Fluid Capacities
Crankcase (With Filter)(Note 4)
Closed Cooling System (Note 5)
In-Line Transmission (Note 4)
Walters V-Drive Transmission (Note 4)
Hurth V-Drive Transmission (Note 4)
Notes:
1) Minimum recorded compression in any one cylinder should not be less than 70% of the highest recorded cylinder.
2) Measured using an accurate shop tachometer at normal operating temperature. Idle RPM on EFI models is not
adjustable.
3) Timing must be set using special procedures indicated in the appropriate service manual. Timing cannot be set
using conventional methods. Special tool(s) required.
4) Always use dipstick to determine exact quantity of oil required. Do not fill above "FULL" mark.
5) Do not over fill. Correct level is at the "Full Cold" mark on the coolant recovery bottle when coolant is cold.
B-4
454 Carb
7 Quarts (6.62 L) With Filter (10 Quarts with Jet Pan)
14-16 Quarts (13.25-15.14 L)
2.12 Quarts (2.0 L) Dexron 3 ATF
2 Pints (0.95 L) 30W Motor Oil
4.4 Quarts (4.16 L) 15W40 Motor Oil
502 Carb
