  • Page 1 GLION SNAPnGO User Manual Model No. 325...
  • Page 2 Thank you for purchasing a SNAPnGO Electric Scooter by Probity Cell LLC doing business as GLION Electric Scooter. For your safety and the reliable operation of this product, please carefully read this User Manual in its entirety AND VIEW INSTRUCTIONAL VIDEOS on our website BEFORE operating this product.
  • Page 3 Driving a mobility scooter requires a combination of healthy traits and abilities, including but not limited to: good vision; strength; coordination; balance and concentration. If you have these traits and abilities, you are on the right track. Additionally, to safely operate the SNAPnGO, you must be able to: •...

  • Page 4: Table Of Contents

    TABLE OF CONTENTS SAFETY SPECIFICATIONS AND OWNER OBLIGATIONS ..................4 GLĪON SNAPNGO MODEL 315 SPECIFICATIONS ....................8 GLĪON MODEL 325 PARTS DIAGRAM ......................... 9 FOOT PEDAL INSTALLATION ............................10 UNFOLD/FOLD INSTRUCTIONS ..........................11 VERTICAL SELF STANDING INSTRUCTIONS ......................13 SEAT INSTALLATION ..............................13 BASKET INSTALLATION..............................

  • Page 5: Safety Specifications And Owner Obligations

    SAFETY SPECIFICATIONS AND OWNER OBLIGATIONS 1. SAFETY INSTRUCTIONS. The below instructions and tips will help you to operate your SNAPnGO safely. PLEASE NOTE - The SNAPnGO scooter is designed to be used by one person at a time and is not recommended for any person younger than 16 years old. •...
  • Page 6 6. INCLINES: Never operate this scooter on steep inclines (inclines that have slopes steeper than a standard handicap ramp). Always climb and descend inclines straight on and at slow speeds. When climbing inclines, you may need to use higher Gears (gear 3) to allow more power to the motor and maintain your speed depending on the steepness of the hill and rider weight so that the scooter does not loose momentum.
  • Page 7 descending hills or turning. The scooter has a short wheel base and can become unsteady at excessive downhill speeds or sharp turns. Do not use Gear 2 (8kmh or 5mph) or Gear 3 while making turns. 13. VISIBILITY: Do not ride your scooter at night or in conditions of poor visibility. If riding in such conditions is unavoidable, drive slowly, turning on the lights and wear reflective clothing or vest.
  • Page 8 injury as well as damage to the scooter. Always hold the retractable dolly handle to prevent it from tipping over and falling to the ground. 09/20/18...

  • Page 9: Glīon Snapngo Model 315 Specifications

    GLĪON SNAPNGO MODEL 315 SPECIFICATIONS Unfolded Dimension 43x22x35 inch Size Folded Dimension 40x22x14 inch Frame Net Weight 1 14 kg (31.3 lb) Detachable Battery Weight 1.5 kg (3.3 lb) Travel Seat Weight 1.5 kg ( 3.3 lb) Deluxe Seat 5 kg (11 lb) Maximum Load 136 KG (300 lb) Performance...

  • Page 10: Glīon Model 325 Parts Diagram

    GLĪON MODEL 325 PARTS DIAGRAM LCD Display Travel T Bar Seat Seat Post Downtube Battery Controller Rear Bumper/ handle Head lamp Seat Post Folding Storage Collar Lever Rear Motor Wheel Light Foot Pedal Rear Wheel Scooter Side View Unfolded With Travel Seat Arm Rest Lever to adjust seat horizontally...

  • Page 11: Foot Pedal Installation

    FOOT PEDAL INSTALLATION Take the scooter frame out of box. Step 1: Stand scooter up vertically on its 2 rear wheels and rear bumper (Vertical Self Standing Position) for easy access before installing the foot pedals. You can find 3 bolt holes on each side of the flanges at the bottom of the neck shown below.

  • Page 12: Unfold/Fold Instructions

    UNFOLD/FOLD INSTRUCTIONS For video instructions, please visit our website at glion-scooter.com. We encourage you to view the video instructions prior to unfolding/folding operation to avoid damage to your Glīon scooter.
  • Page 13 Folding pin in notch Push T-bar all the way VERY IMPORTANT: Push the T-bar all the way forward and make sure the folding pin is fully seated in its notch. FOLDING YOUR SCOOTER: Make sure the scooter is off. While pushing the T-bar forward a little, put one foot on the folding pedal and press.

