Glīon User Manual Model No. 100
Thank you for purchasing our product. For your safety and the reliable
operation of this product, please carefully read this User Manual and Limited
Manufacturer Warranty in its entirety AND VIEW INSTRUCTIONAL VIDEOS on
our website BEFORE operating this product. The information in this manual
is accurate as of the time of printing. To determine whether updates have
been added, please visit our website (glion-scooter.com) for the latest version
of the User Manual. The website also provides videos demonstrating how to
fold, unfold, and operate the scooter.
Please do not hesitate to contact us if you have any questions:
support@glion-scooter.com
www.glion-scooter.com
Probity Cell LLC
701 4
Avenue, Suite 7
th
Holdrege, NE 68949
WARNING:
Whenever you ride this motorized
scooter, you risk death or serious injury from loss of control,
collisions and falls.
THIS IS NOT A STUNT VEHICLE, AND
SHOULD NOT BE USED AS SUCH.
When riding, use common
sense and good judgment: Always wear a helmet. Ride on legal
surfaces. Ride at a speed you can control. Be alert and
prepared for changes in your riding surface. Never ride
intoxicated or in any other manner that impairs your ability to
drive this scooter safely. Yield to pedestrians at ALL TIMES!
1
3/19/15

Advertisement

Table of Contents
loading

Related Manuals for Glion 100

Summary of Contents for Glion 100

  • Page 1 BEFORE operating this product. The information in this manual is accurate as of the time of printing. To determine whether updates have been added, please visit our website (glion-scooter.com) for the latest version of the User Manual. The website also provides videos demonstrating how to fold, unfold, and operate the scooter.

  • Page 2: Table Of Contents

    TABLE OF CONTENTS SAFETY SPECIFICATIONS AND OWNER OBLIGATIONS ............3 GLĪON MODEL 100 SPECIFICATIONS ..................... 6 GLĪON PARTS DIAGRAM ........................7 UNFOLD/FOLD INSTRUCTIONS ......................9 OVERVIEW OF YOUR GLĪON SCOOTER ..................11 OPERATING YOUR GLĪON SCOOTER .................... 14 BATTERY AND CHARGER ......................... 15 USB CHARGING PORT ........................

  • Page 3: Safety Specifications And Owner Obligations

    SAFETY SPECIFICATIONS AND OWNER OBLIGATIONS 1. LEGAL RIDING LOCATIONS: Always check and obey local laws or regulations, which govern where you can legally operate the scooter. Only operate the scooter where legally allowed and with caution. The scooter can only be operated on private property unless it is street legal in your jurisdiction.
  • Page 4 WARNING This product should not be used by persons unwilling or unable to take responsibility for their own actions. 9. INSURANCE: YOUR INSURANCE POLICIES MAY NOT PROVIDE COVERAGE FOR ACCIDENTS INVOLVING THE USE OF THIS SCOOTER. TO DETERMINE IF COVERAGE IS PROVIDED, YOU SHOULD CONTACT YOUR INSURANCE COMPANY OR AGENT.
  • Page 5 15. TEMPERATURE: Do not use the scooter when the temperature is below -5 C (23 degrees F). 16. WEATHER CONDITIONS: Avoid riding in wet or icy conditions. Stop the scooter and walk it across rough or slippery road conditions. WARNING Wet or icy weather impairs traction, braking, and visibility for riders and others.

  • Page 6: Glīon Model 100 Specifications

    GLĪON MODEL 100 SPECIFICATIONS Unfolded Dimension 970x1150x410mm Size Folded Dimension 950x300x200mm Net Weight 11.6KG Maximum Load 100KG Performance Top Speed 24km/h* Range 25km* Voltage Type Li-ion Battery Battery Capacity 6.6AH Type Brushless DC Motor Rated Output Power 250W Motor Rated Voltage...

  • Page 7: Glīon Parts Diagram

    GLĪON PARTS DIAGRAM T Bar and Handel Grip Upper Handlebar Handlebar Quick Release Lever Handlebar Height Adjustment Button Handlebar Clamp Rear Fender Neck Front Standing Board & Fender Battery Compartment Rear Wheel Hub Fender Motor/Brake Front Fork Fender Front Wheel Scooter Side View Unfolded Fender 3/19/15...
  • Page 8 Handlebar USB Phone Charging Port Scooter Charging Port Hook Plate – Must push the handlebar forward and then press the Silver Folding Lever down to release the tension on it before folding. Silver Folding Lever for Folding/Unfolding Neck (Charging and Folding Mechanism) 3/19/15...

  • Page 9: Unfold/Fold Instructions

    UNFOLD/FOLD INSTRUCTIONS For video instructions, please visit our website at glion-scooter.com. We encourage you to view the video instructions prior to folding/unfolding operation to avoid damage to your Glīon scooter. UNFOLDING YOUR SCOOTER: 1. Make sure the scooter is turned off.
  • Page 10 FOLDING YOUR SCOOTER: 1. Make sure the scooter is off. The LED battery 2. Hold the handlebar grips. Pull straight out indicator lights on the right handle grip should and then down not be on. Open the handlebar quick release lever (D).

