Light for Life UC3.400 User Manual

Hide thumbs Also See for UC3.400:

Advertisement

Quick Links

TAC59063_UC3400_UserGuide_510.indd 1
UC3.400 User Guide
UC3.400 User Guide
For the best performance,
allow your light to charge for
a minimum of 4 hours before
routine use.
For enhanced performance for
the lifetime of your light, always
store the light in charging mode
on its charger when not in use.
5/10/10 4:38 PM

Advertisement

loading
Need help?

Need help?

Do you have a question about the UC3.400 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Light for Life UC3.400

  • Page 1 UC3.400 User Guide UC3.400 User Guide For the best performance, allow your light to charge for a minimum of 4 hours before routine use. For enhanced performance for the lifetime of your light, always store the light in charging mode on its charger when not in use.
  • Page 2 5.11 Tactical 4300 Spyres Way Modesto, CA, USA, 95356 www.511Tactical.com Copyright © 2010, 5.11 Tactical, All rights reserved Light For Life™ Service Center Numbers: USA Call: 1-888-511-4LFL (4535), Europe Call: +46 40 467 388 TAC59063 5.10 UC3.400 User Guide TAC59063_UC3400_UserGuide_510.indd 2...
  • Page 3 UC3.400 does not require batteries or replacement components. The UC3.400 consistently performs in a wide temperature range and is water resistant. The UC3.400 will provide a lifetime of dependable service even in the most rigorous environments. Unlike conventional rechargeable fl ashlights, the Light For Life™ is TAC59063 designed to be stored on the charger when not in use.
  • Page 4 I. Operating Instructions A. On/Off Operations The UC3.400 flashlight is operated with a multi-function button. There are multiple modes of operation with the UC3.400. You may activate the various modes by pressing the button (I/O) on the flashlight. Peak – 270 lumens Standard –...
  • Page 5 Unlike conventional flashlights, the Light for Life is designed to be stored in the charger when not in use, and in no way shortens or negatively affects its run-time or use. For optimum performance of your UC3.400 flashlight, please: •...
  • Page 6 DC plug. To Charge: Insert the tail end (with gold rings) of the UC3.400 flashlight into the charger unit until it “snaps” into place. Once inserted, the flashlight will immediately begin its 90 second charge cycle.
  • Page 7 See details below. D. Hardwiring Installation Instructions The Light For Life™ charging unit is a sophisticated power management device. When actively charging the flashlight, there are periods of moderate current consumption throughout the 90 sec recharge cycle.
  • Page 8 2. Insert the large end of the line cord into your AC power source or wall outlet. 3. Connect the large female “cigarette plug” on the adapter to the male plug attached to the flashlight charger. UC3.400 User Guide TAC59063_UC3400_UserGuide_510.indd 8 5/10/10 4:38 PM...
  • Page 9: Safety Precautions

    3. For optimal efficiency it is necessary to periodically inspect and provide preventative maintenance on the UC3.400 flashlight. If at any time the light becomes soiled, clean with a soft cloth and mild detergent.
  • Page 10 CAUTION The UC3.400 flashlight is not classified as intrinsically safe, meaning it is not approved for use in hazardous atmospheres. It is important that the UC3.400 flashlight not be used in areas requiring explosion proof lighting.
  • Page 11: Technical Specifications

    CAUTION Although the UC3.400 Flashlight is designed to be splash-proof, full submersion of the flashlight is not recommended. All use not in conformance with instructions will void warranty. CAUTION Do not attempt to service the flashlight, adapter or charger unit in any way.
  • Page 12: Warranty

    VIII. Warranty 5.11 Light For Life™ Limited Warranty 5.11, Inc. (“5.11”) warrants each Light for Life™ product (“Product”) sold by 5.11 or its authorized dealers to be free of defects in materials or workmanship for as long as you own the Product, or for the maximum period allowed by the laws of your jurisdiction, if less.
  • Page 13 5.11 warrants the chargers for Light for Life™ products for a period of one year from the date of purchase, but the chargers are otherwise subject to the same terms and conditions of this warranty. Exclusions from Coverage Excluded from coverage under this warranty are the following: •...
  • Page 14: Frequently Asked Questions

