MODEL 335 USER MANUAL
Thank you for purchasing the SNAPnGO Model 335 Electric Scooter from
Glion. The SNAPnGO is a top-quality electric scooter that will provide years of
enjoyment. This manual contains instructions for assembling and operating
your electric scooter. Please read and understand this manual fully before
assembling and operating your scooter. Please also view in their entirety our
Assembly Video and Operating Video on our website www.getglion.com. If
you still have any questions after reading this manual and viewing the videos,
please visit our website, send us an email, and/or give us a phone call.
We are here to help.
Website: www.getglion.com/support
Email: support@getglion.com
Phone: 855-500-2640
1 / 48
V3.1

Advertisement

Table of Contents
loading

Related Manuals for Glion SNAPnGO 335

Summary of Contents for Glion SNAPnGO 335

  • Page 1 MODEL 335 USER MANUAL Thank you for purchasing the SNAPnGO Model 335 Electric Scooter from Glion. The SNAPnGO is a top-quality electric scooter that will provide years of enjoyment. This manual contains instructions for assembling and operating your electric scooter. Please read and understand this manual fully before assembling and operating your scooter.
  • Page 2 If you have these traits and abilities, you are on the right track. Additionally, to safely operate the Glion SNAPnGO, you must be able to: •...

  • Page 3: Table Of Contents

    ADDITIONAL SAFETY GUIDELINES GLION SNAPNGO MODEL 335 SPECIFICATIONS GLION SNAPNGO MODEL 335 PARTS DIAGRAM OPEN BOX ASSEMBLY (see Open Box/Assembly Video at getglion.com) OVERVIEW OF YOUR GLION SNAPNGO ELECTRIC SCOOTER OPERATING YOUR SNAPnGO ELECTRIC SCOOTER BATTERY AND CHARGER GENERAL TROUBLESHOOTING...

  • Page 4: Safety Specifications And Owner Obligations

    • Do not carry passengers or exceed the maximum weight capacity. Do not mount or dismount the Glion SNAPnGO unless it is resting at a complete stop, on a • level surface, parking brake engaged and is turned off.
  • Page 5 Get off the Glion SNAPnGO and walk the product either up or down the incline. The scooter has a short wheelbase and a high center of gravity. It may become unsteady at excessive speeds.
  • Page 6 device and is not intended to assist, treat, diagnose, or alleviate any medical condition or disability. This scooter is not designed or intended for stunts or tricks, including but not limited to jumps, operating on two wheels only or operating while standing on the scooter. Always stay seated, keep both hands on the handlebars, both feet on the foot pedals and all three wheels touching the 12.

