- Page 1 Brivo Access Control System (ACS) Installation Manual – ENG-DOC-003 OCUMENT UMBER ACS5000-E ENG-WI-001...
-
Page 2: Legal Disclaimers
United States. Activation of Services Agreement Any use of this product is subject to the activation of the Brivo Systems Services Agreement. Please request a copy from Brivo Systems, LLC. and review this agreement carefully. -
Page 3: Table Of Contents
MAIN BOARD ....................22 ONNECT A LAPTOP TO THE MAIN BOARD....................23 ONNECT THE TO THE ............................23 OORS INPUT OUTPUT BOARD ......................27 ......................27 ROUND THE CONTROL CHASSIS ENG-WI-001 © 2005 Brivo Systems, LLC. All rights reserved. Page 2... - Page 4 Brivo ACS Installation Manual ACS5000-E ENG-WI-001 © 2005 Brivo Systems, LLC. All rights reserved. Page 3...
-
Page 5: Introduction
ACS Online. The Brivo software application, accessed via the Internet, which enables an organization to manage its ACS account. • Brivo Central. The off-site servers hosted by Brivo Systems, LLC. that are used to store an account’s database. Configuration and maintenance of the control panel is managed through ACS Online. -
Page 6: Pre-Installation Procedures
Use your dealer login and password to access the Extranet and download the latest PDF version of the Wiring Guide. If you have a specific model of reader or keypad that is not listed on the Brivo website, please contact Technical Support at 1-866-BRIVO-4-U to determine the compatibility. -
Page 7: Verify Shipping Contents
Brivo ACS Installation Manual ACS5000-E Verify shipping contents. 1. Locate and check the contents of the 2-Door Ethernet Control Panel kit (#ACS5000-E). The control panel kit should contain the following parts: a) 1 metal chassis (MCH-CHA-0001). Packed inside the chassis are: •... -
Page 8: Plan Your Installation
DOOR BOARD can be used to control two doors. • The same inputs and outputs that drive a door can also be used for other devices as configured through Brivo Online. In other words, DOOR BOARDs do not need to be used to control doors. WARNING: Door Wiring If a node is to be used for a door, do not connect any other device to the following terminal blocks: REX &... - Page 9 NOTE: The following copy of the installation worksheet is for reference purposes only. Clean copies of the worksheet are available in PDF format on the Dealer Extranet. ENG- WI-001 © 2005 Brivo Systems, LLC. All rights reserved. Page 8...
- Page 10 (5) Required if Internal and External sequences are Non-Matching EXAMPLE: C K D B Yes No * C Card Reader K Keypad D Dual Reader (Card Reader+Keypad) B Bioscrypt V-Smart ** REX Request-to-Exit Switch/Sensor ' 2003 Brivo Systems, Inc. All Rights Reserved. Revised 10/29/03...
-
Page 11: Decide Where To Install Each Chassis
DO NOT INSTALL THE SYSTEM IN THE FAIL SECURE MODE UNLESS PERMITTED BY THE LOCAL AUTHORITY HAVING JURISDICTION. Doing so may cause interference with the operation of panic hardware. ENG-WI-001 © 2005 Brivo Systems, LLC. All rights reserved. Page 10... - Page 12 UPS (Uninterruptible Power Supply) between the AC Mains and the transformer. ENG-WI-001 © 2005 Brivo Systems, LLC. All rights reserved. Page 11...
-
Page 13: Assembly Procedures
You will note that the control panel kit contained an adhesive Identity Label. This label should be affixed to the inside of the front door of the control chassis, beneath the large wiring guide. 5. Install the tamper switch in each chassis. ENG-WI-001 © 2005 Brivo Systems, LLC. All rights reserved. Page 12... -
Page 14: Connect The Main Board And All Expansion Boards To A Power Supply Board
+12V, Ground, AC, Power Detection, and Earth Ground to each board from the power supply. WARNING: Power Supply DO NOT USE ANY POWER SUPPLY OTHER THAN THOSE SUPPLIED WITH YOUR BRIVO PRODUCT. ENG-WI-001 © 2005 Brivo Systems, LLC. All rights reserved. Page 13... -
Page 15: Connect The Tamper Switch To The Main Board And To One Board In Each Expansion Chassis
DO NOT POWER ELECTRONIC STRIKES AND LATCHES WITH THE BATTERY (OR OTHER POWER SOURCE) USED TO POWER THE CONTROL PANEL; DOING SO WILL CAUSE DAMAGE TO THE BRIVO CONTROL PANEL. USE ONLY A UL LISTED BURGLAR ALARM OR ACCESS CONTROL SYSTEM TO POWER ELECTRONIC STRIKES AND LATCHES. -
Page 16: Connect The Battery Leads To The Power Supply
DO NOT CONNECT THE TRANSFORMER TO A SWITCHED OUTLET OR OTHERWISE CONTROLLED AC OUTLET. DO NOT CONNECT THE TRANSFORMER TO THE 120 VAC OUTLET UNTIL ALL WIRING IS COMPLETED. ENG-WI-001 © 2005 Brivo Systems, LLC. All rights reserved. Page 15... - Page 17 1. Use 18 AWG wire (minimum grade) to connect the screw terminals on the transformer to the 16 VAC POWER INPUT terminal block on the power supply board, using terminals AC1 and AC2. ENG-WI-001 © 2005 Brivo Systems, LLC. All rights reserved. Page 16...
