- Page 1 Balto Electric Scooter User Manual...
- Page 2 THIS MANUAL CONTAINS IMPORTANT SAFETY, PERFORMANCE, AND SERVICE INFORMATION. Read it before you take the first ride on your new Glion Electric Scooter, and keep it for reference. Whenever you ride this motorized scooter, you risk death or serious injury from loss of control, collisions, and falls.
- Page 3 SAFETY SPECIFICATIONS AND OWNER OBLIGATIONS ..................3 ......................7 OPEN BOX INSTRUCTIONS .............................. 8 UNFOLD/FOLD INSTRUCTIONS ............................ 8 SEAT, LUGGAGE RACK AND BASKET INSTALLATIONS ..................13 ................15 ....................16 BATTERY AND CHARGER .............................. 17 DOLLY FEATURE ................................19 ......................20 GENERAL TROUBLESHOOTING ..........................
- Page 4 ATIONS AND Always check and obey local laws or regulations, which govern where you can legally operate the scooter. Only operate the scooter where legally permitted, and do so with caution. The scooter can only be operated on private property unless it is street legal in your jurisdiction.
- Page 5 WARNING: Failure to control your speed when descending a hill can result in serious injury or death. Never permit a guest to use this scooter unless the guest has read the user manual and all the warnings. Always provide a guest with helmet, elbow pads, and knee pads before permitting the guest to operate the scooter.
- Page 6 Avoid riding in wet or icy conditions. Stop the scooter and walk it across rough or slippery road conditions. WARNING Wet or icy weather impairs traction, braking, and visibility for riders and other vehicles and pedestrians sharing the roads. The risk of accident is dramatically increased in wet or icy conditions. The scooter is intended for use on hard, flat, dry paved surfaces without loose debris such as sand, leaves, rocks or gravel.
- Page 7 X1 SPECIFICATIONS * Top speed and range per charge depends on rider weight, wind speed, temperature, riding style, riding surface, battery condition, and other factors. Actual top speed and range per charge may vary.
- Page 8 Mode/horn/turning signal control Rear view Mirror Thumb throttle/battery indicator/Power & Light Switch Hand brake lever Controller box Folding hook Detachable batter Seat Basket Folding box & release Head Lamp lever Serial Motor Tire Number Luggage/folding Kickstand stand rack...
- Page 9 INSTRUCTIONS battery. E co gear. UNFOLD/FOLD INSTRUCTIONS www.getglion.com unfolding/ scooter. Hook Release Trigger Step 1. Lay the folded scooter on ground or floor with head lamp facing you. The scooter handlebar is locked to the rear fork via the folding hook. Push/pull the hook release trigger towards the direction of handlebar to allow the folding hook to come out and the handle bar is unlocked from the rear fork.
- Page 10 Step with your body weight on the side of the board that is close to you. Step 2. Hold the horizontal handle bar and lift it up to its while both wheels are on the ground. At this point, the standing board is tilted and the folding box at the neck is separated.
- Page 11 In order to make sure the detachable battery connection is tight and safe for road bumps, Balto has multiple designs. After sliding the battery onto its docking station, tighten the strap around the battery and lock the battery using provided keys.
- Page 12 Step 1. Make sure the scooter is off. The LED battery indicator screen on the right handle grip should not be lit. Fold the rear view mirror. Kick up the kickstand and put one foot on the standing board. Use left hand to hold scooter handle bar and use right hand to lift the folding release lever (1) and move it out of its notch (2).
- Page 13 wheel and bring the folding hook into its locking notch. and the hook release trigger should go back to its original position to lock the folding hook. Failure to securely lock the handle bar could cause the scooter to unfold and fall resulting in significant damage to the scooter when scooter is in its vertical dolly position.
- Page 14 battery.) become To take the scooter out of the rack, reverse above steps. SEAT, (H) Grooved Safety Line Mark Fitting curves for braces are not aligned to braces when the bolt (G) is loose. As the bolt (G) gets tightened, braces will get into the fitting curves.
- Page 15 Place the luggage rack above the rear wheel as shown above. Have the rack supportsfrom both sides of the rear fork fully inserted into the resting slot (F). Make sure the tip of the rack front (I) is fully rested on the rack support notch attached to the seat post base. Close both rack locking levers (C) fully to lock the rack onto the scooter.
- Page 16 SCOOTER WARNING: For your safety, please take the time to familiarize yourself with the handlebar controls and with its movements and balance before attempting to ride your scooter with the motor engaged. Please see our demonstration videos on our website: www.getglion.com. /Off (J2): To turn the scooter on, you must press the GRAY on/off switch ONCE as shown below (F).
- Page 17 9. Kickstand: The kickstand (I) is located in the middle underneath the standing board on the left side. Be sure to always lift the kickstand before beginning operation of the scooter. WARNING: For your safety and for the safety of others, please take the time to practice accelerating, braking and familiarize yourself with the in an open and safe area before taking your scooter out into the general environment.
- Page 18 As the motor begins to slowly propel the scooter forward, place the foot which pushed off the ground onto the riding board behind your front foot. Press the thumb control more to increase speed when feeling comfortable and safe. Stop 1.
- Page 19 1. Battery charging port is located at the bottom of the battery. Fully charge the battery before first time operation or first time after a long period of non-usage (see Instructions for Charging below). The battery is fully charged when the LED light on the charger turns green.
- Page 20 2. Avoid operating the scooter when the battery is hot. DOLLY FEATURE When Balto is folded and locked vertically in the dolly rack, user can dolly the scooter by grabbing the handlebar and tilt the scooter towards the side with dolly wheels on the rack as shown below.
- Page 21 MAINTENANCE MECHANICAL: 1. Due to vibration, nuts and bolts can become loose. Make sure that all lug nuts, other nuts and bolts are securely fastened and tighten them if necessary. To test: Pick your scooter up 1-2 inches and bounce it off the ground. Do a quick visual and tactile inspection of the whole scooter.
- Page 22 Your product uses lithium ion batteries, which must be recycled or disposed of in an environmentally safe manner. Do not dispose of a lithium ion battery in a fire. The battery may explode. Do not dispose of a lithium ion battery with your household trash. The incineration, landfilling, or combining a lithium ion battery with your household trash is prohibited in most jurisdictions.
- Page 23 . Your satisfaction is our greatest priority! regulations. We encourage you to register your Glion Electric Scooter with us. Registration helps us ensure your continued satisfaction and enables us to contact you with new product instructions. Also, registration and proof of purchase are necessary to make a warranty claim. Please register your Glion Electric Scooter at www.getglion.com/register.
- Page 24 Your Glion Electric Scooter is covered by a warranty. For the specifics of this warranty, visit our website at: www.getglion.com. UNDER NO CIRCUMSTANCES SHALL PROBITY CELL LLC, DBA GLION® BE LIABLE FOR CONSEQUENTIAL, INCIDENTAL OR SPECIAL DAMAGES ARISING DIRECTLY OR INDIRECTLY IN CONNECTION WITH USE, OR INABILITY TO USE, THIS PRODUCT.