    It is also recommended for the flashlight to be periodically placed on the charger for 1 hour. The flashlight maintains optimum performance when left on the charger when not in use. UC3.400 User Guide TAC59063_UC3400_UserGuide_510.indd 14 5/10/10 4:38 PM...
  • Page 15 A: The charging unit uses very little battery power once it has completed its charge cycle and the blue light stops flashing. The low power consumption of the charger will not compromise your car’s battery when leaving the UC3.400 User Guide TAC59063_UC3400_UserGuide_510.indd 15 5/10/10 4:38 PM...
  • Page 16 A: The PC3.300 P1 flashlight runs for 45 minutes at 70 lumens, then it automatically switches to reserve mode for an additional 15 minutes starting at 25 lumens. In total, it delivers usable light for one hour. The UC3.400 flashlight runs for 1 hour at 90 lumens, then it automatically switches to reserve mode for an additional 1 hour starting at 25 lumens.
  • Page 17 A: The UC3.400 is currently not rated as intrinsically safe. Q: May the flashlight be used in IDLH atmospheres? A: The UC3.400 IS currently not rated to be used in IDLH atmospheres. IDLH means “immediate danger of life & health,” which is a safety term for environments that may have reduced oxygen levels and possible toxic conditions.
  • Page 18 It is either on or off. Q: What are the physical dimensions of the UC3.400? A: The UC3.400 is approximately 11.5 inches long, is 2.75 inches wide at the lens, has a barrel diameter of 1.75 inches, and weighs approximately 16 ounces.
  • Page 19 U.S. +1.888.511.4LFL (4535), or International +46 40230080 for additional information on how to order this accessory. Q: Are the flashlights available globally or only in the United States? A: The flashlights are available globally. UC3.400 User Guide TAC59063_UC3400_UserGuide_510.indd 19 5/10/10 4:38 PM...
  • Page 20 Q: What kind of darkness penetration can we expect from the flashlight? A: The flashlight issues a tightly-focused beam that easily illuminates objects over 100 yards away. The halo or corona is also effective at illuminating nearby objects. UC3.400 User Guide TAC59063_UC3400_UserGuide_510.indd 20 5/10/10 4:38 PM...
  • Page 21 Life warranty section at www.511tactical.com/lightforlife for locations and additional information regarding authorized repair centers near you. You may also contact one of the following technical support/repair representatives: U.S.: +1.888.511.4LFL (4535) or LFLUS@511tactical.com International: +46 40230080 or LFLEU@511tactical.com UC3.400 User Guide TAC59063_UC3400_UserGuide_510.indd 21 5/10/10 4:38 PM...
  • Page 22 Typically if you turn the flashlight on to demonstrate it’s a working device and communicate that there are capacitors inside the flashlight instead of batteries, the security team clears the flashlight for air transit inside the cabin. UC3.400 User Guide TAC59063_UC3400_UserGuide_510.indd 22 5/10/10 4:38 PM...
  • Page 23 UC3.400 User Guide TAC59063_UC3400_UserGuide_510.indd 23 5/10/10 4:38 PM...
  • Page 24 UC3.400 User Guide TAC59063_UC3400_UserGuide_510.indd 24 5/10/10 4:38 PM...
  • Page 25 UC3.400 User Guide TAC59063_UC3400_UserGuide_510.indd 25 5/10/10 4:38 PM...
  • Page 26 UC3.400 User Guide TAC59063_UC3400_UserGuide_510.indd 26 5/10/10 4:38 PM...
  • Page 27 UC3.400 User Guide TAC59063_UC3400_UserGuide_510.indd 27 5/10/10 4:38 PM...
  • Page 28 UC3.400 User Guide TAC59063_UC3400_UserGuide_510.indd 28 5/10/10 4:38 PM...
  • Page 29 UC3.400 User Guide TAC59063_UC3400_UserGuide_510.indd 29 5/10/10 4:38 PM...
  • Page 30 UC3.400 User Guide TAC59063_UC3400_UserGuide_510.indd 30 5/10/10 4:38 PM...
  • Page 31 UC3.400 User Guide TAC59063_UC3400_UserGuide_510.indd 31 5/10/10 4:38 PM...
  • Page 32 UC3.400 User Guide TAC59063_UC3400_UserGuide_510.indd 32 5/10/10 4:38 PM...
  • Page 33 UC3.400 User Guide TAC59063_UC3400_UserGuide_510.indd 33 5/10/10 4:38 PM...
  • Page 34 UC3.400 User Guide TAC59063_UC3400_UserGuide_510.indd 34 5/10/10 4:38 PM...
  • Page 35 UC3.400 User Guide TAC59063_UC3400_UserGuide_510.indd 35 5/10/10 4:38 PM...
  • Page 36 UC3.400 User Guide TAC59063_UC3400_UserGuide_510.indd 36 5/10/10 4:38 PM...
  • Page 37 UC3.400 User Guide TAC59063_UC3400_UserGuide_510.indd 37 5/10/10 4:38 PM...
  • Page 38 UC3.400 User Guide TAC59063_UC3400_UserGuide_510.indd 38 5/10/10 4:38 PM...
  • Page 39 UC3.400 User Guide TAC59063_UC3400_UserGuide_510.indd 39 5/10/10 4:38 PM...
  • Page 40 UC3.400 User Guide TAC59063_UC3400_UserGuide_510.indd 40 5/10/10 4:38 PM...
  • Page 41 UC3.400 User Guide TAC59063_UC3400_UserGuide_510.indd 41 5/10/10 4:38 PM...
  • Page 42 UC3.400 User Guide TAC59063_UC3400_UserGuide_510.indd 42 5/10/10 4:38 PM...
  • Page 43 UC3.400 User Guide TAC59063_UC3400_UserGuide_510.indd 43 5/10/10 4:38 PM...
  • Page 44 UC3.400 User Guide TAC59063_UC3400_UserGuide_510.indd 44 5/10/10 4:38 PM...
  • Page 45 UC3.400 User Guide TAC59063_UC3400_UserGuide_510.indd 45 5/10/10 4:38 PM...
  • Page 46 UC3.400 User Guide TAC59063_UC3400_UserGuide_510.indd 46 5/10/10 4:38 PM...
  • Page 47 UC3.400 User Guide TAC59063_UC3400_UserGuide_510.indd 47 5/10/10 4:38 PM...
  • Page 48 UC3.400 User Guide TAC59063_UC3400_UserGuide_510.indd 48 5/10/10 4:38 PM...