  • Page 7: Additional Safety Guidelines

    WARNING! The Glion SNAPnGO is not intended for use by persons who cannot support themselves in an upright position. WARNING! Prior to operating your scooter, familiarize yourself with the location and use of controls, including the tiller for steering, the throttle for accelerating, and the handbrake for stopping.
  • Page 8 Under no circumstances should you modify, add, remove, or disable any feature, part, or function of your scooter. WARNING! Do not modify your scooter in any way not authorized by Glion. Do not use accessories if they have not been tested or approved for the scooter.
  • Page 9 Contact Glion or your authorized Dealer immediately to report the incident Weight Limitations Your scooter is rated for a maximum weight capacity. Please refer to the product specifications table for this limit. Keep in mind that the maximum weight capacity includes the combined weight of the user and any accessories mounted to the scooter.
  • Page 10 inclines in power setting 3 for maximum climbing torque. If you must stop, start up again slowly, and then accelerate cautiously. When driving down an incline, set your scooter to the slowest speed setting and drive in the forward direction only. If your scooter starts to move down the incline faster than you anticipated or desired, release the thumb throttle and engage the manual brake lever slightly until you reach your desired speed.
  • Page 11 Refer to “Overview” and “Operating Your Scooter” sections The Glion SNAPnGO is equipped with three brake systems: a manual handbrake lever, an electric motor brake and a parking brake. The brake lever must be activated manually to for braking information.
  • Page 12 engaged, and forward acceleration is stopped. The manual handbrake must be engaged to come to a controlled stop. There are three power settings. Power setting 1 is the slowest power setting. Power setting 3 is the fastest power setting. NOTICE: If the thumb throttle is released while climbing an incline, the scooter may “roll back.”...
  • Page 13 WARNING! Do not approach curbs at an angle; instead, approach any curb you intend to ascend or descend in the forward position. WARNING! The Glion SNAPnGO is intended for operation on flat, even surfaces whether indoors or outdoors. Examples of “indoors” typically include, but are not limited to, linoleum, hardwood, tile, and non-pile and low-pile carpeting.
  • Page 14 WARNING! Check battery case for signs of damage. If the battery case appears damaged, do not charge or use your battery and contact Glion or your authorized Dealer immediately. 14 / 48...
  • Page 15 WARNING! Be aware that the battery charger case may become hot during charging. Avoid skin contact and do not place the charger on surfaces that may be affected by heat including carpeting or clothing. WARNING! If the battery charger is equipped with cooling slots, then do not attempt to insert objects through these slots and keep the cooling slots free from objects.
  • Page 16 Figure 6 Below Left -Proper Reaching and Bending. Figure 7 Below Right -Improper Reaching and Bending. Figure 6 Figure 7 Transfers Transferring on and off your scooter requires a good sense of balance. Always have an attendant present while learning to properly transfer. To eliminate the possibility of injury, we recommend that you or a trained attendant perform the following tasks before attempting a transfer: ■...
  • Page 17 Drugs/Medications Users must exercise care and common sense when operating a scooter. This includes awareness of safety issues that arise when taking prescribed or over-the-counter drugs/medications. WARNING! Consult with your physician if you are taking prescribed or over-the- counter drugs/medications. Some drugs/medications may impair your ability to operate your scooter safely.
  • Page 18 combustible materials. Contact your oxygen dealer for information on using oxygen safely. WARNING! Replace worn or damaged upholstery immediately to reduce the risk of fire hazard. WARNING! Be aware that washing of upholstered items may reduce the resistance to flammability of the fabric Hazardous Environments WARNING! Due to the electrical make-up of our products, we do not recommend use of our scooters in Class I Division I industrial or commercial environments where the...
  • Page 19 Do not use a cell phone, walkie-talkie, laptop, or other radio transmitter while operating. ● Do not tamper with, modify, or attempt to repair the mobility device. Contact Glion or your authorized Dealer for service or repair. ● Avoid exposure to rain, snow, ice, salt, or standing water whenever possible.
  • Page 20 Please register your Glion Electric Scooter at https://getglion.com/product-registration/. Please keep your original proof of purchase in a safe place in the event of a warranty claim. Scooter serial number is located on the back of the seat post base.

  • Page 21: Glion Snapngo Model 335 Specifications

    * Top speed and range per charge depends on rider weight, wind speed, temperature, riding style, riding surface, battery condition, and other factors. Actual top speed and range per charge may vary. GLION SNAPNGO MODEL 335 PARTS DIAGRAM 21 / 48...

  • Page 22: Open Box Assembly (See Open Box/Assembly Video At Getglion.com)