  • Page 14: Vertical Self Standing Instructions

    VERTICAL SELF STANDING INSTRUCTIONS After you fold the scooter, you can lift the front wheel up and have the scooter stand vertically. . In the vertical self-standing position, you can also insert the seat post into the collar on driver’s side or hang the deluxe seat onto one of the foot pedals.
  • Page 15 Insert the silver seat post into the scooter seat post and make sure the pin is fully seated in the notch. And then insert the deluxe seat into the silver seat post Armrest: insert the armrest in to the armrest holder under the seat. Adjust the armrest position to find the most comfortable width and use the knob to securely tighten it.

  • Page 16: Basket Installation

    BASKET INSTALLATION Your SNAPnGO electric scooter has an optional basket. To install the basket, stand in front of the scooter front wheel and hold the basket upside down to have the hooks face towards the driver and position the hooks in-between the braces for the LCD screen. Then carefully rotate the hooks onto the T-bar and rest the hooks on the T-bar.

  • Page 17: Overview Of Your Snapngo Electric Scooter

    Any questions regarding any information contained in this Manual, our website, any support materials or any other general questions should be sent by email to support@glion-scooter.com or called in to our customer service representatives at (855) 500-2640. 1. Powering On/Off: To turn the scooter on or off, you must press and hold for about 2 seconds the on/off switch as shown below (F).
  • Page 18 feature, the motor will be in the default “braking” mode when the LCD is on and when the accelerator is not pressed. The Default gear is 1 as shown on the LCD screen G section. The speed for gear 1 is 3-4 kmh or 2 mph. Press the gear up button (F1) once, G section will show 2.

  • Page 19: Operating Your Snapngo Electric Scooter

    WARNING: For your safety and for the safety of others, please take the time to practice accelerating, turning, braking and familiarize yourself with the scooter’s braking distance in an open and safe area before taking your scooter out into the general environment. IT IS YOUR RESPONSIBILITY TO MAINTAIN CONTROL OF YOUR SCOOTER AT ALL TIMES! OPERATING YOUR SNAPnGO ELECTRIC SCOOTER...
  • Page 20 1. Install foot pedals, the deluxe seat or travel seat onto the scooter frame. Sit on the seat with both feet rested on the foot pedals. 2. Press and hold the on/off button on the right handle about two seconds to turn on the scooter.
  • Page 21 WARNING: Always ride at speeds you can comfortably and safely control. Take the time to familiarize yourself with the electronic brakes and the distance it takes to come to a complete stop at various speeds. Keep both hands on the handle grips while operating the scooter at all times. Failure to do so could result in serious injury or death.
  • Page 22 • Never travel up or down on an incline that is potentially hazardous such as one that is wet, icy, slippery, has loose gravel, etc. • Always start an incline at the base of the hill and not at an angle. •...

  • Page 23: Additional Configuration Change Using Lcd Screen

    POTHOLES AND PUDDLES Avoid all potholes and deep puddles. WARNING: Attempting to drive over potholes or uneven surfaces can cause the product to tip over backwards and can result in serioius injury or death. INDOOR USE Similar to an electric wheelchair, you are generally permitted to use the SNAPnGO inside of buildings, airports, shopping malls, stores, theaters, etc.
  • Page 24 The LCD Display is made up of 2 major components: 1. LCD screen 2 Control Buttons. The Control Buttons has 3 buttons, Up Arrow or Gear Up (UP), Switch On/Off (SW) and Down Arrow or Gear Down (DOWN). The SETTING mode has 3 different tiers: Normal Setting, P value and C value. Below is a complete instruction of settings for each mode.
  • Page 25 After modifying the km/mile setting, short press SW once to complete the NORMAL SETTING. The speed and distance flashing should stop. If user needs to get back to the OPERATING mode at this time, simply long press SW. If user needs to get into P mode in the SETTING, press and hold the Up and Down at the same time.
  • Page 26 Remember, long press SW to get out of setting at any time. Modify Gear 1 and Reverse Gear Speed and Torque Factory default for Gear 1 is 33% of Gear 3 top speed and torque. Reverse gear has a torque that matches Gear 1 torque. The 33% value could be modified. As a result, the Gear 1 speed and torque, which is also the reverse gear torque could be modified.
  • Page 27 WARNING: Adjusting the strength of the electronic brake will affect stopping distance and could lead to serious injury or death. C13 would allow user to modify the electric braking strength. Toggle to C13 and use Up or Down to change values. 5 being the strongest braking and 1 being the lowest. After modification, long press SW to get out of setting mode.