-
Page 18: Powering And Testing Procedures
Brivo ACS Installation Manual ACS5000-E Powering and Testing Procedures WARNING: Power Precautions BEFORE POWERING UP THE CONTROL PANEL, CHECK THE FOLLOWING CONNECTIONS. MAKE SURE THAT: • The transformer is NOT plugged into the 120 VAC outlet. • All wiring to the back-up battery is DISCONNECTED. - Page 19 NOTE: A steady light is an indication of a problem, just as much as no light is. 3. If ALL power indicators are correct, attach the back-up battery and check that ALL indicators remain the same. Only then should you go on to Installation Procedures. ENG-WI-001 © 2005 Brivo Systems, LLC. All rights reserved. Page 18...
-
Page 20: Installation Procedures
1. If there is an expansion board in the control chassis, connect it to the MAIN BOARD. Figure 9. Connect Expansion Board to MAIN BOARD 2. If there are expansion chassis, in each chassis connect the second expansion board to the first one. ENG-WI-001 © 2005 Brivo Systems, LLC. All rights reserved. Page 19... - Page 21 • Wire E3 to E2 in Expansion Chassis 1. • Wire E2 in Expansion Chassis 1 to E1 in the Control Chassis. • Wire E1 to the MAIN BOARD. ENG-WI-001 © 2005 Brivo Systems, LLC. All rights reserved. Page 20...
- Page 22 9. Connect the CAN NODE ADDRESS jumpers. The silkscreen next to the CAN NODE ADDRESS pins shows how to position the jumpers for first four addresses. 10. Positions for additional address values are shown in the diagram below. ENG-WI-001 © 2005 Brivo Systems, LLC. All rights reserved. Page 21...
-
Page 23: Ignore The Aen Port
Figure 13. Connect Laptop to MAIN BOARD 1. Connect a laptop to the ADMIN port on the MAIN BOARD, using a standard Ethernet cable or a patch cable. ENG-W I-001 © 2005 Brivo Systems, LLC. All rights reserved. Page 22... -
Page 24: Connect The Lan To The Main Board
For each board node to be used for controlling a door, as indicated in the completed Installation Worksheet, make the following connections. NOTE: Doors can be wired to the MAIN BOARD or to expansion boards, including both DOOR BOARDs and INPUT OUTPUT BOARDS. ENG-WI-001 © 2005 Brivo Systems, LLC. All rights reserved. Page 23... - Page 25 “Door Closed” condition. • This circuit provides door status information (open/closed) to the control panel so ACS Online can take appropriate action locally, or send email notifications if necessary. ENG-WI-001 © 2005 Brivo Systems, LLC. All rights reserved. Page 24...
- Page 26 The outputs are programmed via ACS Online. c) Wire the Reader switches to the last block of terminals in this door node. NOTE: Refer to the Wiring Guide for Brivo approved devices and connection diagrams. ENG-WI-001 © 2005 Brivo Systems, LLC. All rights reserved.
- Page 27 Use the wire recommended by the manufacturer of the electric strike or latch. If no wire is recommended, use a minimum of 18 AWG wire with sufficient strands for the specific electronic strike or latch. ENG-WI-001 © 2005 Brivo Systems, LLC. All rights reserved. Page 26...
-
Page 28: Wire Input Output Boards
DO NOT POWER ELECTRONIC STRIKES AND LATCHES WITH THE BATTERY (OR OTHER POWER SOURCE) USED TO POWER THE CONTROL PANEL; DOING SO WILL CAUSE DAMAGE TO THE BRIVO CONTROL PANEL. USE ONLY A UL LISTED BURGLAR ALARM OR ACCESS CONTROL SYSTEM TO POWER ELECTRONIC STRIKES AND LATCHES. - Page 29 2. Use 18 AWG or larger wire to connect the chassis to a suitable earth ground. 3. The ground contact point is in the lower panel area, near the hinge for the door and in front of the power supply. ENG-WI-001 © 2005 Brivo Systems, LLC. All rights reserved. Page 28...