    OPEN BOX ASSEMBLY (see Open Box/Assembly Video at getglion.com) VERY IMPORTANT: Please go to our website https://getglion.com/videos/ and select Glion contact our customer support. Also, please register on our website for manufacturer’s warranty. SNAPnGO to watch our Unboxing/Assembly Video and our Operating Video. Use the following instructions as additional assistance.
  • Page 23 FOOT REST INSTALLATION Step 1: Stand scooter up vertically on its 2 rear wheels and rear bumper (Vertical Self Standing Position) for easy access before installing the footrests. You can find 3 bolt holes on each side of the flanges at the bottom of the neck shown below. Footrests are bolted onto the flanges. Please note: there are 2 settings for each footrest.
  • Page 24 UNFOLD/FOLD INSTRUCTIONS For video instructions, please visit our website at getglion.com. We encourage you to view the video instructions prior to unfolding/folding operation to avoid damage to your Glīon scooter. UNFOLDING YOUR SCOOTER: Step on the folding pedal Hold the handlebar Step on the folding pedal to release the folding lock and lift the handlebar.
  • Page 25 VERY IMPORTANT: Push the T-bar all the way forward and make sure the folding pin is fully seated in its notch. (You will hear a “click”, which is the sound of folding pin hitting the bottom of the notch). FOLDING YOUR SCOOTER: Make sure the scooter is off.
  • Page 26 VERTICAL SELF STANDING INSTRUCTIONS Travel seat bundled with the scooter the vertical self-standing position, you can insert the seat post into the collar on driver’s side and insert the travel seat into the collar on passenger’s side. You can also use the included bungee After you fold the scooter, you can lift the front wheel up and have the scooter stand vertically.
  • Page 27 27 / 48...
  • Page 28 SEAT INSTALLATION Your SNAPnGO electric scooter comes with two seat options: Deluxe Seat (Standard) and Travel Seat (Optional). They both share the same seat post. The deluxe seat base comes with four positions to allow various distances from seat to handlebar. Using the bolts install the seat base in the ideal position for you.
  • Page 29 Armrest: insert the armrest into the armrest holder under the seat. Adjust the armrest position to find the most comfortable width and use the knob to securely tighten it. You can raise and lower the armrest if needed. Swivel lever: The deluxe seat comes with a swivel function.
  • Page 30 Travel Seat: Insert the seat post into the scooter frame. Then insert the travel seat into the seat post. You can use the included bungee cord to bundle a carry-on suitcase with the scooter while using the travel seat. Hook one end of the bungee cord to the seat post support and through the rear bumper.
  • Page 31 BASKET INSTALLATION Your SNAPnGO electric scooter has 1 wire front basket, 2 wire side baskets and 1 canvas pouch for your various cargo needs. WARNING: For your safety, the maximum load capacity for your front pouch is 6 lbs. The maximum load capacity for each basket is 10 lbs.
  • Page 32 To install the pouch, hang the pouch hooks onto the T-bar (make sure the hooks go under the braking wire before latching onto the T-bar so that the hooks do not press on the braking wire) and close the Velcro band around the handlebar down tube. To install the front basket, simply hang its hooks onto the T-bar (make sure the hooks go under the braking wire before latching onto the T-bar so that the hooks do not press on the braking wire) and have the front basket bottom bracket securely lean against the handlebar...

  • Page 33: Overview Of Your Glion Snapngo Electric Scooter

    OVERVIEW OF YOUR SNAPnGO ELECTRIC SCOOTER WARNING: SNAPnGO was designed to make everyday mobility easy. However, there are still certain risks that users should be aware of when operating a SNAPnGO electric scooter such as injury from loss of control, tipping over, collisions or falls. It is your responsibility to learn how to safely ride the SNAPnGO to potentially reduce these risks.
  • Page 34 1. Powering On/Off and Battery Indicator: To turn the scooter on, you must press the on/off switch as shown below (S) once. The Battery Indicator LED Light (S1) will indicate the power is on by lighting. If all 3 lights are on, it means the battery is at least 50% full. If only 2 lights are on, battery is below 50%.

