remove the saw blade (5).
WARNING: To reduce the risk of serious personal injury, read, understand and follow all important safety warnings and
instructions prior to using tool.
IMPORTANT: READ SAFETY WARNINGS AND INSTRUCTIONS.
GUARD AGAINST KICKBACK
With unit unplugged, follow all assembly, adjustment and set up instructions. Make sure lower guard operates.
Select the proper blade for the material to be cut.
• Measure and mark work for cutting.
• Support and secure work properly (See Safety Rules and Instructions).
• Use appropriate and required safety equipment (See Safety Rules).
• Secure and maintain work area (See Safety Rules).
• With plug inserted and guard closed, make sure switch turns saw on and off.
WARNING: It is important to support the work properly and to hold the saw firmly to prevent loss of control which
could cause personal injury. Fig. C illustrates recommended hand position.
OPERATION
SWITCH
• To operate the tool, depress the trigger switch (1). The tool will continue to run as long as the trigger is depressed.
• To turn the tool off, release the trigger switch (1). There is no provision for locking the tool on, and the switch should
never be locked on by any other means.
KERF PLATE ADJUSTMENT (FIG. K)
The tool is equipped with a sight guide for straight cutting (17) and for 45° miter cutting (18).
• Be sure the saw is unplugged.
• Adjust the kerf plate as described below.
• Align the left edge of the guides (17) or (18) with the cutting line.
GENERAL CUTS
