Hepburn Operation Guide
Battery Use
Your Hepburn can be powered by 4 x Type 'D' batteries.
Be sure to insert batteries of the correct type and ensure correct polarity (+/-).
Battery Removal
1
Slide battery cover to the left and
3
Tilt product to the left, as shown,
until another battery slides over the
then lift out.
ribbon. Repeat Step 2.
+
2
Pull ribbon to remove battery then
replace the ribbon inside.
Tilt product to the right, as shown,
4
until another battery slides over the
ribbon. Repeat Step 2. Do this twice
as there are two batteries.
-
x2