  • Page 35: Operating Your Snapngo Electric Scooter

    7. Horn (G): When power is on, you can press the horn (G) to give alerts. WARNING: Do not make turns at high speeds or on steep inclines. Your Glion SNAPnGO may tip over. Before turning, slow down. Go straight up and straight down inclines.
  • Page 36 Getting Ready: 1. Fully charge the battery. For safety reasons, the battery is only 50% charged when shipped from the factory (See Battery Charging Instructions Below). 2. Choose a controlled environment away from vehicles, obstacles, and other hazards for riding. Even if you have experience with motorized scooters, vehicles, bicycles, etc., you must familiarize yourself with the function, handling, turning, ramp climbing, braking distance, performance, and safety of this scooter in a safe and...
  • Page 37 PLEASE NOTE – SNAPnGO is a front-wheel-drive scooter. As a result, fast starts can and come to a complete stop. Repeat this process several times, each time allowing the scooter to venture farther before applying the hand brake to come to a complete stop. cause its front wheel to spin, which can be dangerous for drivers.
  • Page 38 you may find yourself negotiating a curve or corner too fast and the inner rear wheel starts to lift off the ground. If this happens, immediately reduce your speed, lessen the steering angle, and shift your upper body toward the wheel that is lifting off the ground.
  • Page 39 Generally, the SNAPnGO can handle slightly uneven surfaces. You should approach each at a reduced speed and in a direct frontal position (perpendicular to the obstacle). WARNING: Attempting to drive over speed bumps or uneven surfaces indirectly can cause the product to tip over and can result in serious injury or death.

  • Page 40: Battery And Charger

    Your SNAPnGO scooter comes with a 2-Level parking brake design. Level 2 is tighter than level 1. Squeezing the brake handle should release the parking brake. BATTERY AND CHARGER Each electric scooter is equipped with a lithium battery and a smart charger designed specifically for each other.
  • Page 41 replaced. Unplug the charger and disconnect from the scooter when not in use. As a safety mechanism, when the charger stops charging because either the battery is full or the charger is disconnected from the scooter, the charger must be reset by unplugging it from the outlet before it will resume charging.
  • Page 42 protect your investment, never detach battery and leave the exposed battery docking station in the rain. This will short and damage the battery. CHARGER: 1. The battery is charging when the LED light on the charger is red. When the battery is 100% charged, the light on the charger will go from red to green.
  • Page 43 USAGE: 1. You will not damage the battery by riding the scooter until the battery is fully discharged and the scooter motor shuts down. 2. Avoid operating the scooter when the battery is hot. BATTERY LEVEL INDICATOR 1. The battery level indicator lights are on the power switch control. When the scooter is turned on, the battery level indicator is on.

  • Page 44: General Troubleshooting

    BATTERY DISPOSAL: Your Glion product uses lithium-ion batteries, which must be recycled or disposed of in an environmentally safe manner. Do not dispose of a lithium-ion battery in a fire. The battery may explode. Do not dispose of a lithium-ion battery with your household trash. The incineration, landfilling, or combining a lithium-ion battery with your household trash is prohibited in most jurisdictions.

  • Page 45: Cleaning, Storing, And Servicing

    5. The on/off switch on the battery is off. Solution: Turn switch on by pressing straight line side of battery switch down. Problem: The Scooter Operates Intermittently. Possible causes/solutions: 1. The battery is low on charge causing soft riding condition. See page 45 above for description of soft riding condition.

  • Page 46: Product Registration

    Your satisfaction is our greatest priority! Glion. PRODUCT REGISTRATION We encourage you to register your Glion Electric Scooter with us. Registration helps us ensure your continued satisfaction and enables us to contact you with new product instructions. Also, registration and proof of purchase are necessary to make a warranty claim.
  • Page 47 instructions in the User’s Instruction Manual and battery Operating Instruction, or other causes refund the purchase price, is your exclusive remedy. This warranty excludes damage caused by abuse, misuse, accidents, unauthorized repairs, alterations, modifications, failure to follow that are not defects in materials and workmanship for which Probity Cell is responsible. This Limited Warranty does not cover parts which may, under normal wear and tear, require replacement including, without limitation, tires, upholstery, fuses, etc.
  • Page 48 YOUR INSURANCE POLICIES MAY NOT PROVIDE COVERAGE FOR ACCIDENTS INVOLVING THE USE OF THIS SCOOTER. TO DETERMINE IF COVERAGE IS PROVIDED, YOU SHOULD CONTACT YOUR INSURANCE COMPANY OR AGENT. 48 / 48...
