Ford MILAN 2010 Quick Reference Manual

Multi-function lever
R otate the end of the control up/
• a nd hold for a longer
down to increase/decrease the wash cycle.
speed of the wipers.
Your vehicle is equipped with speed
Push the end of the stalk:
dependent wipers. When the wiper
• q uickly for a single swipe control is set on the intermittent
without fluid. settings, the speed of the wipers
will automatically adjust with the
• a nd hold briefly for three
vehicle speed.
swipes with washer fluid.

headlaMPS

Turns the headlamps off.
T urns on parking, instrument
panel, license plate and
tail lamps.
Turns on headlamps.
( if equipped) Automatically
turns the exterior lamps
on/off based on
available daylight.
( if equipped) Turns on fog
lamps by pulling the control
towards you.
MILAN
Panel diMMer control
2010
Press to adjust the
instrument panel brightness.
Press and hold
the interior courtesy lights.
Press to turn off.
Use extreme caution when using any device or
feature that may take your attention off the road.
Your primary responsibility is the safe operation of
the vehicle. Only use non-essential features and
devices when it is safe to do so.
150723_10_Milan_123008.indd 1-6

MeSSage center

PaSSenger airbag off
For better visibility, your vehicle access various menus and
Displays important vehicle Illuminates when the passenger
may also automatically turn on settings within the message
information through a constant airbag has been turned off due
your headlights if your windshield
monitoring of vehicle systems. center. Refer to your Owner's to the system detecting light
wipers and auto lamps
The system will notify you of Guide for more information. to medium weight in the front
(if equipped) are on.
potential problems with a display passenger seat. For complete
note: For optimal wiper of warnings followed by a long information, refer to the Front
hazard flaSher
performance, clean blades and glass indicator chime. Use the INFO, Passenger Sensing system in the
regularly. Refer to your Owner's SETUP and RESET buttons to Seating and Safety Restraints
Guide for more information. chapter of your Owner's Guide.
tilt/teleScoPe

Steering wheel controlS

Steering wheel To set the speed: • T o set a lower speed, press
1. Press ON. and hold SET – or press SET –
2. Accelerate to the repeatedly until the desired speed
to turn on
interior trunk releaSe
is reached.
desired speed.
3. Press SET + and take your • T o return to a previously set
foot off the accelerator. speed, press RESUME.
• T o set a higher speed, press
• T o turn off, depress the brake
and hold SET + or press SET +
pedal or press OFF.
repeatedly until the desired
speed is reached.
navigation SySteM aMbient lighting
(if equiPPed) (if equiPPed)
The Mobile Media Navigation Press repeatedly to turn the
System allows you to record CDs, feature on, cycle through your
listen to your saved music, play color options and turn the feature
DVDs and access climate control off. When activated, the foot well
options in addition to navigating the
areas, cup holders and center
vehicle. Refer to your Navigation
console bin illuminates with the
supplement for more information.
chosen color.
heated driver/PaSSenger
SeatS (if equiPPed)
Push once to activate high heat,
twice to activate low heat and a
third time to deactivate.
advancetrac
enhanceMent SySteM
Helps you maintain stability
and steerability of your vehicle
during a variety of road
conditions. If your vehicle
becomes stuck, try turning
off the AdvanceTrac
(by pressing the control) to
allow wheel spin and help
increase momentum to help
dig the vehicle out. Refer to
your Owner's Guide for
more information.
VOL +/- : Press to increase/ : Press to access voice
decrease volume levels. recognition, if equipped.
: Press to access the : Press to access SYNC
®
previous/next radio station, phone features, if equipped.
CD track or preset satellite
For a complete list of all
radio channel.
possible options, refer to
MEDIA: Press repeatedly your Owner's Guide.
to access all possible
media sources.

Service Engine Soon Light

Throttle Control/
Transmission Light
Illuminates briefly when the ignition is
turned on. If it remains on or is blinking Illuminates when a powertrain or AWD
after the engine is started, the On Board fault is detected. If the light remains on
Diagnostics System (OBD-II) has detected or continues to come on, contact your
a malfunction. Drive in a moderate fashion authorized dealer for service as soon
and contact your authorized dealer as soon as possible.
as possible.
Traction Control TM
ABS (Anti-lock
Illuminates when AdvanceTrac
Brake System) Light
TractionControl TM is active. If the light
Illuminates briefly when the ignition is remains on, contact your authorized dealer
turned on. If the light remains on or as soon as possible.
continues to flash, a malfunction has been
detected. Contact your authorized dealer

Low Tire Pressure Warning

as soon as possible and have the system
serviced. Normal braking (less ABS) is still Illuminates when your tire pressure is low.
functional unless the brake warning light If the light remains on, the tire pressure
should be checked. If the light does not turn
is also illuminated.
on or begins to flash when the ignition is
first turned on or while driving, contact your

Airbag Readiness Light

authorized dealer as soon as possible.
Stability
®
Illuminates briefly when the ignition is
turned on. If this light fails to illuminate,
remains on or continues to flash after the
engine is started, contact your authorized
dealer for service as soon as possible.
A chime will also sound if there is a
malfunction in the indicator light.
® system
note: The system illustrated here is the navigation based audio system.
Light
Please refer to your navigation supplement for complete information on this system.
® /
In-dash CD6/MP3 Satellite Compatible Sound System
(if equipped)
VoL/PuSh SouND
Push to turn the system on/off. Turn to Press repeatedly to access: Bass, Treble,
increase/decrease the volume. Balance, Fade, Speed compensated volume
and All seats (Occupancy mode, if equipped)
CD menu options. Press t SEEK/TRACK u to
make adjustments.
Press to enter CD/MP3 mode. If a disc is
already present in the system, CD play will
begin where it last ended. SCAN
Press for a brief sampling of all radio stations,
CD tracks or satellite radio channels
AM/FM
(if equipped). Press again to stop.
Press repeatedly to cycle through AM, FM1 or
FM2 frequency bands.
DIRECT
Press DIRECT and then, using the memory
CLoCK
presets (0-9), enter in the desired radio station,
To set the time, press CLOCK. Use the
track number, MP3 folder number
memory preset numbers (0-9) to enter the
(if in MP3 mode), or satellite radio channel.
desired time.
TuNE
SIRIuS
Turn to go to the next/previous satellite radio
Press repeatedly to cycle through SAT1, SAT2
channel, or to go up/down the radio band
and SAT3 (satellite radio modes, if equipped).
frequency in individual increments.
Press MENU when active and then OK to enter
the satellite radio menu and access more
options. Refer to your Owner's Guide for
more information.
SIRIuS ® satellite radio broadcasts music, sports, news and entertainment programming. For more
information and a complete list of SIRIUS ® satellite radio channels, visit www.sirius.com in the United
States, www.sirius-canada.ca in Canada, or call SIRIUS ® at 1–888–539–7474. Satellite radio is only
available with a valid SIRIUS ® radio subscription.