  • Page 28: Battery And Charger

    Parking Brake Instruction Your SNAPnGO scooter comes with a 2-Level parking brake design. Level 2 is tighter than level 1. Parking brake is NOT actuated Squeeze the brake handle and push the stopper in. Parking brake is on Gear 1 Squeeze the brake handle more and push the stopper in.
  • Page 29 mechanism, when the charger stops charging because either the battery is full or the charger is disconnected from the scooter, the charger must be reset by unplugging it from the outlet before it will resume charging. BATTERY: 1. Fully charge the battery before first time operation or after a long period of non-usage (see Instructions For Charging below).
  • Page 30 Detaching the battery: The battery comes with keys (2) to lock and unlock the battery from the scooter frame. Please keep the spare key in a safe place. Glion does NOT have replacement keys. Detach the charging port connecter first and then use the key provided to unlock the battery.
  • Page 31 2. The provided charger has a built in overcharge protection to prevent the battery from being overcharged. 3. Charging time is approximately 3.5 hours for a fully discharged battery. 4. Regularly inspect the charger for damage to the cord, plug, enclosure and other parts. In the event of such damage, the charger must not be used until it has been repaired or replaced.
  • Page 32 4. Soft Riding Condition. When the battery is nearly depleted, a “soft” riding condition can occur. A “soft” riding condition means the scooter can move forward at lower speed but under full speed it shuts down. This occurs because under full speed, a large instant current causes the voltage to drop in the battery reaching the controller stop limit to protect the battery and shutting down the scooter.

  • Page 33: General Troubleshooting

    landfilling, or combining a lithium ion battery with your household trash is prohibited in most jurisdictions. Locate a place that collects and recycles lithium ion batteries. To search online, go to www.call2recycle.org and enter your zip code, or if you prefer to locate a place by phone, dial 1- 877-2-RECYCLE to find the nearest retailer that collects lithium ion batteries.

  • Page 34: Cleaning, Storing, And Servicing

    WITH YOUR SCOOTER, PLEASE CONTACT CUSTOMER SERVICE by phone at 855-500-2640, by email at support@glion-scooter.com or on our website: www.glion-scooter.com. Also visit our website for replacement parts, product support, and instructional videos. Use only replacement parts supplied by Glīon. CLEANING, STORING, AND SERVICING 1.

  • Page 35: Product Registration

    (www.glion-scooter.com). Your satisfaction is our greatest priority! Glion. PRODUCT REGISTRATION We encourage you to register your Glion Electric Scooter with us. Registration helps us ensure your continued satisfaction and enables us to contact you with new product instructions. Also, registration and proof of purchase are necessary to make a warranty claim.
  • Page 36 original limited warranty period, or 90 days after Probity Cell ships the SNAPnGO/functionally equivalent product to you. Probity Cell’s responsibility to repair or replace the SNAPnGO, or to refund the purchase price, is your exclusive remedy. This warranty excludes damage caused by abuse, misuse, accidents, unauthorized repairs, alterations, modifications, failure to follow instructions in the User’s Instruction Manual and battery Operating Instruction, or other causes that are not defects in materials and workmanship for which Probity Cell is responsible.
  • Page 37 YOUR INSURANCE POLICIES MAY NOT PROVIDE COVERAGE FOR ACCIDENTS INVOLVING THE USE OF THIS SCOOTER. TO DETERMINE IF COVERAGE IS PROVIDED, YOU SHOULD CONTACT YOUR INSURANCE COMPANY OR AGENT. 09/20/18...
