iSimple Connect Installation Manual page 7

10. Plug in the male connector(s) on the CONNECT
on the back of the radio. Next, connect the factory harness(es) into the female
connectors on the CONNECT
connection but do not force it. Plug the Black micro-fit 24-pin connector on the
®
CONNECT vehicle harness into the CONNECT
11. To complete the installation secure the CONNECT
the cavity in the dash behind the radio. Be sure that the cables and interface
modules are not near moving parts or sharp metal edges as they may damage the
cables. To prevent rattling noises inside the dash, use zip ties, tape, or other
fasteners to mount the interfaces securely.
**PLEASE NOTE: At this point in the installation we recommend
pressing the reset button to clear the flash memory of the Connect.
This will ensure that the interface initializes properly and is recognized
by the radio.
12. With all connections made, reconnect the vehicle's battery, insert the key into
the ignition, and turn the vehicle on. Check for proper operation of the
®
CONNECT before reinstalling the factory dash panels. There is a green and
red status LED located on the interface. When operating properly the green light
will remain solid and the red light will flash with data activity.
Please visit www.iSimplesolutions.com/ConnectInfo to find the
most up to date operating instructions for your vehicle.
®
vehicle harness into the port(s)
vehicle harness. Be sure to make a firm
®
®
box.
®
and any other modules into
5