  • Page 11: Overview Of Your Glīon Scooter

    Please see our demonstration videos on our website www.glion-scooter.com. 1. Powering On/Off: Press and hold for about 1 second the on/off switch as shown (F). The battery indicator lights will indicate the power is on by lighting. If the battery indicator lights are not lit, the scooter is turned off.
  • Page 12 3. Brake: The left twist grip is the brake (H). The brake is an electric antilock brake located inside of the rear hub motor. The further you twist the left grip towards you, the more braking force is applied. The electronic brake only works when the scooter is turned on.
  • Page 13 WARNING: For your safety and for the safety of others, please take the time to practice accelerating, braking and familiarize yourself with the scooter’s braking distance in an open and safe area before taking your scooter out into the general environment. IT IS YOUR RESPONSIBILITY TO MAINTAIN CONTROL OF YOUR SCOOTER AT ALL TIMES! 3/19/15...

  • Page 14: Operating Your Glīon Scooter

    OPERATING YOUR GLĪON SCOOTER Getting Ready: 1. Fully charge the battery. For safety reasons, the battery is only 50% charged when shipped from the factory (See Battery Charging Instructions Below). 2. Choose a controlled environment away from vehicles, obstacles, and other hazards for riding.

  • Page 15: Battery And Charger

    Riding the Scooter Powered: 1. Raise the kickstand. 2. Press the power button to turn on the scooter. The battery indicator lights on the right handle grip should be lit when the scooter is turned on. 3. With both hands on the handlebar and one foot located towards the front half of the standing board and one foot on the ground, manually push the scooter forward and slowly twist the accelerator.
  • Page 16 1. The battery is charging when the LED light on the charger is red. When the battery is 100% charged, the charger will automatically stop charging and the light on the charger will go from red to green. When the LED light on the charger is green, the battery is fully charged.
  • Page 17 INSTRUCTIONS FOR CHARGING: 1. Turn the scooter off. The charge port (K) is located on the frame of the scooter above the folding mechanism. Open the charge port rubber protective cover and securely plug the charger into the charge port. 2.

  • Page 18: Usb Charging Port

    BATTERY INDICATOR LIGHTS 1. The battery indicator lights (J) are located on the right handle grip. When the scooter is turned on, the battery indicator lights are turned on. 2. Green means the battery is fully charged. Yellow means the battery is approximately 50% charged.

  • Page 19: Battery Disconnect

    BATTERY DISCONNECT The Glīon Model 100 has a battery disconnect (M) located above the neck of the scooter. Separating this connection isolates the battery from the controls to prevent inadvertent activation during shipping or airline travel. Please make sure the pins are properly aligned before completing the connection.

  • Page 20: General Troubleshooting

    anything sounds, feels, or looks loose, or shows signs of stress replace or secure them. BATTERY: When used normally, the lithium battery provided with your scooter should not lose more than 30% of its capacity within the first 500 charging cycles. Average battery life for a properly maintained lithium ion battery is approximately 1,000 charge/discharge cycles.

  • Page 21: Cleaning, Storing, And Servicing

    Manual. Problem: Short ride time/runs slow. Possible causes/solutions: 1. Rider weight. Solution: Do not exceed 100 kg (220 lbs.) maximum weight limit. 2. Riding conditions. Solution: Use only on flat, dry surfaces. Avoid inclines and areas with debris on surface.
  • Page 22 discharged and before storing the scooter for longer periods. Even in storage, please monitor the battery level and recharge the battery fully at least once every 3 months. 4. SERVICE: Should your scooter require service, DO NOT RETURN TO THE STORE! Please contact customer service through our website.

  • Page 23: Glīon Limited Warranty

    If, during the limited warranty period, this product appears to contain a defect covered by this limited warranty, email support@glion-scooter.com, before dismantling this product. Then send the product, pre-paid and insured, to our service center for warranty repair. You will be advised of shipping instructions in reply to your email.
  • Page 24 limitations on how long an implied warranty lasts, so the above limitation may not apply to you. THIS LIMITED WARRANTY DOES NOT COVER NON-DEFECT DAMAGE, DAMAGE DUE TO NORMAL WEAR AND TEAR, DAMAGE CAUSED BY IMPROPER OPERATION, MAINTENANCE OR STORAGE OF THE PRODUCT (INCLUDING, BUT NOT LIMITED TO ABUSE, MISUSE, FAILURE TO PROVIDE REASONABLE AND NECESSSARY MAINTENANCE, UNAUTHORIZED REPAIRS OR ANY ALTERATIONS TO THIS...
  • Page 25 YOUR INSURANCE POLICIES MAY NOT PROVIDE COVERAGE FOR ACCIDENTS INVOLVING THE USE OF THIS SCOOTER. TO DETERMINE IF COVERAGE IS PROVIDED, YOU SHOULD CONTACT YOUR INSURANCE COMPANY OR AGENT. 3/19/15...
