Summary of Contents for DigiTech Le Lyra
- Page 1 Owner’s Manual...
-
Page 2: Declaration Of Conformity
European Contact: Your local DigiTech Sales and Service Office or Private household in the 25 member states of the EU, in Switzerland and Norway may return their used... -
Page 3: Important Safety Instructions
Warning For your protection, please read the following: Important Safety Instructions 1. Read these instructions. 2. Keep these instructions. 3. Heed all warnings. 4. Do not use this apparatus near water. 5. Clean only with dry cloth. 6. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions. 7. -
Page 4: Warranty
6. The consumer forfeits the benefits of this warranty if the product’s main assembly is opened and tampered with by anyone other than a certified DigiTech technician or, if the product is used with AC voltages outside of the range suggested by the manufacturer. - Page 5 Congratulations and thank you for purchasing the Eternal Descent Lyra FX Pedal by DigiTech! The DigiTech Lyra pedal is a limited edition stompbox featuring the tones from the music behind the Eternal Descent comic book/CD created by guitarist/comic book designer Llexi Leon. The 7 tones in Lyra were originally created using the DigiTech RP1000.
-
Page 6: Controls & Jacks
Controls & Jacks... -
Page 7: Level Knob
DC Adapter Jack Connect the included Harman PS200R power supply to this jack. Use the proper supply for your area’s Mains line voltage. Level Knob Controls the output level. Turning the knob clockwise increases the level and turning it counter-clockwise decreases the level. Gain Knob Controls the amount of amp/distortion gain in each of the Lyra types. - Page 8 Lyra Knob The Lyra knob selects one of the seven tones taken from songs of the Eternal Descent soundtrack. The selectable Lyra tones are: - A shimmering clean laden with repeats. Crystal Cascade “Memories flooding back”, “moments lost in time”, “echo in eternity” - An eerie tone with a touch of dirt and a swirling phase.
-
Page 9: Input Jack
Input Jack Connect your guitar here. Indicator LED This LED indicates when the effect is turned on or off. 8. Foot Switch Press the Foot Switch to turn the effect on and off. 9. Out 1 (Mono) Jack Use this output when connecting to a single amp input. 10. - Page 10 Connections The Lyra has a single input and a pair of stereo outputs. Follow these setup directions before use: 1. Turn the volume down on the amplifier you are connecting to. 2. Connect the pedal output to the amplifier input. 3.
- Page 11 PS200R Amplifier 2 (Optional) Amplifier 1 Amplifier 1 Amplifier 1...
-
Page 12: Specifications
Specifications Controls Level, Gain, FX Mix, Lyra, Footswitch Unit Controls: Input 1/4” Mono (Tip/Sleeve) Input Connector Type: +8 dBu Maximum Input Level: 1 MOhm Input Impedance: Outputs (1 & 2) 1/4” Mono (Tip/Sleeve) Output Connector Type: +8 dBu Maximum Output Level: 100 Ohms Output Impedance: Digital... - Page 13 Power 1.4 Watts Power: 140 mA @ 9 VDC Current Draw: PS200R (Included), Output: 9.6 VDC 300 mA Adapter: PS200R-120 US and Canada: PS200R-100 Japan: PS200R-230 Europe: PS200R-240 PS200R-240-AU Australia: Dimensions 3.13” (W) x 4.94” (L) x 2.13” (H) Unit Dimensions: 79.5 mm (W) x 125.5 mm (L) x 54.1 mm (H) Weight 0.75 lbs...
- Page 14 notes:...
- Page 15 notes:...
- Page 16 DigiTech® 8760 South Sandy Parkway Sandy, Utah 84070 PH (801) 566-8800 FAX (801) 566-7005 www.digitech.com Lyra Owner’s Manual 18-0834V-A Printed in China DigiTech is a registered trademark of Harman. ©2011 Harman. All rights reserved.
